REVISED EDITION.

The first edition of Military Schools in France and Prussia was issued in 1862, as a number of the American Journal of Education; and subsequently in the same year this portion was printed as Part I. of a comprehensive survey of the whole field of Instruction in the Science and Art of War in different countries. The circumstances under which the publication was begun, are set forth in the Preface to the imperfect edition of 1862. Now that the survey in the serial chapters of the Journal is as complete as the material at the command of the Editor, and the space which he can give to this special subject enable him to make it, the several chapters have been revised and brought together in a single volume, to present the actual condition of this important department of national education in the principal states of Europe, as well as in our own country.

It is due to the late Col. Samuel Colt, the inventor of the Colt Revolver, and the founder of the Colt Patent Fire-Arms Factory—two enterprises which have changed the character and the mode of constructing fire-arms in every country—to state that the information contained in the first edition of this Treatise, was collected and prepared at his request, to assist him in maturing the plan of a School of Mechanical Engineering, which he proposed to establish on his estate at Hartford, and on which, after the breaking out of the War of Secession, he decided to engraft both military drill, and military history, and to give that scientific instruction which every graduate of our national Military and Naval Academies ought to possess. Soon after Col. Colt’s death (Jan. 10, 1862), Mrs. Elizabeth Jarvis Colt, learning what had been done in the direction of her husband’s wishes, authorized the use which has been made, of the material already collected, in the preparation of this treatise, and of the volume already published on Technical Schools in different countries, and of any more which might be collected and prepared at her expense, to illustrate any department of his plan of a scientific school at Hartford.

HENRY BARNARD.

Hartford, Conn., March, 1872.

CONTENTS.

MILITARY SCHOOLS AND EDUCATION.

An account of the Military and Naval Schools of different countries, with special reference to the extension and improvement, among ourselves, of similar institutions and agencies, both national and state, for the special training of officers and men for the exigencies of war, was promised by the Editor in his original announcement of “The American Journal and Library of Education.” Believing that the best preparation for professional and official service of any kind, either of peace or war, is to be made in the thorough culture of all manly qualities, and that all special schools should rest on the basis, and rise naturally out of a general system of education for the whole community, we devoted our first efforts to the fullest exposition of the best principles and methods of elementary instruction, and to improvements in the organization, teaching, and discipline of schools, of different grades, but all designed to give a proportionate culture of all the faculties. We have from time to time introduced the subject of Scientific Schools—or of institutions in which the principles of mathematics, mechanics, physics, and chemistry are thoroughly mastered, and their applications to the more common as well as higher arts of construction, machinery, manufactures, and agriculture, are experimentally taught. In this kind of instruction must we look for the special training of our engineers, both civil and military; and schools of this kind established in every state, should turn out every year a certain number of candidates of suitable age to compete freely in open examinations for admission to a great National School, like the Polytechnic at Paris, or the purely scientific course of the Military Academy at West Point, and then after two years of severe study, and having been found qualified by repeated examinations, semi-annual and final, by a board composed, not of honorary visitors, but of experts in each science, should pass to schools of application or training for the special service for which they have a natural aptitude and particular preparation.

The terrible realities of our present situation as a people—the fact that within a period of twelve months a million of able bodied men have been summoned to arms from the peaceful occupations of the office, the shop, and the field, and are now in hostile array, or in actual conflict, within the limits of the United States, and the no less alarming aspect of the future, arising not only from the delicate position of our own relations with foreign governments, but from the armed interference of the great Military Powers of Europe in the internal affairs of a neighboring republic, have brought up the subject of Military Schools, and Military Education, for consideration and action with an urgency which admits of no delay. Something must and will be done at once. And in reply to numerous letters for information and suggestions, and to enable those who are urging the National, State or Municipal authorities to provide additional facilities for military instruction, or who may propose to establish schools, or engraft on existing schools exercises for this purpose,—to profit by the experience of our own and other countries, in the work of training officers and men for the Art of War, we shall bring together into a single volume, “Papers on Military Education,” which it was our intention to publish in successive numbers of the New Series of the “American Journal of Education.”

This volume, as will be seen by the Contents, presents a most comprehensive survey of the Institutions and Courses of Instruction, which the chief nations of Europe have matured from their own experience, and the study of each other’s improvements, to perfect their officers for every department of military and naval service which the exigences of modern warfare require, and at the same time, furnishes valuable hints for the final organization of our entire military establishments, both national and state.

We shall publish in the Part devoted to the United States, an account of the Military Academy at West Point, the Naval Academy at Newport, and other Institutions and Agencies,—State, Associated, and Individual, for Military instruction, now in existence in this country, together with several communications and suggestions which we have received in advocacy of Military Drill and Gymnastic exercises in Schools. We do not object to a moderate amount of this Drill and these exercises, properly regulated as to time and amount, and given by competent teachers. There is much of great practical value in the military element, in respect both to physical training, and moral and mental discipline. But we do not believe in the physical degeneracy, or the lack of military aptitude and spirit of the American people—at least to the extent asserted to exist by many writers on the subject. And we do not believe that any amount of juvenile military drill, any organization of cadet-corps, any amount of rifle or musket practice, or target shooting, valuable as these are, will be an adequate substitute for the severe scientific study, or the special training which a well organized system of military institutions provides for the training of officers both for the army and navy.

Our old and abiding reliance for industrial progress, social well being, internal peace, and security from foreign aggression rests on:—

I. The better Elementary education of the whole people—through better homes and better schools—through homes, such as Christianity establishes and recognizes, and schools, common because cheap enough for the poorest, and good enough for the best,—made better by a more intelligent public conviction of their necessity, and a more general knowledge among adults of the most direct modes of effecting their improvement, and by the joint action of more intelligent parents, better qualified teachers, and more faithful school officers. This first great point must be secured by the more vigorous prosecution of all the agencies and measures now employed for the advancement of public schools, and a more general appreciation of the enormous amount of stolid ignorance and half education, or mis-education which now prevails, even in states where the most attention has been paid to popular education.

II. The establishment of a System of Public High Schools in every state—far more complete than exists at this time, based on the system of Elementary Schools, into which candidates shall gain admission only after having been found qualified in certain studies by an open examination. The studies of this class of schools should be preparatory both in literature and science for what is now the College Course, and for what is now also the requirements in mathematics in the Second Year’s Course at the Military Academy at West Point.

III. A system of Special Schools, either in connection with existing Colleges, or on an independent basis, in which the principles of science shall be taught with special reference to their applications to the Arts of Peace and War. Foremost in this class should stand a National School of Science, organized and conducted on the plan of the Polytechnic School of France, and preparatory to Special Military and Naval Schools.

IV. The Appointment to vacancies, in all higher Public Schools, either among teachers or pupils, and in all departments of the Public Service by Open Competitive Examination.

HENRY BARNARD.

Hartford, Conn., 1862.

PART I
MILITARY SYSTEM AND SCHOOLS IN FRANCE.

AUTHORITIES.

The following account of the System of Military Education in France, except in the case of three or four schools, where credit is given to other authorities, is taken from an English Document entitled “Report of the Commissioners appointed (by the Secretary of War) to consider the best mode of reorganizing the system of Training Officers for the Scientific Corps: together with an Account of Foreign and other Military Education.” Reference has been had, especially in the Programmes and Courses of Instruction to the original authorities referred to by the Commissioners.

MILITARY SYSTEM AND SCHOOLS OF FRANCE

I. MILITARY SYSTEM.

The French armies are composed of soldiers levied by yearly conscription for a service of seven years. Substitutes are allowed, but in accordance with a recent alteration, they are selected by the state. Private arrangements are no longer permitted; a fixed sum is paid over to the authorities, and the choice of the substitutes made by them.

The troops are officered partly from the military schools and partly by promotion from the ranks. The proportions are established by law. One-third of the commissions are reserved for the military schools, and one-third left for the promotion from the ranks. The disposal of the remaining third part is left to the Emperor.

The promotion is partly by seniority and partly by selection.

The following regulations exist as to the length of service in each rank before promotion can be given, during a period of peace:—

But in time of war these regulations are not in force.

Up to the rank of captain, two-thirds of the promotion takes place according to seniority, and the other one-third by selection.

From the rank of captain to that of major (chef de bataillon ou d’escadron) half of the promotion is by seniority and the other half by selection, and from major upwards, it is entirely by selection.

The steps which lead to the selection are as follows:—The general officers appointed by the minister at war to make the annual inspections of the several divisions of the army of France, who are called inspectors-general, as soon as they have completed their tours of inspection, return to Paris and assemble together for the purpose of comparing their notes respecting the officers they have each seen, and thus prepare a list arranged in the order in which they recommend that the selection for promotion should be made.

We were informed that the present minister of war almost invariably promoted the officers from the head of this list, or, in other words, followed the recommendation of the inspector-general.

II. MILITARY SCHOOLS.

The principal Military Schools at present existing in France are the following:—

The military schools are under the charge of the minister of war, with whom the authorities of the schools are in direct communication.

The expenses to the state of the military schools, including the pay of the military men who are employed in connection with them, for the year 1851, are as follows:—

From this sum, 2,224,542fr., should be deducted 421,372fr. secured from paying pupils, leaving the total cost to the state to be 1,803,308fr., or about $360,000, for about 2,100 pupils. The cost to the state for training an officer of Artillery and Engineers is about $1,500, and that of an officer of the Staff is about $1,400.

SUBJECTS AND METHODS OF INSTRUCTION
IN MATHEMATICS AS PRESCRIBED FOR ADMISSION TO THE POLYTECHNIC SCHOOL OF FRANCE.

“L’École Polytechnique” is too well known, by name at least, to need eulogy in this journal. Its course of instruction has long been famed for its completeness, precision, and adaptation to its intended objects. But this course had gradually lost somewhat of its symmetrical proportions by the introduction of some new subjects and the excessive development of others. The same defects had crept into the programme of the subjects of examination for admission to the school. Influenced by these considerations, the Legislative Assembly of France, by the law of June 5th, 1850, appointed a “Commission” to revise the programmes of admission and of internal instruction. The President of the Commission was Thenard, its “Reporter” was Le Verrier, and the other nine members were worthy to be their colleagues. They were charged to avoid the error of giving to young students, subjects and methods of instruction “too elevated, too abstract, and above their comprehension;” to see that the course prescribed should be “adapted, not merely to a few select spirits, but to average intelligences;” and to correct “the excessive development of the preparatory studies, which had gone far beyond the end desired.”

The Commission, by M. Le Verrier, prepared an elaborate report of 440 quarto pages, only two hundred copies of which were printed, and these merely for the use of the authorities. A copy belonging to a deceased member of the Commission (the lamented Professor Theodore Olivier), having come into the hands of the present writer, he has thought that some valuable hints for our use in this country might be drawn from it, presenting as it does a precise and thorough course of mathematical instruction, adapted to any latitude, and arranged in the most perfect order by such competent authorities. He has accordingly here presented, in a condensed form, the opinions of the Commission on the proper subjects for examination in mathematics, preparatory to admission to the Polytechnic School, and the best methods of teaching them.

The subjects which will be discussed are Arithmetic; Geometry; Algebra; Trigonometry; Analytical Geometry; Descriptive Geometry.

I. ARITHMETIC.

A knowledge of Arithmetic is indispensable to every one. The merchant, the workman, the engineer, all need to know how to calculate with rapidity and precision. The useful character of arithmetic indicates that its methods should admit of great simplicity, and that its teaching should be most carefully freed from all needless complication. When we enter into the spirit of the methods of arithmetic, we perceive that they all flow clearly and simply from the very principles of numeration, from some precise definitions, and from certain ideas of relations between numbers, which all minds easily perceive, and which they even possessed in advance, before their teacher made them recognize them and taught them to class them in a methodical and fruitful order. We therefore believe that there is no one who is not capable of receiving, of understanding, and of enjoying well-arranged and well-digested arithmetical instruction.

But the great majority of those who have received a liberal education do not possess this useful knowledge. Their minds, they say, are not suited to the study of mathematics. They have found it impossible to bend themselves to the study of those abstract sciences whose barrenness and dryness form so striking a contrast to the attractions of history, and the beauties of style and of thought in the great poets; and so on.

Now, without admitting entirely the justice of this language, we do not hesitate to acknowledge, that the teaching of elementary mathematics has lost its former simplicity, and assumed a complicated and pretentious form, which possesses no advantages and is full of inconveniences. The reproach which is cast upon the sciences in themselves, we out-and-out repulse, and apply it only to the vicious manner in which they are now taught.

Arithmetic especially is only an instrument, a tool, the theory of which we certainly ought to know, but the practice of which it is above all important most thoroughly to possess. The methods of analysis and of mechanics, invariably lead to solutions whose applications require reduction into numbers by arithmetical calculations. We may add that the numerical determination of the final result is almost always indispensable to the clear and complete comprehension of a method ever so little complicated. Such an application, either by the more complete condensation of the ideas which it requires, or by its fixing the mind on the subject more precisely and clearly, develops a crowd of remarks which otherwise would not have been made, and it thus contributes to facilitate the comprehension of theories in such an efficacious manner 15 that the time given to the numerical work is more than regained by its being no longer necessary to return incessantly to new explanations of the same method.

The teaching of arithmetic will therefore have for its essential object, to make the pupils acquire the habit of calculation, so that they may be able to make an easy and continual use of it in the course of their studies. The theory of the operations must be given to them with clearness and precision; not only that they may understand the mechanism of those operations, but because, in almost all questions, the application of the methods calls for great attention and continual discussion, if we would arrive at a result in which we can confide. But at the same time every useless theory must be carefully removed, so as not to distract the attention of the pupil, but to devote it entirely to the essential objects of this instruction.

It may be objected that these theories are excellent exercises to form the mind of the pupils. We answer that such an opinion may be doubted for more than one reason, and that, in any case, exercises on useful subjects not being wanting in the immense field embraced by mathematics, it is quite superfluous to create, for the mere pleasure of it, difficulties which will never have any useful application.

Another remark we think important. It is of no use to arrive at a numerical result, if we cannot answer for its correctness. The teaching of calculation should include, as an essential condition, that the pupils should be shown how every result, deduced from a series of arithmetical operations, may always be controlled in such a way that we may have all desirable certainty of its correctness; so that, though a pupil may and must often make mistakes, he may be able to discover them himself, to correct them himself, and never to present, at last, any other than an exact result.

The Programme given below is made very minute to avoid the evils which resulted from the brevity of the old one. In it, the limits of the matter required not being clearly defined, each teacher preferred to extend them excessively, rather than to expose his pupils to the risk of being unable to answer certain questions. The examiners were then naturally led to put the questions thus offered to them, so to say; and thus the preparatory studies grew into excessive and extravagant development. These abuses could be remedied only by the publication of programmes so detailed, that the limits within which the branches required for admission must be restricted should be so apparent to the eyes of all, as to render it impossible for the examiners to go out of them, and thus to permit teachers to confine their instruction within them.

The new programme for arithmetic commences with the words Decimal numeration. This is to indicate that the Duodecimal numeration will not be required.

The only practical verification of Addition and Multiplication, is to recommence these operations in a different order.

The Division of whole numbers is the first question considered at all difficult. This difficulty arises from the complication of the methods by which division is taught. In some books its explanation contains twice as many reasons as is necessary. The mind becomes confused by such instruction, and no longer understands what is a demonstration, when it sees it continued at the moment when it appeared to be finished. In most cases the demonstration is excessively complicated and does not follow the same order as the practical rule, to which it is then necessary to return. There lies the evil, and it is real and profound.

The phrase of the programme, Division of whole numbers, intends that the pupil shall be required to explain the practical rule, and be able to use it in a familiar and rapid manner. We do not present any particular mode of demonstration, but, to explain our views, we will indicate how we would treat the subject if we were making the detailed programme of a course of arithmetic, and not merely that of an examination. It would be somewhat thus:

“The quotient may be found by addition, subtraction, multiplication;

“Division of a number by a number of one figure, when the quotient is less than 10;

“Division of any number by a number less than 10;

“Division of any two numbers when the quotient has only one figure;

“Division in the most general case.

The properties of the Divisors of numbers, and the decomposition of a number into prime factors should be known by the student. But here also we recommend simplicity. The theory of the greatest common divisor, for example, has no need to be given with all the details with which it is usually surrounded, for it is of no use in practice.

The calculation of Decimal numbers is especially that in which it is indispensable to exercise students. Such are the numbers on which they will generally have to operate. It is rare that the data of a question are whole numbers; usually they are decimal numbers which are not even known with rigor, but only with a given decimal approximation; and the result which is sought is to deduce from these, other decimal numbers, themselves exact to a certain degree of approximation, 17 fixed by the conditions of the problem. It is thus that this subject should be taught. The pupil should not merely learn how, in one or two cases, he can obtain a result to within 1/n, n being any number, but how to arrive by a practicable route to results which are exact to within a required decimal, and on the correctness of which they can depend.

Let us take decimal multiplication for an example. Generally the pupils do not know any other rule than “to multiply one factor by the other, without noticing the decimal point, except to cut off on the right of the product as many decimal figures as there are in the two factors.” The rule thus enunciated is methodical, simple, and apparently easy. But, in reality, it is practically of a repulsive length, and is most generally inapplicable.

Let us suppose that we have to multiply together two numbers having each six decimals, and that we wish to know the product also to the sixth decimal. The above rule will give twelve decimals, the last six of which, being useless, will have caused by their calculation the loss of precious time. Still farther; when a factor of a product is given with six decimals, it is because we have stopped in its determination at that degree of approximation, neglecting the following decimals; whence it results that several of the decimals situated on the right of the calculated product are not those which would belong to the rigorous product. What then is the use of taking the trouble of determining them?

We will remark lastly that if the factors of the product are incommensurable, and if it is necessary to convert them into decimals before effecting the multiplication, we should not know how far we should carry the approximation of the factors before applying the above rule. It will therefore be necessary to teach the pupils the abridged methods by which we succeed, at the same time, in using fewer figures and in knowing the real approximation of the result at which we arrive.

Periodical decimal fractions are of no use. The two elementary questions of the programme are all that need be known about them.

The Extraction of the square root must be given very carefully, especially that of decimal numbers. It is quite impossible here to observe the rule of having in the square twice as many decimals as are required in the root. That rule is in fact impracticable when a series of operations is to be effected. “When a number N increases by a comparatively small quantity d, the square of that number increases very nearly as 2Nd.” It is thus that we determine the approximation with which a number must be calculated so that its square root may afterwards be obtained with the necessary exactitude. This supposes that before determining the square with all necessary precision, we have a 18 suitable lower limit of the value of the root, which can always be done without difficulty.

The Cube root is included in the programme. The pupils should know this; but while it will be necessary to exercise them on the extraction of the square root by numerous examples, we should be very sparing of this in the cube root, and not go far beyond the mere theory. The calculations become too complicated and waste too much time. Logarithms are useful even for the square root; and quite indispensable for the cube root, and still more so for higher roots.

When a question contains only quantities which vary in the same ratio, or in an inverse ratio, it is immediately resolved by a very simple method, known under the name of reduction to unity. The result once obtained, it is indispensable to make the pupils remark that it is composed of the quantity which, among the data, is of the nature of that which is sought, multiplied successively by a series of abstract ratios between other quantities which also, taken two and two, are of the same nature. Hence flows the rule for writing directly the required result, without being obliged to take up again for each question the series of reasonings. This has the advantage, not only of saving time, but of better showing the spirit of the method, of making clearer the meaning of the solution, and of preparing for the subsequent use of formulas. The consideration of “homogeneity” conduces to these results.

We recommend teachers to abandon as much as possible the use of examples in abstract numbers, and of insignificant problems, in which the data, taken at random, have no connection with reality. Let the examples and the exercises presented to students always relate to objects which are found in the arts, in industry, in nature, in physics, in the system of the world. This will have many advantages. The precise meaning of the solutions will be better grasped. The pupils will thus acquire, without any trouble, a stock of precise and precious knowledge of the world which surrounds them. They will also more willingly engage in numerical calculations, when their attention is thus incessantly aroused and sustained, and when the result, instead of being merely a dry number, embodies information which is real, useful, and interesting.

The former arithmetical programme included the theory of progressions and logarithms; the latter being deduced from the former. But the theory of logarithms is again deduced in algebra from exponents, much the best method. This constitutes an objectionable “double emploi.” There is finally no good reason for retaining these theories in arithmetic.

The programme retains the questions which can be solved by making two arbitrary and successive hypotheses on the desired result. It is true 19 that these questions can be directly resolved by means of a simple equation of the first degree; but we have considered that, since the resolution of problems by means of hypotheses, constitutes the most fruitful method really used in practice, it is well to accustom students to it the soonest possible. This is the more necessary, because teachers have generally pursued the opposite course, aiming especially to give their pupils direct solutions, without reflecting that the theory of these is usually much more complicated, and that the mind of the learner thus receives a direction exactly contrary to that which it will have to take in the end.

“Proportions” remain to be noticed.

In most arithmetics problems are resolved first by the method of “reduction to unity,” and then by the theory of proportions. But beside the objection of the “double emploi,” it is very certain that the method of reduction to unity presents, in their true light and in a complete and simple manner, all the questions of ratio which are the bases of arithmetical solutions; so that the subsequent introduction of proportions teaches nothing new to the pupils, and only presents the same thing in a more complicated manner. We therefore exclude from our programme of examination the solution of questions of arithmetic, presented under the special form which constitutes the theory of proportions.

This special form we would be very careful not to invent, if it had not already been employed. Why not say simply “The ratio of M to N is equal to that of P to Q,” instead of hunting for this other form of enunciating the same idea, “M is to N as P is to Q”? It is in vain to allege the necessities of geometry; if we consider all the questions in which proportions are used, we shall see that the simple consideration of the equality of ratios is equally well adapted to the simplicity of the enunciation and the clearness of the demonstrations. However, since all the old books of geometry make use of proportions, we retain the properties of proportions at the end of our programme; but with this express reserve, that the examiners shall limit themselves to the simple properties which we indicate, and that they shall not demand any application of proportions to the solution of arithmetical problems.

PROGRAMME OF ARITHMETIC.

II. GEOMETRY

Some knowledge of Geometry is, next to arithmetic, most indispensable to every one, and yet very few possess even its first principles. This is the fault of the common system of instruction. We do not pay sufficient regard to the natural notions about straight lines, angles, parallels, circles, etc., which the young have acquired by looking around them, and which their minds have unconsciously considered before making them a regular study. We thus waste time in giving a dogmatic form to truths which the mind seizes directly.

The illustrious Clairaut complains of this, and of the instruction commencing always with a great number of definitions, postulates, axioms, and preliminary principles, dry and repulsive, and followed by propositions equally uninteresting. He also condemns the profusion of self-evident propositions, saying, “It is not surprising that Euclid should give himself the trouble to demonstrate that two circles which intersect have not the same centre; that a triangle situated within another has the sum of its sides smaller than that of the sides of the triangle which contains it; and so on. That geometer had to convince obstinate sophists, who gloried in denying the most evident truths. It was therefore necessary that geometry, like logic, should then have the aid of formal reasonings, to close the mouths of cavillers; but in our day things have changed face; all reasoning about what mere good sense decides in advance is now a pure waste of time, and is fitted, only to obscure the truth and to disgust the reader.”

Bezout also condemns the multiplication of the number of theorems, propositions, and corollaries; an array which makes the student dizzy, and amid which he is lost. All that follows from a principle should be given in natural language as far as possible, avoiding the dogmatic form. It is true that some consider the works of Bezout deficient in rigor, but he knew better than any one what really was a demonstration. Nor do we find in the works of the great old masters less generality of views, less precision, less clearness of conception than in modern treatises. Quite the contrary indeed.

We see this in Bezout’s definition of a right line—that it tends continually towards one and the same point; and in that of a curved line—that it is the trace of a moving point, which turns aside infinitely little at each step of its progress; definitions most fruitful in consequences. When we define a right line as the shortest path from one point to another, we enunciate a property of that line which is of no use for demonstrations. When we define a curved line as one which is neither straight 22 nor composed of straight lines, we enunciate two negations which can lead to no result, and which have no connection with the peculiar nature of the curved line. Bezout’s definition, on the contrary, enters into the nature of the object to be defined, seizes its mode of being, its character, and puts the reader immediately in possession of the general idea from which are afterwards deduced the properties of curved lines and the construction of their tangents.

So too when Bezout says that, in order to form an exact idea of an angle, it is necessary to consider the movement of a line turning around one of its points, he gives an idea at once more just and more fruitful in consequences, both mathematical and mechanical, than that which is limited to saying, that the indefinite space comprised between two straight lines which meet in a point, and which may be regarded as prolonged indefinitely, is called an angle; a definition not very easily comprehended and absolutely useless for ulterior explanations, while that of Bezout is of continual service.

We therefore urge teachers to return, in their demonstrations, to the simplest ideas, which are also the most general; to consider a demonstration as finished and complete when it has evidently caused the truth to enter into the mind of the pupil, and to add nothing merely for the sake of silencing sophists.

Referring to our Programme of Geometry, given below, our first comments relate to the “Theory of parallels.” This is a subject on which all students fear to be examined; and this being a general feeling, it is plain that it is not their fault, but that of the manner in which this subject is taught. The omission of the natural idea of the constant direction of the right line (as defined by Bezout) causes the complication of the first elements; makes it necessary for Legendre to demonstrate that all right angles are equal (a proposition whose meaning is rarely understood); and is the real source of all the pretended difficulties of the theory of parallels. These difficulties are now usually avoided by the admission of a postulate, after the example of Euclid, and to regulate the practice in that matter, we have thought proper to prescribe that this proposition—Through a given point only a single parallel to a right line can be drawn—should be admitted purely and simply, without demonstration, and as a direct consequence of our idea of the nature of the right line.

We should remark that the order of ideas in our programme supposes the properties of lines established without any use of the properties of surfaces. We think that, in this respect, it is better to follow Lacroix than Legendre.

When we prove thus that three parallels always divide two right lines into proportional parts, this proposition can be extended to the case in which the ratio of the parts is incommensurable, either by the method called Reductio ad absurdum, or by the method of Limits. We especially recommend the use of the latter method. The former has in fact nothing which satisfies the mind, and we should never have recourse to it, for it is always possible to do without it. When we have proved to the pupil that a desired quantity, X, cannot be either larger or smaller than A, the pupil is indeed forced to admit that X and A are equal; but that does not make him understand or feel why that equality exists. Now those demonstrations which are of such a nature that, once given, they disappear, as it were, so as to leave to the proposition demonstrated the character of a truth evident à priori, are those which should be carefully sought for, not only because they make that truth better felt, but because they better prepare the mind for conceptions of a more elevated order. The method of limits, is, for a certain number of questions, the only one which possesses this characteristic—that the demonstration is closely connected with the essential nature of the proposition to be established.

In reference to the relations which exist between the sides of a triangle and the segments formed by perpendiculars let fall from the summits, we will, once for all, recommend to the teacher, to exercise his students in making numerical applications of relations of that kind, as often as they shall present themselves in the course of geometry. This is the way to cause their meaning to be well understood, to fix them in the mind of students, and to give these the exercise in numerical calculation to which we positively require them to be habituated.

The theory of similar figures has a direct application in the art of surveying for plans (Lever des plans). We wish that this application should be given to the pupils in detail; that they should be taught to range out and measure a straight line on the ground; that a graphometer should be placed in their hands; and that they should use it and the chain to obtain on the ground, for themselves, all the data necessary for the construction of a map, which they will present to the examiners with the calculations in the margins.

It is true that a more complete study of this subject will have to be subsequently made by means of trigonometry, in which calculation will give more precision than these graphical operations. But some pupils may fail to extend their studies to trigonometry (the course given for the Polytechnic school having become the model for general instruction in France), and those who do will thus learn that trigonometry merely gives means of more precise calculation. This application will also be 24 an encouragement to the study of a science whose utility the pupil will thus begin to comprehend.

It is common to say that an angle is measured by the arc of a circle, described from its summit or centre, and intercepted between its sides. It is true that teachers add, that since a quantity cannot be measured except by one of the same nature, and since the arc of a circle is of a different nature from an angle, the preceding enunciation is only an abridgment of the proposition by which we find the ratio of an angle to a right angle. Despite this precaution, the unqualified enunciation which precedes, causes uncertainty in the mind of the pupil, and produces in it a lamentable confusion. We will say as much of the following enunciations: “A dihedral angle is measured by the plane angle included between its sides;” “The surface of a spherical triangle is measured by the excess of the sum of its three angles above two right angles,” etc.; enunciations which have no meaning in themselves, and from which every trace of homogeneity has disappeared. Now that everybody is requiring that the students of the Polytechnic school should better understand the meaning of the formulas which they are taught, which requires that their homogeneity should always be apparent, this should be attended to from the beginning of their studies, in geometry as well as in arithmetic. The examiners must therefore insist that the pupils shall never give them any enunciations in which homogeneity is not preserved.

The proportionality of the circumferences of circles to their radii must be inferred directly from the proportionality of the perimeters of regular polygons, of the same number of sides, to their apothems. In like manner, from the area of a regular polygon being measured by half of the product of its perimeter by the radius of the inscribed circle, it must be directly inferred that the area of a circle is measured by half of the product of its circumference by its radius. For a long time, these properties of the circle were differently demonstrated by proving, for example, with Legendre, that the measure of the circle could not be either smaller or greater than that which we have just given, whence it had to be inferred that it must be equal to it. The “Council of improvement” finally decided that this method should be abandoned, and that the method of limits should alone be admitted, in the examinations, for demonstrations of this kind. This was a true advance, but it was not sufficient. It did not, as it should, go on to consider the circle, purely and simply, as the limit of a series of regular polygons, the number of whose sides goes on increasing to infinity, and to regard the circle as possessing every property demonstrated for polygons. Instead of this, they inscribed and circumscribed to the circle two polygons of the same number of sides, and 25 proved that, by the multiplication of the number of the sides of these polygons, the difference of their areas might become smaller than any given quantity, and thence, finally, deduced the measure of the area of the circle; that is to say, they took away from the method of limits all its advantage as to simplicity, by not applying it frankly.

We now ask that this shall cease; and that we shall no longer reproach for want of rigor, the Lagranges, the Laplaces, the Poissons, and Leibnitz, who has given us this principle: that “A curvilinear figure may be regarded as equivalent to a polygon of an infinite number of sides; whence it follows that whatsoever can be demonstrated of such a polygon, no regard being paid to the number of its sides, the same may be asserted of the curve.” This is the principle for the most simple application of which to the measure of the circle and of the round bodies we appeal.

Whatever may be the formulas which may be given to the pupils for the determination of the ratio of the circumference to the diameter (the “Method of isoperimeters” is to be recommended for its simplicity), they must be required to perform the calculation, so as to obtain at least two or three exact decimals. These calculations, made with logarithms, must be methodically arranged and presented at the examination. It may be known whether the candidate is really the author of the papers, by calling for explanations on some of the steps, or making him calculate some points afresh.

The enunciations relating to the measurement of areas too often leave indistinctness in the minds of students, doubtless because of their form. We desire to make them better comprehended, by insisting on their application by means of a great number of examples.

As one application, we require the knowledge of the methods of surveying for content (arpentage), differing somewhat from the method of triangulation, used in the surveying for plans (lever des plans). To make this application more fruitful, the ground should be bounded on one side by an irregular curve. The pupils will not only thus learn how to overcome this practical difficulty, but they will find, in the calculation of the surface by means of trapezoids, the first application of the method of quadratures, with which it is important that they should very early become familiar. This application will constitute a new sheet of drawing and calculations to be presented at the examination.

Most of our remarks on plane geometry apply to geometry of three dimensions. Care should be taken always to leave homogeneity apparent and to make numerous applications to the measurement of volumes.

The theory of similar polyhedrons often gives rise in the examination of the students to serious difficulties on their part. These difficulties 26 belong rather to the form than to the substance, and to the manner in which each individual mind seizes relations of position; relations always easier to feel than to express. The examiners should be content with arriving at the results enunciated in our programme, by the shortest and easiest road.

The simplicity desired cannot however be attained unless all have a common starting-point, in the definition of similar polyhedrons. The best course is assuredly to consider that theory in the point of view in which it is employed in the arts, especially in sculpture; i.e. to conceive the given system of points, M, N, P, . . . . to have lines passing from them through a point S, the pole of similitude, and prolonged beyond it to M’, N’, P’, . . . . so that SM’, SN’, SP’, . . . . are proportional to SM, SN, SP, . . . . . Then the points M’, N’, P’, . . . . form a system similar to M, N, P, . . . . .

The areas and volumes of the cylinder, of the cone, and of the sphere must be deduced from the areas and from the volumes of the prism, of the pyramid, and of the polygonal sector, with the same simplicity which we have required for the measure of the surface of the circle, and for the same reasons. It is, besides, the only means of easily extending to cones and cylinders with any bases whatever, right or oblique, those properties of cones and cylinders,—right and with circular bases,—which are applicable to them.

Numerical examples of the calculations, by logarithms, of these areas and volumes, including the area of a spherical triangle, will make another sheet to be presented to the examiners.

PROGRAMME OF GEOMETRY.

III. ALGEBRA.

Algebra4 is not, as are Arithmetic and Geometry, indispensable to every one. It should be very sparingly introduced into the general education of youth, and we would there willingly dispense with it entirely, excepting logarithms, if this would benefit the study of arithmetic and geometry. The programme of it which we are now to give, considers it purely in view of its utility to engineers, and we will carefully eliminate every thing not necessary for them.

Algebraical calculation presents no serious difficulty, when its students become well impressed with this idea, that every letter represents a number; and particularly when the consideration of negative quantities is not brought in at the outset and in an absolute manner. These quantities and their properties should not be introduced except as the solution of questions by means of equations causes their necessity to be felt, either for generalizing the rules of calculation, or for extending the meaning of the formulas to which it leads. Clairaut pursues this course. He says, “I treat of the multiplication of negative quantities, that dangerous shoal for both scholars and teachers, only after having shown its necessity to the learner, by giving him a problem in which he has to consider negative quantities independently of any positive quantities from which they are subtracted. When I have arrived at that point in the problem where I have to multiply or divide negative quantities by one another, I take the course which was undoubtedly taken by the first analysts who have had those operations to perform and who have wished to follow a perfectly sure route: I seek for a solution of the problem which does not involve these operations; I thus arrive at the result by reasonings which admit of no doubt, and I thus see what those products or quotients of negative quantities, which had given me the first solution, must be.” Bezout proceeds in the same way.

We recommend to teachers to follow these examples; not to speak to their pupils about negative quantities till the necessity of it is felt, and 32 when they have become familiar with algebraic calculation; and above all not to lose precious time in obscure discussions and demonstrations, which the best theory will never teach students so well as numerous applications.

It has been customary to take up again, in algebra, the calculus of fractions, so as to generalize the explanations given in arithmetic, since the terms of literal fractions may be any quantities whatsoever. Rigorously, this may be well, but to save time we omit this, thinking it better to employ this time in advancing and exercising the mind on new truths, rather than in returning continually to rules already given, in order to imprint a new degree of rigor on their demonstration, or to give them an extension of which no one doubts.

The study of numerical equations of the first degree, with one or several unknown quantities, must be made with great care. We have required the solution of these equations to be made by the method of substitution. We have done this, not only because this method really comprehends the others, particularly that of comparison, but for this farther reason. In treatises on algebra, those equations alone are considered whose numerical coefficients and solutions are very simple numbers. It then makes very little difference what method is used, or in what order the unknown quantities are eliminated. But it is a very different thing in practice, where the coefficients are complicated numbers, given with decimal parts, and where the numerical values of these coefficients may be very different in the same equation, some being very great and some very small. In such cases the method of substitution can alone be employed to advantage, and that with the precaution of taking the value of the unknown quantity to be eliminated from that equation in which it has relatively the greatest, coefficient. Now the method of comparison is only the method of substitution put in a form in which these precautions cannot be observed, so that in practice it will give bad results with much labor.

The candidates must present to the examiners the complete calculations of the resolution of four equations with four unknown quantities, made with all the precision permitted by the logarithmic tables of Callet, and the proof that that precision has been obtained. The coefficients must contain decimals and be very different from one another, and the elimination must be effected with the above precautions.

The teaching of the present day disregards too much the applicability of the methods given, provided only that they be elegant in their form; so that they have to be abandoned and changed when the pupils enter on practice. This disdain of practical utility was not felt by our great mathematicians, who incessantly turned their attention towards applications. 33 Thus the illustrious Lagrange made suggestions like those just given; and Laplace recommended the drawing of curves for solving directly all kinds of numerical equations.

As to literal equations of the first degree, we call for formulas sufficient for the resolution of equations of two or three unknown quantities. Bezout’s method of elimination must be given as a first application of that fruitful method of indeterminates. The general discussion of formulas will be confined to the case of two unknown quantities. The discussion of three equations with three unknown quantities, x, y, and z, in which the terms independent of the unknown quantities are null, will be made directly, by this simple consideration that the system then really includes only two unknown quantities, to wit, the ratios of x and y, for example, to z.

The resolution of inequalities of the first degree with one or more unknown quantities, was added to equations of the first degree some years ago. We do not retain that addition.

The equations of the second degree, like the first, must be very carefully given. In dwelling on the case where the coefficient of x² converges towards zero, it will be remarked that, when the coefficient is very small, the ordinary formula would give one of the roots by the difference of two numbers almost equal; so that sufficient exactness could not be obtained without much labor. It must be shown how that inconvenience may be avoided.

It is common to meet with expressions of which the maximum or the minimum can be determined by the consideration of an equation of the second degree. We retain the study of them, especially for the benefit of those who will not have the opportunity of advancing to the general theory of maxima and minima.

The theory of the algebraic calculation of imaginary quantities, given à priori, may, on the contrary, be set aside without inconvenience. It is enough that the pupils know that the different powers of √-1 continually reproduce in turn one of these four values, ±1, ±√-1. We will say as much of the calculation of the algebraic values of radicals, which is of no use. The calculation of their arithmetical values will alone be demanded. In this connection will be taught the notation of fractional exponents and that of negative exponents.

The theory of numbers has taken by degrees a disproportionate development in the examinations for admission; it is of no use in practice, and, besides, constitutes in the pure mathematics a science apart.

The theory of continued fractions at first seems more useful. It is employed in the resolution of algebraic equations, and in that of the 34 exponential equation a^x=b. But these methods are entirely unsuited to practice, and we therefore omit this theory.

The theory of series, on the contrary, claims some farther developments. Series are continually met with in practice; they give the best solutions of many questions, and it is indispensable to know in what circumstances they can be safely employed.

We have so often insisted on the necessity of teaching students to calculate, as to justify the extent of the part of the programme relating to logarithms. We have suppressed the inapplicable method of determining logarithms by continued fractions, and have substituted the employment of the series which gives the logarithm of n+1, knowing that of n. To exercise the students in the calculation of the series, they should be made to determine the logarithms of the numbers from 1 to 10, from 101 to 110, and from 10,000 to 10,010, the object of these last being to show them with what rapidity the calculation proceeds when the numbers are large; the first term of the series is then sufficient, the variations of the logarithms being sensibly proportional to the variations of the numbers, within the limits of the necessary exactness. In the logarithmic calculations, the pupils will be exercised in judging of the exactness which they may have been able to obtain: the consideration of the numerical values of the proportional parts given in the tables is quite sufficient for this purpose, and is beside the only one which can be employed in practice.

The use of the sliding rule, which is merely an application of logarithms, gives a rapid and portable means of executing approximately a great number of calculations which do not require great exactness. We desire that the use of this little instrument should be made familiar to the candidates. This is asked for by all the professors of the “School of application,” particularly those of Topography, of Artillery, of Construction, and of Applied Mechanics, who have been convinced by experience of the utility of this instrument, which has the greatest possible analogy with tables of logarithms.

Before entering on the subjects of higher algebra, it should be remembered that the reductions of the course which we have found to be so urgent, will be made chiefly on it. The general theory of equations has taken in the examinations an abnormal and improper development, not worth the time which it costs the students. We may add, that it is very rare to meet a numerical equation of a high degree requiring to be resolved, and that those who have to do this, take care not to seek its roots by the methods which they have been taught. These methods moreover are not applicable to transcendental equations, which are much more frequently found in practice.

The theory of the greatest common algebraic divisor, in its entire generality, is of no use, even in pure science, unless in the elimination between equations of any degree whatever. But this last subject being omitted, the greatest common divisor is likewise dispensed with.

It is usual in the general theory of algebraic equations to consider the derived polynomials of entire functions of x. These polynomials are in fact useful in several circumstances, and particularly in the theory of equal roots; and in analytical geometry, they serve for the discussion of curves and the determination of their tangents. But since transcendental curves are very often encountered in practice, we give in our programme the calculation of the derivatives of algebraic and fractional functions, and transcendental functions, logarithmic, exponential, and circular. This has been long called for, not only because it must be of great assistance in the teaching of analytical geometry, but also because it will facilitate the elementary study of the infinitesimal calculus.

We have not retrenched any of the general ideas on the composition of an entire polynomial by means of factors corresponding to its roots. We retain several theorems rather because they contain the germs of useful ideas than because of their practical utility, and therefore wish the examiners to restrict themselves scrupulously to the programme.

The essential point in practice is to be able to determine conveniently an incommensurable root of an algebraic or transcendental equation, when encountered. Let us consider first an algebraic equation.

All the methods which have for their object to separate the roots, or to approximate to them, begin with the substitution of the series of consecutive whole numbers, in the first member of the equation. The direct substitution becomes exceedingly complicated, when the numbers substituted become large. It may be much shortened, however, by deducing the results from one another by means of their differences, and guarding against any possibility of error, by verifying some of those results, those corresponding to the numbers easiest to substitute, such as ±10, ±20. The teacher should not fail to explain this to his pupils.

Still farther: let us suppose that we have to resolve an equation of the third degree, and that we have recognized by the preceding calculations the necessity of substituting, between the numbers 2 and 3, numbers differing by a tenth, either for the purpose of continuing to effect the separation of the roots, or to approximate nearer to a root comprised between 2 and 3. If we knew, for the result corresponding to the substitution of 2, the first, second, and third differences of the results of the new substitutions, we could thence deduce those results themselves with as much simplicity, as in the case of the whole numbers. The new third difference, for example, will be simply the thousandth part of the old 36 third difference. We may also remark that there is no possibility of error, since, the numbers being deduced from one another, when we in this way arrive at the result of the substitution of 3, which has already been calculated, the whole work will thus be verified.

Let us suppose again that we have thus recognized that the equation has a root comprised between 2.3 and 2.4; we will approximate still nearer by substituting intermediate numbers, differing by 0.01, and employing the course just prescribed. As soon as the third differences can be neglected, the calculation will be finished at once, by the consideration of an equation of the second degree; or, if it is preferred to continue the approximations till the second differences in their turn may be neglected, the calculation will then be finished by a simple proportion.

When, in a transcendental equation f(X) = 0, we have substituted in f(X) equidistant numbers, sufficiently near to each other to allow the differences of the results to be neglected, commencing with a certain order, the 4th, for example, we may, within certain limits of x, replace the transcendental function by an algebraic and entire function of x, and thus reduce the search for the roots of f(X) = 0 to the preceding theory.

Whether the proposed equation be algebraic or transcendental, we can thus, when we have obtained one root of it with a suitable degree of exactness, continue the approximation by the method of Newton.

PROGRAMME OF ALGEBRA.

IV. TRIGONOMETRY.

In explaining the use of trigonometrical tables, the pupil must be able to tell with what degree of exactness an angle can be determined by the logarithms of any of its trigonometrical lines. The consideration of the proportional parts will be sufficient for this. It will thus be seen that if the sine determines perfectly a small angle, the degree of exactness, which may be expected from the use of that line, diminishes as the angle increases, and becomes quite insufficient in the neighborhood of 90 degrees. It is the reverse for the cosine, which may serve very well to represent an angle near 90 degrees, while it would be very inexact for small angles. We see, then, that in our applications, we should distrust those formulas which give an angle by its sine or cosine. The tangent 39 being alone exempt from these difficulties, we should seek, as far as possible, to resolve all questions by means of it. Thus, let us suppose that we know the hypothenuse and one of the sides of a right-angled triangle, the direct determination of the included angle will be given by a cosine, which will be wanting in exactness if the hypothenuse of the triangle does not differ much from the given side. In that case we should begin by calculating the third side, and then use it with the first side to determine the desired angle by means of its tangent. When two sides of a triangle and the included angle are given, the tangent of the half difference of the desired angles may be calculated with advantage; but we may also separately determine the tangent of each of them. When the three sides of a triangle are given, the best formula for calculating an angle, and the only one never at fault, is that which gives the tangent of half of it.

The surveying for plans, taught in the course of Geometry, employing only graphical methods of calculation, did not need any more accurate instruments than the chain and the graphometer; but now that trigonometry furnishes more accurate methods of calculation, the measurements on the ground require more precision. Hence the requirement for the pupil to measure carefully a base, to use telescopes, verniers, etc., and to make the necessary calculations, the ground being still considered as plane. But as these slow and laborious methods can be employed for only the principal points of the survey, the more expeditious means of the plane-table and compass will be used for the details.

In spherical trigonometry, all that will be needed in geodesy should be learned before admission to the school, so that the subject will not need to be again taken up. We have specially inscribed in the programme the relations between the angles and sides of a right-angled triangle, which must be known by the students; they are those which occur in practice. In tracing the course to be pursued in the resolution of the three cases of any triangles, we have indicated that which is in fact employed in the applications, and which is the most convenient. As to the rest, ambiguous cases never occur in practice, and therefore we should take care not to speak of them to learners.

In surveying, spherical trigonometry will now allow us to consider cases in which the signals are not all in the same plane, and to operate on uneven ground, obtain its projection on the plane of the horizon, and at the same time determine differences of level.

It may be remarked that Descriptive Geometry might supply the place of spherical trigonometry by a graphical construction, but the degree of exactitude of the differences of level thus obtained would be insufficient.

V. ANALYTICAL GEOMETRY.

The important property of homogeneity must be given with clearness and simplicity.

The transformation of co-ordinates must receive some numerical applications, which are indispensable to make the student clearly see the meaning of the formulas.

The determination of tangents will be effected in the most general manner by means of the derivatives of the various functions, which we inserted in the programme of algebra. After having shown that this determination depends on the calculation of the derivative of the ordinate with respect to the abscissa, this will be used to simplify the investigation of the tangent to curves of the second degree and to curves whose equations contain transcendental functions. The discussion of these, formerly pursued by laborious indirect methods, will now become easy; and as curves with transcendental equations are frequently encountered, it will be well to exercise students in their discussion.

The properties of foci and of the directrices of curves of the second degree will be established directly, for each of the three curves, by means of the simplest equations of these curves, and without any consideration of the analytical properties of foci, with respect to the general equation of the second degree. With even greater reason will we dispense with examining whether curves of higher degree have foci, a question whose meaning even is not well defined.

We retained in algebra the elimination between two equations of the second degree with two unknown quantities, a problem which corresponds to the purely analytical investigation of the co-ordinates of the points of inter of two curves of the second degree. The final equation is in general of the fourth degree, but we may sometimes dispense with calculating that equation. A graphical construction of the curves, carefully made, will in fact be sufficient to make known, approximately, the co-ordinates of each of the points of inter; and when we shall have thus obtained an approximate solution, we will often be able to give it all the numerical rigor desirable, by successive approximations, deduced from the equations. These considerations will be extended to the investigation of the real roots of equations of any form whatever with one unknown quantity.

Analytical geometry of three dimensions was formerly entirely taught within the Polytechnic school, none of it being reserved for the course of admission. For some years past, however, candidates were required to know the equations of the right line in space, the equation of the plane, the solution of the problems which relate to it and the transformation 42 of co-ordinates. But the consideration of surfaces of the second order was reserved for the interior teaching. We think it well to place this also among the studies to be mastered before admission, in accordance with the general principle now sought to be realized, of classing with them that double instruction which does not exact a previous knowledge of the differential calculus.

We have not, however, inserted here all the properties of surfaces of the second order, but have retained only those which it is indispensable to know and to retain. The transformation of rectilinear co-ordinates, for example, must be executed with simplicity, and the teacher must restrict himself to giving his pupils a succinct explanation of the course to be pursued; this will suffice to them for the very rare cases in which they may happen to have need of them. No questions will be asked relating to the general considerations, which require very complicated theoretical discussions, and especially that of the general reduction of the equation of the second degree with three variables. We have omitted from the problems relating to the right line and to the plane, the determination of the shortest distance of two right lines.

The properties of surfaces of the second order will be deduced from the equations of those surfaces, taken directly in the simplest forms. Among these properties, we place in the first rank, for their valuable applications, those of the surfaces which can be generated by the movement of a right line.

PROGRAMME OF ANALYTICAL GEOMETRY.

VI. DESCRIPTIVE GEOMETRY.

The general methods of Descriptive Geometry,—their uses in Stone-cutting and Carpentry, in Linear Perspective, and in the determination of the Shadows of bodies,—constitute one of the most fruitful branches of the applications of mathematics. The course has always been given at the Polytechnic School with particular care, according to the plans traced by the illustrious Monge, but no part of the subject has heretofore been required for admission. The time given to it in the school, being however complained of on all sides as insufficient for its great extent and important applications, the general methods of Descriptive Geometry will henceforth be retrenched from the internal course, and be required of all candidates for admission.

As to the programme itself, it is needless to say any thing, for it was established by Monge, and the extent which he gave to it, as well as the methods which he had created, have thus far been maintained. We merely suppress the construction of the shortest distance between two right-lines, which presents a disagreeable and useless complication.

Candidates will have to present to the examiner a collection of their graphical constructions (épures) of all the questions of the programme, signed by their teacher. They are farther required to make free-hand sketches of five of their épures.

VII. OTHER REQUIREMENTS.

The preceding six heads complete the outline of the elementary course of mathematical instruction which it was the object of this article to present; but a few more lines may well be given to a mere enumeration of the other requirements for admission to the school.

Mechanics comes next. The programme is arranged under these heads: Simple motion and compound motion; Inertia; Forces applied to a free material point; Work of forces applied to a movable point; Forces applied to a solid body; Machines.

Physics comprises these topics: General properties of bodies; Hydrostatics and hydraulics; Densities of solids and liquids; Properties of gases; Heat; Steam; Electricity; Magnetism; Acoustics; Light.

Chemistry treats of Oxygen; Hydrogen; Combinations of hydrogen with oxygen; Azote or nitrogen; Combinations of azote with oxygen; Combination of azote with hydrogen, or ammonia; Sulphur; Chlorine; Phosphorus; Carbon.

Cosmography describes the Stars; the Earth; the Sun; the Moon; the Planets; Comets; the Tides.

History and Geography treat of Europe from the Roman Empire to the accession of Louis XVI.

German must be known sufficiently for it to be translated, spoken a little, and written in its own characters.

Drawing, besides the épures of descriptive geometry, must have been acquired sufficiently for copying an academic study, and shading in pencil and in India ink.

Will not our readers agree with M. Coriolis, that “There are very few learned mathematicians who could answer perfectly well at an examination for admission to the Polytechnic School”?

SCHOOLS OF PREPARATION FOR THE POLYTECHNIC SCHOOL

There are strictly speaking no Junior Military Schools preparatory to the Polytechnic School, or to the Special Military School at St. Cyr. These schools are recruited in general from the Lycées and other schools for secondary instruction, upon which they exert a most powerful influence. Until 1852 there was no special provision made in the courses of instruction in the Lycées for the mathematical preparation required for admission into the Polytechnic, and the Bachelor’s degree in science could not be obtained without being able to meet the requirements in Latin, rhetoric, and logic for graduation in the arts, which was necessary to the profession of law, medicine, and theology. In consequence, young men who prepared to be candidates for the preliminary examinations at the Polytechnic and the St. Cyr, left the Lycées before graduation in order to acquire more geometry and less literature in the private schools, or under private tuition.

A new arrangement, popularly called the Bifurcation, was introduced by the Decrees of the 10th of April, 1852; and has now come into operation. The conditions demanded for the degree in science were adapted to the requirements of the Military Schools; and in return for this concession it is henceforth to be exacted from candidates for the Military Schools. The diploma of arts is no longer required before the diploma of science can be given. The instruction, which in the upper classes of the Lycées had hitherto been mainly preparatory for the former, takes henceforth at a certain point (called that of Bifurcation) two different routes, conducting separately, the one to the baccalaureate of arts, the other to that of science. The whole system of teaching has accordingly been altered. Boys wanting to study algebra are no longer carried through a long course of Latin; mathematics are raised to an equality with literature; and thus military pupils—pupils desirous of admission at the Polytechnic and St. Cyr, may henceforth, it is hoped, obtain in the Lycées all the preparation which they had latterly sought elsewhere.

Under this new system the usual course for a boy seems to be the following:—

He enters the Lycée, in the Elementary Classes; or, a little later, in the Grammar Classes, where he learns Latin and begins Greek. At the age of about fourteen, he is called upon to pass an examination for admission into the Upper Division, and here, in accordance with the new regulations, he makes his choice for mathematics or for literature, the studies henceforth being divided, one course leading to the bachelorship of science, the other to that of arts.

In either case he has before him three yearly courses, three classes—the Third, the Second, and what is called the Rhetoric. At the close of this, or after passing, if he pleases, another year in what is called the Logic, he may go up for his bachelor’s degree. The boy who wants to go to St. Cyr or the Polytechnic chooses, of course, the mathematical division leading to the diploma he will want, that of a bachelor of science. He accordingly begins algebra, goes on to trigonometry, to conic s, and to mechanics, and through corresponding stages in natural philosophy, and the like. If he chooses to spend a fourth year in the Logic, he will be chiefly employed in going over his subjects again. He may take his bachelor’s degree at any time after finishing his third year; and he may, if he pleases, having taken that, remain during a fifth or even a sixth year, in the class of Special Mathematics.

If he be intended for St. Cyr, he may very well leave at the end of his year in Rhetoric, taking of course his degree. One year in the course of Special Mathematics will be required before he can have a chance for the Polytechnic. Usually the number of students admitted at the latter, who have not passed more than one year in the mathematiques spéciales is very small. Very probably the young aspirant would try at the end of his first year in this class, and would learn by practice to do better at the end of the second.

The following are the studies of the mathematical of the upper division as laid down by the ordinance of 30th August, 1854.

It will only be necessary to add a few sentences in explanation of the methods pursued in the upper classes of the Lycées. The classes are large—from 80 to above 100; the lessons strictly professorial lectures, with occasional questions, as at the Polytechnic itself. In large establishments the class is divided, and two professors are employed, giving two parallel courses on the same subject. To correct and fortify this general teaching, we find, corresponding to the interrogations of the Polytechnic, what are here called conferences. The members of the large class are examined first of all in small detachments of five or six by their own professors once a week; and, secondly, a matter of yet greater importance, by the professor who is conducting the parallel course, and by professors who are engaged for this purpose from other Lycées and preparatory schools, and from among the répétiteurs of the Polytechnic and the Ecole Normale themselves. It appeared by the table of the examinations of this latter kind which had been passed by the pupils of the class of Special Mathematics at the Lycée St. Louis, that the first pupil on the list had in the interval between the opening of the school and the date of our visit (February 16th) gone through as many as twenty-four.

The assistants, who bear the name of répétiteurs at the Lycées, do not correspond in any sense to those whom we shall hereafter notice at the Ecole Polytechnique. They are in the Lycées mere superintendents in the salles d’étude, who attend to order and discipline, who give some slight occasional help to the pupils, and may be 50 employed in certain cases, where the parents wish for it, in giving private tuition to the less proficient. The system of salles d’étude appears to prevail universally; the number of the pupils placed in each probably varying greatly. At the Polytechnic we found eight or ten pupils in each; at St. Cyr as many as 200. The number considered most desirable at the Lycée of St. Louis was stated to be thirty.

It thus appears that in France not only do private establishments succeed in giving preparation for the military schools, but that even in the first-class public schools, which educate for the learned professions, it has been considered possible to conduct a series of military or science classes by the side of the usual literary or arts classes. The common upper schools are not, as they used to be, and as with us they are, Grammar schools, they are also Science schools. In every Lycée there is, so to say, a sort of elementary polytechnic department, giving a kind of instruction which will be useful to the future soldier, and at the same time to others, to those who may have to do with mines, manufactures, or any description of civil engineering. There is thus no occasion for Junior Military Schools in France, for all the schools of this class are more or less of a military character in their studies.

The conditions of admission to the examination for the degree of Bachelor of Science are simply, sixteen years of age, and the payment of fees amounting to about 200 fr. (10l.) Examinations are held three times a year by the Faculties at Paris, Besançon, Bordeaux, Caen, Clermont, Dijon, Grenoble, Lille, Lyons, Marseilles, Montpellier, Nancy, Poitiers, Rennes, Strasburg, and Toulouse, and once a year at Ajaccio, Algiers, and nineteen other towns. There is a written examination of six hours, and a viva voce examination of an hour and a quarter. It is, of course, only a pass examination, and is said to be much less difficult than the competitive examination for admission to St. Cyr.—Report of English Commissioners, 1856.

THE POLYTECHNIC SCHOOL OF FRANCE.

CONTENTS.

THE POLYTECHNIC SCHOOL AT PARIS8

I. FOUNDATION AND HISTORY.

The origin of the Ecole Polytechnique dates from a period of disorder and distress in the history of France which might seem alien to all intellectual pursuits, if we did not remember that the general stimulus of a revolutionary period often acts powerfully upon thought and education. It is, perhaps, even more than the Institute, the chief scientific creation of the first French Revolution. It was during the government of the committee of public safety, when Carnot, as war minister, was gradually driving back the invading armies, and reorganizing victory out of defeat and confusion, that the first steps were taken for its establishment. A law, dating the 1st Ventose, year II., the 12th of March 1794, created a “Commission des Travaux Publics,” charged with the duty of establishing a regular system for carrying on public works; and this commission ultimately founded a central school for public works, and drew up a plan for the competitive examination of candidates for admission to the service. It was intended at first to give a complete education for some of the public services, but it was soon changed into a preparatory school, to be succeeded by special schools of application. This was the Ecole Polytechnique.

The school and its plan were both owing to an immediate and pressing want. It was to be partly military and partly civil. Military, as well as civil education had been destroyed by the revolutionists. The committee of public safety had, indeed, formed a provisional school for engineers at Metz, to supply the immediate wants of the army on the frontier, and at this school young men were hastily taught the elements of fortification, and were sent direct to the troops, to learn as they best could, the practice of their art. “But such a method,” says the report accompanying the law which founded the school, “does not form engineers in any true sense of the term, and can only be justified by the emergency of the 56 time. The young men should be recalled to the new school to complete their studies.” Indeed no one knew better than Carnot, to use the language of the report, “that patriotism and courage can not always supply the want of knowledge;” and in the critical campaigns of 1793–4, he must often have felt the need of the institution which he was then contributing to set on foot. Such was the immediate motive for the creation of this school. At first, it only included the engineers amongst its pupils. But the artillery were added within a year.

We must not, however, omit to notice its civil character, the combination of which with its military object forms its peculiar feature, and has greatly contributed to its reputation. Amongst its founders were men, who though ardent revolutionists, were thirsting for the restoration of schools and learning, which for a time had been totally extinguished. The chief of these, besides Carnot, were Monge and Fourcroy, Berthollet and Lagrange. Of Carnot and Lagrange, one amongst the first of war ministers, the other one of the greatest of mathematicians, we need not say more. Berthollet, a man of science and practical skill, first suggested the school; Monge, the founder of Descriptive Geometry, a favorite savant of Napoleon though a zealous republican, united to real genius that passion for teaching and for his pupils, which makes the beau idéal of the founder of a school; and Fourcroy was a man of equal practical tact and science, who at the time had great influence with the convention, and was afterwards intrusted by Napoleon with much of the reorganization of education in France.

When the school first started there was scarcely another of any description in the country. For nearly three years the revolution had destroyed every kind of teaching. The attack upon the old schools, in France, as elsewhere, chiefly in the hands of the clergy, had been begun by a famous report of Talleyrand’s, presented to the legislative assembly in 1791, which recommended to suppress all the existing academies within Paris and the provinces, and to replace them by an entirely new system of national education through the country. In this plan a considerable number of military schools were proposed, where boys were to be educated from a very early age. When the violent revolutionists were in power, they adopted the destructive part of Talleyrand’s suggestions without the other. All schools, from the university downwards, were destroyed; the large exhibitions or Bourses, numbering nearly 40,000, were confiscated or plundered by individuals, and even the military schools and those for the public works (which were absolutely 57 necessary for the very roads and the defense of the country) were suppressed or disorganized. The school of engineers at Mézières (an excellent one, where Monge had been a professor,) and that of the artillery at La Fère, were both broken up, whilst the murder of Lavoisier, and the well known saying in respect to it, that “the Republic had no need of chemists,” gave currency to a belief, which Fourcroy expressed in proposing the Polytechnic, “that the late conspirators had formed a deliberate plan to destroy the arts and sciences, and to establish their tyranny on the ruins of human reason.”

Thus it was on the ruin of all the old teaching, that the new institution was erected; a truly revolutionary school, as its founders delighted to call it, using the term as it was then commonly used, as a synonym for all that was excellent. And then for the first time avowing the principle of public competition, its founders, Monge and Fourcroy, began their work with an energy and enthusiasm which they seem to have left as a traditional inheritance to their school. It is curious to see the difficulties which the bankruptcy of the country threw in their way, and the vigor with which, assisted by the summary powers of the republican government, they overcame them. They begged the old Palais Bourbon for their building; were supplied with pictures from the Louvre; the fortunate capture of an English ship gave them some uncut diamonds for their first experiments; presents of military instruments were sent from the arsenals of Havre; and even the hospitals contributed some chemical substances. In fine, having set their school in motion, the government and its professors worked at it with such zeal and effect, that within five months after their project was announced, they had held their first entrance examination, open to the competition of all France, and started with three hundred and seventy-nine pupils.

The account of one of these first pupils, who is among the most distinguished still surviving ornaments of the Polytechnic, will convey a far better idea of the spirit of the young institution than could be given by a more lengthy description. M. Biot described to us vividly the zeal of the earliest teachers, and the thirst for knowledge which, repressed for awhile by the horrors of the period, burst forth with fresh ardor amongst the French youth of the time. Many of them, he said, like himself, had been carried away by the enthusiasm of the revolution, and had entered the army. “My father had sent me,” he added, “to a mercantile house, and indeed I never felt any great vocation to be a soldier, but Que voulez vous? 58 les Prussiens etaient en Champagne.” He joined the army, served two years under Dumouriez, and returned to Paris in the reign of terror, “to see from his lodgings in the Rue St. Honore the very generals who had led us to victory, Custine and Biron, carried by in the carts to the guillotine. “Imagine what it was when we heard that Robespierre was dead, and that we might return safely to study after all this misery, and then to have for our teachers La Place, Lagrange, and Monge. We felt like men brought to life again after suffocation. Lagrange said, modestly, “Let me teach them arithmetic.” Monge was more like our father than our teacher; he would come to us in the evening, and assist us in our work till midnight, and when he explained a difficulty to one of our chefs de brigade, it ran like an electric spark through the party.” The pupils were not then, he told us, as they have since been, shut up in barracks, they were left free, but there was no idleness or dissipation amongst them. They were united in zealous work and in good camaraderie, and any one known as a bad character was avoided. This account may be a little tinged by enthusiastic recollections, but it agreed almost entirely with that of M. de Barante, who bore similar testimony to the early devotion of the pupils, and the unique excellence of the teaching of Monge.

We are not, however, writing a history of this school, and must confine ourselves to such points as directly illustrate its system of teaching and its organization. These may be roughly enumerated in the following order:

1. Its early history is completed by the law of its organization, given it by La Place in his short ministry of the interior. This occurred in the last month of 1799, a memorable era in French history, for it was immediately after the revolution of the 18th of Brumaire, when Napoleon overthrew the Directory and made himself First Consul. One of his earliest acts was to sign the charter of his great civil and military school. This charter or decree deserves some attention, because it is always referred to as the law of the foundation of the school. It determined the composition of the two councils of instruction and improvement, the bodies to which the direction of the school was to be, and still is, intrusted; some of its marked peculiarities in the mode and subject of teaching. It is important to notice each of the two points.

The direction of the school was at first almost entirely in the hands of its professors, who formed what is still called its Council of Instruction. Each of them presided over the school alternately for one month, a plan copied from the revolutionary government of 59 the Convention. In the course of a few years, however, another body was added, which has now the real management of the school. This is called the “Council of Improvement” (Conseil de perfectionnement,) and a part of its business is to see that the studies form a good preparation for those of the more special schools (écoles d’application) for the civil and military service. It consists of eminent men belonging to the various public departments supplied by the school, and some of the professors. It has had, as far as we could judge, an useful influence; first, as a body not liable to be prejudiced in its proposals by the feelings of the school, and yet interested in its welfare and understanding it; secondly, as having shown much skill in the difficult task of making the theoretical teaching of the Polytechnic a good introduction to the practical studies of the public service; thirdly, as being sufficiently influential, from the character of its members, to shield the school from occasional ill-judged interference. It should be added that hardly any year has passed without the Council making a full report on the studies of the school, with particular reference to their bearing on the Special Schools of Application.

The method of scientific teaching has been peculiar from the beginning. It is the most energetic form of what may be called the repetitorial system, a method of teaching almost peculiar to France, and which may be described as a very able combination of professional and tutorial teaching. The object of the répétiteur, or private tutor, is to second every lecture of the professor, to explain and fix it by ocular demonstration, explanations, or examination. This was a peculiarity in the scheme of Monge and Foureroy. The latter said, in the first programme, “Our pupils must not only learn, they must at once carry out their theory. We must distribute them into small rooms, where they shall practice the plans of descriptive geometry, which the professors have just shown them in their public lectures. And in the same manner they must go over in practice (répéteront) in separate laboratories the principal operations of chemistry.” To carry out this system the twenty best pupils, of whom M. Biot was one, were selected as répétiteurs soon after the school had started. Since then the vacancies have always been filled by young but competent men, aspiring themselves to become in turn professors. They form a class of teachers more like the highest style of private tutors in our universities, or what are called in Germany Privat-docenten, than any other body—with this difference, that they do not give their own lectures, but breaking up the professor’s large class into small classes of five and six pupils, examine 60 these in his lecture. The success of this attempt we shall describe hereafter.

2. A change may be noticed which was effected very early by the Council of Improvement—the union of pupils for artillery and engineers in a single school of application. The first report in December 1800, speaks of the identity in extent and character of the studies required for these two services; and in conformity with its recommendation, the law of the 3rd of October 1802, (12th Vendémiaire, XI.) dissolved the separate artillery school at Châlons, and established the united school for both arms in the form which it still retains at Metz.

3. In 1805 a curious change was made, and one very characteristic of the school. The pupils have always been somewhat turbulent, and generally on the side of opposition. In the earliest times they were constantly charged with incivisme, and the aristocracy was said to have “taken refuge within its walls.” In fact, one of its earliest and of its few great literary pupils, M. de Barante, confirmed this statement, adding, as a reason, that the school gave for a while the only good instruction in France. It was in consequence of some of these changes that the pupils who had hitherto lived in their own private houses or lodgings in Paris, were collected in the school building. This “casernement” said to be immediately owing to a burst of anger of Napoleon, naturally tended to give the school a more military character; but it was regarded as an unfortunate change by its chief scientific friends. “Ah! ma pauvre école!” M. Biot told us he had exclaimed, when he saw their knapsacks on their beds. He felt, he said, that the enthusiasm of free study was gone, and that now they would chiefly work by routine and compulsion.

4. The year 1809 may be called the epoch at which the school attained its final character. By this time the functions, both of boards and teachers, were accurately fixed, some alterations in the studies had taken place, and the plan of a final examination had been drawn up, according to which the pupils were to obtain their choice of the branch of the public service they preferred. In fact, the school may be said to have preserved ever since the form it then assumed, under a variety of governments and through various revolutions, in most of which, indeed, its pupils have borne some share; and one of which, the restoration of 1816, was attended with its temporary dissolution.

Thus, during the first years after its foundation the Polytechnic grew and flourished in the general dearth of public teaching, being 61 indeed not merely the only great school, but, until the Institute was founded, the only scientific body in France. Working on its first idea of high professorial lectures, practically applied and explained by répétiteurs, its success in its own purely scientific line was, and has continued to be, astonishing. Out of its sixteen earliest professors, ten still retain an European name. Lagrange, Monge, Fourcroy, La Place, Guyton de Morveau were connected with it. Malus, Hauy, Biot, Poisson, and De Barante, were among its earliest pupils. Arago, Cauchy, Cavaignac, Lamoricière, with many more modern names, came later. All the great engineers and artillerymen of the empire belonged to it, and the long pages in its calendar of distinguished men are the measure of its influence on the civil and military services of France. In fact its pupils, at a time of enormous demands, supplied all the scientific offices of the army, and directed all the chief public works, fortresses, arsenals, the improvement of cities, the great lines of roads, shipbuilding, mining—carried out, in a word, most of the great improvements of Napoleon. He knew the value of his school, “the hen” as he called it, “that laid him golden eggs”—and perhaps its young pupils were not improved by the excessive official patronage bestowed by him upon “the envy of Europe,” “the first school in the world.” It can not, however, be matter of surprise, that its vigor and success should have caused Frenchmen, even those who criticise its influence severely, to regard it with pride as an institution unrivaled for scientific purposes.

It is not necessary to give any detailed account of the later history of the school, but we must remark that disputes have frequently arisen with regard to the best mode of harmonizing its teaching with that of the special schools of application to which it conducts. These disputes have been no doubt increased by the union of a civil and military object in the same school. The scientific teaching desirable for some of the higher civil professions has appeared of doubtful advantage to those destined for the more practical work of war. There has been always a desire on the one side to qualify pure mathematics by application, a strong feeling on the other that mathematical study sharpens the mind most keenly for some of the practical pursuits of after life. We should add, perhaps, that there has been some protest in France (though little heard among the scientific men who have been the chief directors of the school) against the esprit faux, the exclusive pursuit of mathematics to the utter neglect of literature, and the indifference to moral and historical studies. Some one or other of these complaints 62 any one who studies the literature, the pamphlets, and history of the school will find often reproduced in the letters of war ministers, of artillery and engineer officers commanding the school of application at Metz, or of committees from the similar schools for the mines and the roads and bridges. The last of these occasions illustrates the present position of the school.

On the 5th of June 1850, the legislative assembly appointed a mixed commission of military men and civilians, who were charged to revise all the programs of instruction, and to recommend all needful changes in the studies of the pupils, both those preparatory to entrance9 and those actually pursued in the school. The commission was composed as follows:—

A chronic dispute which has gone on from the very first year of the school’s existence, between the exclusive study of abstract mathematics on the one hand, and their early practical application on the other, was brought to a head (though it has scarcely been set at rest) by this commission. All the alterations effected have been in the direction of eliminating a portion of the pure mathematics, and of reducing abstract study to the limits within which it was believed to be most directly applicable to practice. The results, however, are still a subject of vehement dispute, in which most of the old scientific pupils of the Polytechnic, and many of what may be styled its most practical members, the officers of the artillery and engineers, are ranged on the side of “early and deep scientific study versus early practical applications.” It is, indeed, a question which touches the military pupils nearly, since it is in their case particularly that the proposed abstract studies of the Polytechnic might be thought of the most doubtful advantage. We do not try to solve the problem here, though the facts elsewhere stated will afford some materials for judgment. We incline to the opinion 63 of those who think that the ancient genius loci, the traditional teaching of the school, will be too strong for legislative interference, and that, in spite of recent enactments, abstract science and analysis will reign in the lecture-rooms and halls of study of the Polytechnic, now as in the days of Monge.

II. AN OUTLINE OF THE MANAGEMENT AND OF THE ESTABLISHMENT OF THE SCHOOL, ETC.

The Polytechnic, as we have said, is a preparatory and general scientific school; its studies are not exclusively adapted for any one of the departments to which at the close of its course the scholars will find themselves assigned; and on quitting it they have, before entering on the actual discharge of their duties of whatever kind, to pass through a further term of teaching in some one of the schools of application specially devoted to particular professions.

The public services for which it thus gives a general preparation are the following:

To these may be added at any time, by a decree on the part of the government, any other departments, the duties of which appear to require an extensive knowledge of mathematics, physics, or chemistry.

Admission to the school is, and has been since its first commencement in 1794, obtained by competition in a general examination, held yearly, and open to all. Every French youth, between the age of sixteen and twenty, (or if in the army up to the age of twenty-five,) may offer himself as a candidate.

A board of examiners passes through France once every year, and examines all who present themselves, that have complied with the conditions, which are fully detailed in the decree given in the appendix. It commences at Paris.

A list of such of the candidates as are found eligible for admittance to the Polytechnic is drawn up from the proceedings of the board, and submitted to the minister at war; the number of places likely to be vacant has already been determined, and the minister fixes the number of admissions accordingly. The candidates admitted are invariably taken in the order of merit.

The annual charge for board and instruction is 40l. (1,000 fr.,) payable in advance in four installments. In addition there is the cost of outfit, varying from 20l. to 24l. Exhibitions, however, for the discharge of the whole or of one-half of the expense (bourses and demi-bourses,) are awarded by the state in favor of all the successful candidates, whose parents can prove themselves to be too poor to maintain their children in the school. Outfits and half outfits (trousseaux) and demi-trousseaux) are also granted in these cases, on the entrance of the student into the school; and the number of these boursiers and demi-boursiers amounts at the present time to one-third of the whole.

The course of study is completed in two years. On its successful termination which is preceded by a final examination, the students are distributed into the different services, the choice being offered them in the order of their merit, and laid down in the classified list drawn up after the examination. If it so happen that the number of places or the services which can be offered is not sufficient for the number of qualified students, those at the bottom of the list are offered service in the infantry or cavalry, and those who do not enter the public service, are supplied with certificates of having passed successfully through the school. Students who have been admitted into the school from the army, are obliged to re-enter the army.

All others, as has been said, have the right of choosing, according to their position on the list, the service which they prefer, so far, that is, as the number of vacancies in that service will allow; or they may if they please decline to enter the public service at all.

Such is a general outline of the plan and object of the school. We may add that, besides its military staff, it employs no less than thirty-nine professors and teachers; that it has four boards of management, and that ten scientific men unconnected with the school, and amongst the most distinguished in France, conduct its examinations. 65 The magnitude of this establishment for teaching may be estimated by the fact, that the number of pupils rarely exceeds three hundred and fifty, and is often much less.

A fuller enumeration of these bodies will complete our present sketch.

I. The military establishment consists of:—

II. The civil establishment consists of:—

III. The general control or supervision of the school is vested, under the war department, in four great boards of councils, viz.:—

1. A board of administration, composed of the commandant, the second in command, the director of studies, two professors, two captains, and two members of the administrative staff. This board has the superintendence of all the financial business and all the minutiae of the internal administration of the school.

2. A board of discipline, consisting of the second in command, the director, two professors, three captains (of the school,) and two captains of the army, chosen from former pupils. The duty of this board is to decide upon cases of misconduct.

3. A board of instruction, whose members are, the commandant, the second in command, the director, the examiners of students, and the professors; and whose chief duty is to make recommendations relating to ameliorations in the studies, the programmes of admission and of instruction in the school, to—

4. A board of improvement, charged with the general control of the studies, formed of—

III. CONDITIONS AND EXAMINATIONS FOR ADMISSION.

The entrance examination is held yearly in August; the most important conditions for admission to it are always inserted in the Moniteur early in the year, and are—

1st. All candidates must be bachelors of science.

2nd. All candidates (unless they have served in the army) must have been as much as sixteen and not more than twenty years old on the 1st of January preceding.

3rd. Privates and non-commissioned officers of the army must be above twenty and under twenty-five years of age; must have served two years, and have certificates of good conduct.

4th. Candidates who propose to claim pecuniary assistance (a bourse or demi-bourse) must present formal proofs of their need of it.

The subjects of the entrance examination are the following:—

This examination is partly written and partly oral. It is not public, but conducted in the following manner:—

Five examiners are appointed by the minister of war to examine the candidates at Paris, and at the several towns named for the purpose throughout France.

Two of these examiners conduct what may be called a preliminary examination (du premier degré,) and the other three a second examination (du second degré.) The preliminary examiners precede by a few days in their journey through France those who conduct the second examination. The written compositions come before either.

The preliminary examination (du premier degré) is made solely for the purpose of ascertaining whether the candidates possess sufficient knowledge to warrant their being admitted to the second examination; and the second examination serves, in conjunction with the written compositions, for their classification in the order of merit.

Prior to the examination, each candidate is called upon to give in certain written sheets containing calculations, sketches, plans and drawings, executed by him at school during the year, certified and dated by the professor under whom he has studied. Care is taken to ascertain whether these are the pupils’ own work, and any deception in this matter, if discovered, excludes at once from the competition of the school.

This done, the candidates are required to reply in writing to written or printed questions, and to write out French and German exercises; great care being taken to prevent copying. This written examination occupies about twenty-four hours during three and a half separate days, as shown in the following table. It usually takes place in the presence of certain official authorities, the examiners not being present.

Next each candidate is examined orally for three-quarters of an hour, on two successive days, by each of the two examiners separately, and each examiner makes a note of the admissibility or non-admissibility of the candidate.

At the close of this oral examination, the notes relating to the various candidates are compared, and if the examiners differ as to the admissibility of any candidate, he is recalled, further orally examined, and his written exercises carefully referred to, both examiners being present. A final decision is then made.

The preliminary examiners then supply the others with a list of the candidates who are entitled to be admitted to the second oral examination. On this occasion each candidate is separately examined for one hour and a half by each examiner, but care is taken that in all the principal subjects of study the candidate is examined by at least two out of the three examiners.

Each examiner records his opinion of the merits of every candidate in replying, orally and in writing, by awarding him a credit varying between O and 20, the highest number indicating a very superior result.

This scale of merit is employed to express the value of the oral replies, written answers, or drawings. It has the following signification, and appears to be generally in use in the French military schools:—

Considerable latitude is granted to the examiner engaged in deciding upon the amount of credit to be allowed to the student, for the manner in which he replies to the various questions. He is 69 expected to bear in mind the temperament of the candidate, his confidence or timidity, as well as the difficulty of the questions, when judging of the quality of the reply, more value being given for an imperfect answer to a difficult question than for a more perfect reply to an easy one.

The reports of the examiners, together with the various documents belonging to each candidate, are sent from each town to the minister at war, who transmits them to the commandant of the Polytechnic School to make out a classified list.

Very different value of course is attached to the importance of some of the subjects, when compared with others; and the measure of the importance is represented in French examinations by what are termed co-efficients of influence, varying for the several subjects of study and kind of examination. The particular co-efficients of influence for each subject in these written and oral examinations, are as follows:—

In order to make out the above mentioned classified list, the respective credits awarded by the examiners to each candidate are multiplied by the co-efficients representing the weight or importance attached to each subject; and the sum of their products furnishes a numerical result, representing the degree of merit of each candidate.

A comparison of these numerical results is then made, and a general list of all the candidates is arranged in order of merit.

This list, and the whole of the documents from which it has been drawn up, are then submitted to a jury composed of the

It is the special business of this jury carefully to scrutinize the whole of the candidates’ documents, drawings, &c., and they further take care that a failure in any one branch of study is duly noted, as such failure is a sufficient reason for the exclusion of the candidate from the general list.

As soon as this general list has been thoroughly verified, it is submitted to the minister of war, who is empowered to add one-tenth to the number actually required for the public services; and thus it may happen that one-tenth of the pupils may annually be disappointed.

IV. THE SCHOOL BUILDINGS AND THE COURSE AND METHOD OF STUDY.

A brief description of the buildings may be a suitable introduction to an account of the studies that are pursued, and the life that is led in them.

The Polytechnic School stands near the Pantheon, and consists of two main buildings, one for the official rooms and the residence of the commandant and director of studies, the other, and larger one, for the pupils. Detached buildings contain the chemical lecture room and laboratory, the laboratory of natural philosophy, the library, fencing and billiard rooms.

The basement floor of the larger building contains the kitchen and refectories. On the first floor, are the two amphitheaters or great lecture rooms, assigned respectively to the pupils of the two years or divisions, in which the ordinary lectures are given. The rooms are large and well arranged; the seats fixed, the students’ names attached to them. The students are admitted by doors behind the upper tier of seats; at the foot of all is a platform for the professor, with a blackboard facing his audience, and with sufficient room for a pupil to stand and work questions beside him. Room also is provided for one of the captains, inspectors of studies, whose duty it is to be present, for the director of studies, whose occasional presence is expected, and for the assistant teachers or répétiteurs, who in the first year of their appointment are called upon to attend the course upon which they will have to give their subsequent questions and explanations. On this floor are also the museums, or repositories of models, instruments, machines, &c., needed for use in the amphitheaters, or elsewhere. The museum provided for the lecturer on Physics (or Natural Philosophy) appeared in particular to be well supplied.

The whole of the second floor is taken up with what are called the salles d’interrogation, a long series of small cabinets or studies, 71 plainly furnished with six or eight stools and a table, devoted to the interrogations particulières, which will presently be described.

The third floor contains the halls of study, salles d’étude, or studying rooms, in which the greater part of the student’s time during the day is passed—where he studies, draws, keeps his papers and instruments, writes his exercises, and prepares his lectures. These are small chambers, containing eight or, exceptionally, eleven occupants. A double desk runs down the middle from the window to the door, with a little shelf and drawers for each student. There is a blackboard for the common use, and various objects are furnished through the senior student, the sergeant, a selected pupil, more advanced than the rest, who is placed in charge of the room, and is responsible for whatever is handed in for the use of the students. He collects the exercises, and generally gives a great deal of assistance to the less proficient. “When I was sergeant,” said an old pupil, “I was always at the board.” The spirit of camaraderie, said to exist so strongly among the Polytechnic students, displays itself in this particular form very beneficially. Young men of all classes work heartily and zealously together in the salles d’étude, and no feeling of rivalry prevents them from assisting one another. The sergeant does not, however, appear to exercise any authority in the way of keeping discipline.

These chambers for study are arranged on each side of a long corridor which runs through the whole length of the building, those of the juniors being separated from those of the seniors by a central chamber or compartment, the cabinet de service, where the officers charged with the discipline are posted, and from hence pass up and down the corridor, looking in through the glass doors and seeing that no interruption to order takes place.

The fourth story is that of the dormitories, airy rooms, with twelve beds in each. These rooms are arranged as below, along the two sides of a corridor, and divided in the same manner into the senior and junior side. A non-commissioned officer is lodged at each end of the corridor to see that order is kept.

Such is the building into which at the beginning of November the successful candidates from the Lycées and the Ecoles préparatoires are introduced, in age resembling the pupils whom the highest classes of English public schools send annually to the universities, and in number equal perhaps to the new under-graduates at one of the largest colleges at Cambridge. There is not, however, in other points much that is common, least of all in the methods 72 and habits of study we are about to describe. This will be best understood by a summary of a day’s work.

The students are summoned to rise at half-past five, have to answer the roll-call at six, from six to eight are to occupy themselves in study, and at eight they go to breakfast. On any morning except Wednesday, at half-past eight, we should find the whole of the new admission assembled in an amphitheater, permanent seats in which are assigned to them by lot, and thus placed they receive a lecture from a professor, rough notes of which they are expected to take while it goes on. The first half hour of the hour and a half assigned to each lecture is occupied with questions put by the professor relating to the previous lecture. A name is drawn by lot, the student on whom the lot falls is called up to the blackboard at which the professor stands, and is required to work a problem and answer questions. The lecture concluded, the pupils are conducted to the salles d’étude, which have just been described, where they are to study. Here for one hour they devote themselves to completing and writing out in full the notes of the lecture they have just heard. The professor and his assistants, the répétiteurs, are expected to follow and make a circuit through the corridors, to give an opportunity to ask for information on any difficult points in the lecture. A lithographed summary of the substance of the lecture, extending perhaps to two octavo pages, is also furnished to each studying room for the use of its pupils.

The lecture, as we have said, commences at half-past eight o’clock; it lasts an hour and a half; the hour of writing up the notes brings us to eleven. The young men are now relieved by a change of occupation, and employ themselves (still in their places in the rooms of study) at drawing. A certain number, detached from the rest, are sent to the physical and chemical laboratories. The rotation is such as to admit each student once a month to two or three hours’ work at a furnace for chemistry, and once in two months to make experiments in electricity, or other similar subjects. In this way, either at their drawing or in the laboratories, they spend three hours, and at two o’clock go to their dinner in the refectories below, and after dinner are free to amuse themselves in the court-yard, the library, the fencing and the billiard rooms, till five. At five they return to the studying rooms, and for two hours, on Mondays and Fridays, they may employ themselves on any work they please (étude libre;) on Tuesday there is a lecture in French literature, and on Thursday in German; at seven o’clock they commence a lesson, which lasts till nine, in landscape and figure drawing, or they 73 do exercises in French writing or in German; at nine they go down to supper; at half-past nine they have to answer to a roll-call in their bedrooms, and at ten all the lights are put out.

Wednesday is a half-holiday, and the pupils are allowed to leave the school after two o’clock, and be absent till ten at night. The morning is occupied either in study, at the pleasure of the students, or in set exercises till eleven, when there is a lecture of one hour and a half, followed, as usual, by an hour of special study on the subject of the lecture. On Sunday they are allowed to be absent almost the whole day till ten P.M. There is no chapel, and apparently no common religious observance of any kind in the school.

Such is a general sketch of the ordinary employment of the day; a couple of hours of preparatory study before breakfast, a lecture on the differential calculus, on descriptive geometry, on chemistry, or natural philosophy, followed by an hour’s work at notes; scientific drawing till dinner; recreation; and general study, or some lighter lecture in the evening. Were we merely to count the hours, we should find a result of eleven or eleven and a half hours of work for every day but Wednesday, and of seven and a half hours for that day. It is to be presumed, however, that though absolute idleness, sleeping, or reading any book not authorized for purposes of study, is strictly prohibited, and when detected, punished, nevertheless the strain on the attention during the hours of drawing and the lectures of the evening is by no means extreme. Landscape and figure drawing, the lecture in French literature, and probably that in German, may fairly be regarded as something like recreation. Such, at least, was the account given us of the lectures on literary subjects, and it agrees with the indifference to literature which marks the school. Of wholesome out-of-door recreation, there certainly seems to be a considerable want. There is nothing either of the English love of games, or of the skillful athletic gymnastics of the German schools.

The method of teaching is peculiar. The plan by which a vast number of students are collected as auditors of professorial lectures is one pursued in many academical institutions, at the Scotch universities, and in Germany. Large classes attend the lectures in Greek, in Latin, and in mathematics at Glasgow; they listen to the professor’s explanations, take notes, are occasionally questioned, and do all the harder work in their private lodgings. Such a system of course deserves in the fullest sense the epithet of voluntary; a diligent student may make much of it; but there is nothing to compel an idle one to give any attention.

It seems to have been one especial object pursued in the Polytechnic to give to this plan of instruction, so lax in itself, the utmost possible stringency, and to accumulate upon it every attainable subsidiary appliance, every available safeguard against idleness. Questions are expressly put vivâ voce by the professor before his lecture; there is a subsequent hour of study devoted to the subject; there is the opportunity for explanation to individual students; the exaction of notes written out in full form; the professor also gives exercises to the students to write during their hours of general study, which he examines, and marks; general vivâ voce examinations (interrogations générales,) conducted by the professors and répétiteurs, follow the termination of each course of lectures; and lastly, one of the most important and peculiar parts of the method, we have what are called the interrogations particulières. After every five or six lectures in each subject, each student is called up for special questioning by one of the répétiteurs. The rooms in which these continual examinations are held have been described. They occupy one entire story of the building; each holds about six or eight pupils, with the répétiteurs. Every evening, except Wednesday, they are filled with these little classes, and busy with these close and personal questionings. A brief notice, at the utmost of twenty-four hours, is served upon the students who are thus to be called up. Generally, after they have had a certain number of lectures, they may expect that their time is at hand, but the precise hour of the summons can not be counted upon. The scheme is continually varied, and it defies, we are told, the efforts of the ablest young analysts to detect the law which it follows.

It will be seen at once that such a system, where, though nominally professorial, so little is left to the student’s own voluntary action, where the ordinary study and reading, as it is called in our English universities (here such an expression is unknown) is subjected to such unceasing superintendence and surveillance, and to so much careful assistance, requires an immense staff of teachers. At the Polytechnic, for a maximum of 350 pupils, a body of fifteen professors and twenty-four répétiteurs, are employed, all solely in actual instruction, and in no way burdened with any part of the charge of the discipline or the finance, or even with the great yearly examinations for the passage from the first to the second division, and for the entrance to the public services.

With a provision of one instructor to every eight students, it is probable that in England we should avoid any system of large classes, from the fear of the inferior pupils being unable to keep 75 pace with the more advanced. We should have numerous small classes, and should endeavor, above all things, to obtain the advantage of equality of attainment in the pupils composing them.

The French, on the other hand, make it their first object to secure one able principal teacher in each subject, a professor whom they burden with very few lectures. And to meet the educational difficulty thus created, to keep the whole large class of listeners up to the prescribed point, they call in this numerous and busily employed corps of assistants to repeat, to go over the professor’s work afresh, to whip in, as it were, the stragglers and hurry up the loiterers. Certainly, one would think, a difficult task with a class of 170 freshmen in such work as the integral and differential calculus. It is one, however, in which they are aided by a stimulus which evidently acts most powerfully on the students of the Polytechnic School. During the two years of their stay, the prospect of their final admission to the public services can rarely be absent from the thoughts even of the least energetic and forethinking of the young men. Upon their place in the last class list will depend their fortune for life. A high position will secure them not only reputation, but the certainty of lucrative employment; will put it in their power to select which service they please, and in whichever they choose will secure them favorable notice. Let it be remembered that fifty-three of these one hundred and seventy are free scholars, born of parents too poor to pay 40l. a year for their instruction; to whom industry must be at all times a necessity, and industry during their two years at the Polytechnic the best conceivable expenditure, the most certainly remunerative investment of their pains and labor. The place on the final class list is obviously the prize for which this race of two years’ length has to be run. What is it determines that place? Not by any means a final struggle before the winning-post, but steady effort and diligence from first to last throughout the course. For the order of the class list is not solely determined by success in the examination after which it is drawn up, but by the result of previous trials and previous work during the whole stay at the school.

For, during the whole time, every written exercise set by the professor, every drawing, the result of every interrogation particulière by the répétiteurs, and of each general interrogation by the professors and répétiteurs, is carefully marked, and a credit placed according to the name of the student and reserved for his benefit, in the last general account. The marks obtained in the examination which closes the first year of study form a large element 76 in this last calculation. It had been found that the work of the first year was often neglected: the evil was quickly remedied by this expedient. The student, it would seem, must feel that he is gaining or losing in his banking account, so to call it, by every day’s work; every portion of his studies will tell directly for or against him in the final competition, upon which so much depends.

Such is the powerful mechanism by which the French nation forces out of the mass of boys attending their ordinary schools the talent and the science which they need for their civil and military services. The efforts made for admission to this great scientific school of the public services, the struggle for the first places at the exit from it, must be more than enough, it is thought, to establish the habits of hard work, to accumulate the information and attainment, and almost to create the ability which the nation requires for the general good.

We may now follow the student through his course of two years’ study. The first year’s work may be mainly divided into three portions of unequal length; two of them of about four months each (with an additional fortnight of private study and examination,) are mainly given to hard lecturing, whilst the third portion of two months is devoted to private study and to the examinations.

In accordance with this arrangement of the year, the four hardest subjects are thus distributed. Analysis and descriptive geometry, the staple work of the school—its Latin, as M. de Barante called it—come in the first four months; there is then a pause for private study and a general examination in these two subjects (interrogations générales as distinct from the interrogations particulières of the répétiteurs.) This brings us to the middle of March. Analysis and geometry are then laid aside for the rest of the year, and for the next portion of four months the pupils work at mechanics and geodesy, private study and a general examination completing this course also. Important lectures on physics and chemistry run on during both these periods, and are similarly closed by private study and a general examination. The less telling evening classes of French literature and German end at the beginning of June, and landscape and figure drawing only last half the year. It may be observed also, that, as a general rule, there is on each day one, and only one, really difficult lecture. This is immediately preceded and followed by private study, but then comes something lighter, as a relief, such as drawing or work in the laboratories.

The chief feature in the third portion of the year is the complete break in the lectures for general private study (étude libre,) a month 77 or six weeks before the closing examination at the end of the year. The immediate prospect of this prevents any undue relaxing of the work; and it is curious to observe here how private efforts and enforced system are combined together, for even the private efforts are thus systematized and directed. The closing examination of the first year begins on the 1st and ends on the 25th of September.

The total number of lectures in each branch of study, with the dates when they respectively commence and finish, and the period when the general examinations (interrogations générales) take place, are exhibited in the following tables, and we should add that the interval between the close of each course and the commencement of the chief yearly examination is devoted to free study.

TABLE FOR THE SECOND OR LOWER DIVISION, FOLLOWING THE FIRST YEAR’S COURSE OF STUDY.

* Begins on the 1st Sept., and ends on the 25th Sept.

The work of the second year is almost identical in its general plan with that of the first. A continuation of analysis with mechanics in place of descriptive geometry is the work of the first four months, then comes the private study and the interrogations générales, and then again, from the middle of March to the middle of July, work of a more professional character, stereotomy, the art of war and topography, forms the natural completion of the pupil’s studies. Chemistry and physics follow the same course as during the first year, and terminate with the private study and the general examination at the beginning of August. The evening lectures in French literature and German end about the middle of June, and those in figure and landscape drawing at the beginning of May. The last portion is again given to private study and the great Final Examination.

TABLE FOR THE FIRST OR UPPER DIVISION, FOLLOWING THE SECOND YEAR’S COURSE OF STUDY.

* Begins on the 10th Sept. and ends on the 10th Oct.

V. THE EXAMINATIONS, PARTICULARLY THAT OF THE FIRST YEAR AND THE FINAL ONE.

We have now brought the pupil nearly to the end of his career, but must previously say a few words about his examinations, the chief epochs which mark his progress, and the last of which fixes his position almost for life. For this purpose it is necessary to recapitulate briefly what has been said in different places of the whole examinatorial system of the Polytechnic School.

1. All the professors require the students in their studying rooms, to answer questions in writing on the courses as they go through them: a different question is given to each student, and every third question is of such a nature as to involve a numerical example in the reply.

These questions are given in the proportion of one to about every four lectures, and the replies after being examined by the professor or répétiteur, are indorsed with a credit, varying from 0 to 20, and the paper is then given back to the student, to be produced at the close of the year.

2. Credits are assigned to the students for their ordinary manipulations in chemistry and physics, during the first year; and at the close of each year, for their manipulations, in chemistry alone, before the examiners.

3. The répétiteurs examine, (in the interrogations particulières,) every ten or fourteen days, from six to eight students during a sitting of two hours, on the subject of study lectured on since the previous examination of the same kind. All these students must continue present, and at the close the répétiteur assigns to each a 79 previous examination of the same kind. All these students must continue present, and at the close the répétiteur assigns to each a credit entirely dependent on the manner in which each has replied. The professors and captains inspectors are occasionally present at these examinations, which are discontinued at certain periods according to the instructions of the director of studies.

4. At different intervals of time, from a fortnight to a month, as may happen, after the close of the course in each branch of study, general examinations (interrogations générales) are made by the professors and répétiteurs. From four to six students are examined together for at least two hours, and at the conclusion the professor makes known to the director of studies the credit he has granted to each student for the manner in which he has passed his examination.

Such may be called the minor or ordinary examinations. But there is an annual closing examination at the end of each year, which we will now describe. The first year’s annual examination commences on the 1st and ends on the 25th September. It is carried on by special examiners, (a different set from those who conduct the entrance examinations,) and not by the professors. These give to every student a credit between 0 and 20 in each branch of study, according to the manner in which he replies.

The following table shows the co-efficients of influence allowed to the different studies of the first year, subdivided also among the particular classes of examination to which the student has been subjected. The component parts of the co-efficients as well as the co-efficients themselves, slightly vary from year to year, dependent on the number of examinations:—

TABLE I.—FIRST YEAR’S COURSE OF STUDIES: SECOND DIVISION.

At the conclusion of this examination the director of studies prepares 80 a statement for each student, exhibiting the credits he has obtained at each of the preceding examinations in each subject, multiplied by the co-efficient of influence, and the sum of the products represents the numerical account of the student’s credit in each branch of study.

As the process is somewhat intricate, we append the following example, to show the nature of the calculation performed, in order to ascertain the amount of credits due to each student:—

REPORT OF THE CREDITS GAINED IN THE FIRST YEAR’S COURSE OF STUDY BY M. N., STUDENT AT THE POLYTECHNIC SCHOOL.

It is important to remark that any student whose mean credit, given in the eighth column of the preceding table, in any branch of study does not exceed three, or whose general mean credit for the whole of the studies being the arithmetical mean of all the values recorded in the eighth column, and given at the bottom in the example, does not exceed six, is considered to possess an insufficient amount of instruction to warrant his being permitted to pass into the first division for the second year’s course. He is accordingly excluded from the school, unless he has been prevented from pursuing his studies by illness, in which case, when the facts are thoroughly established, he will be allowed a second year’s study in the second division, comprising the first year’s course of study.

We now pass to the second annual or great final examination for admission to the public services, remarking only that in the interrogations générales of the second year the principal subjects of both years are included.

The final examinations for admission into the public service commence about the 10th September, and last about one month. They are conducted by the same examiners who examined at the close of the first year. These are five in number, and appointed by the minister of war. One of these takes analysis; a second, mechanics; a third, descriptive geometry and geodesy; the fourth, physics; and the fifth, chemistry.

The examination in military art and topography is conducted by a captain of engineers specially appointed for the purpose; and in the same manner the examination in German is carried on by a professor, usually a civilian, specially but not permanently appointed.

The questions are oral, and extend over the whole course of study pursued during the two years. Each student is taken separately for one hour and a quarter on different days by each of the five examiners; each examiner examines about eight students daily.

A table, very similar to that already given, is prepared under the superintendence of the Director of studies for every student, to ascertain the numerical amount of his credits in each branch of study, the co-efficients of influences for the particular subject of study and nature of examination being extracted from a table similar to that in page 80, and when these tables have all been completed, a general list of all the students is made out, arranged in the order of their merits.

Formerly, conduct was permitted to exercise some slight influence on their position, but that is no longer the case.

The same regulations exist, as regards the minimum amount of 82 credit that will entitle the students to enter into the public service, as have already been stated above in reference to the passage from the first to the second year’s course of study.

TABLE II. SECOND YEAR’S COURSE OF STUDY: FIRST DIVISION.

From the preceding tables and explanations, it will be apparent that, as the whole of the students for each year are compelled to follow precisely the same course of study, the system of professorial instruction, combined with the constant tutelage and supervision exercised by the répétiteurs, and the examinations (interrogations particulières) of the répétiteurs, at short intervals of time, have for their principal object the keeping alive in the minds of the students the information which has been communicated to them. As a stimulus to continuous and unceasing exertion, it will be seen by an inspection of the tables of the co-efficients of influence, that the manner in which the students acquit themselves from day to day, and from week to week, is made an element, and a very important one, in determining their final position in the list arranged according to merit, exceeding as it does in most instances the influence exerted on their classification by their final examination at the close of each year. This principle thus recognizes not only their knowledge at the end of each year, but also the manner in which they have proved it to the professors and répétiteurs in the course of the year; and with reference to the second year’s study, the final result of the first year’s classification exercises an influence amounting to 83 about one-third of the whole, in the final classification at the end of the second year.

It follows also, that as the examinations at the end of each year are made by examiners, otherwise unconnected with the school, and not by the professors belonging to it, the positions of the students in the classified list is partly dependent on the judgment of the professors with whom they are constantly in communication, and partly on the public examiners, whom they meet only in the examination rooms.10

The examiners of the students are not frequently changed, and practically the same may be said of the examiners for admission.

* When taught in the 2nd year

The students at the head of the list have generally since the wars of the first Empire entered into the civil rather than into the military services, the former being much better remunerated.

The services are usually selected by preference, nearly in the following order:—

Such, at least, is the result of a comparison of the selections made by the students during eight different years.

This preference of the civil to the military services has been the subject of frequent complaints on the part of the military authorities to the minister of war.

No steps have, however, been taken by the French government to prevent the free choice of a profession being granted to the most successful students.

We have now followed the student at the Polytechnic to the end of his school career. He is then to pass to his particular School of Application, in which (as the name implies) he is taught to apply his science to practice. It is difficult to state precisely the amount of such science which the highest pupils may be thought to possess on leaving; the best idea of it will be gained by reference to the programmes of the most important of the lectures. It is also needless to dwell again on the main features of the school—the emulation called forth, the minute method, the great prizes offered for sustained labor. We must, however, make some remarks on these points before concluding our account, so far as they bear on the subject of military education.

VI. GENERAL REMARKS.

NOTE.

In addition to the Schools of Application for Artillery and Engineers at Metz, and of Infantry and Cavalry at St. Cyr, of which a pretty full account will be given, the following Public Services are supplied by the Polytechnic School.

PROGRAMMES OF THE PRINCIPAL COURSES OF INSTRUCTION
OF THE IMPERIAL POLYTECHNIC SCHOOL DURING THE TWO YEARS OF STUDY.

I. ANALYSIS.—FIRST YEAR.

DIFFERENTIAL CALCULUS.

Lessons 1–9. Derivatives and Differentials of Functions of a Single Variable.

Indication of the original problems which led geometers to the discovery of the infinitesimal calculus.

Use of infinitesimals; condition, subject to which, two infinitely small quantities may be substituted for one another. Indication in simple cases of the advantage of such substitution.

On the different orders of infinitely small quantities. Infinitely small quantities of a certain order may be neglected in respect of those of an inferior order. The infinitely small increment of a function is in general of the same order as the corresponding increment of the variable, that is to say, their ratio has a finite limit.

Definitions of the derivative and differential of a function of a single variable. Tangents and normals to plane curves, whose equation in linear or polar coordinates is given.

A function is increasing or decreasing, according as its derivative is positive or negative. If the derivative is zero for all values of the variable, the function is constant. Concavity and convexity of curves; points of inflection.

Principle of function of functions. Differentiation of inverse functions.

Differentials of the sums, products, quotients, and powers of functions, whose differentials are known. General theorem for the differentiation of functions composed of several functions.

Differentials of exponential and logarithmic functions.

Differentials of direct and inverse circular functions.

Differentiation of implicit functions.

Tangents to curves of double curvature. Normal plane.

Differential of the area and arc of a plane curve, in terms of rectilinear and polar co-ordinates.

Differential of the arc of a curve of double curvature.

Applications to the cycloid, the spiral of Archimedes, the logarithmic spiral, the curve whose normal, sub-normal, or tangent, is constant; the curve whose normal passes through a fixed point; the curve whose arc is proportional to the angle which it subtends at a given point.

Derivatives and differentials of different orders of functions of one variable. Notation adopted.

Remarks upon the singular points of plane curves.

Lessons 10–13. Derivatives and Differentials of Functions of Several Variables.

Partial derivatives and differentials of functions of several variables. The order in which two or any number of differentiations is effected does not influence the result.

Total differentials. Symbolical formula for representing the total differential of the n^th order of a function of several independent variables.

Total differentials of different orders of a function; several dependent variables. 92 Case where these variables are linear functions of the independent variables.

The infinitesimal increment of a function of several variables may in general be regarded as a linear function of the increments assigned to the variables. Exceptional cases.

Tangent and normal planes to curved surfaces.

Lessons 14–18. Analytical Applications of the Differential Calculus.

Development of F(x + h,) according to ascending powers of h. Limits within which the remainder is confined on stopping at any assigned power of h.

Development of F(x,) according to powers of x or x - a; a being a quantity arbitrarily assumed. Application to the functions sin(x,) cos x, a^x, (1 + x^m) and log.(1 + x.) Numerical applications. Representation of cos x and sin x by imaginary exponential quantities.

Developments of cos^m x and sin^m x in terms of sines and curves of multiples of x.

Development of F(x + h, y + k,) according to powers of h and k. Development of F(x, y) according to powers of x and y. Expression for the remainder. Theorem on homogeneous functions.

Maxima and minima of functions of a single variable; of functions of several variables, whether independent or connected by given equations. How to discriminate between maxima and minima values in the case of one and two independent variables.

True values of functions, which upon a particular supposition assume one or another of the forms

00, ∞∞, ∞ + 0, 0⁰, 4^∞

Lessons 19–23. Geometrical Applications. Curvature of Plane Curves.

Definition of the curvature of a plane curve at any point. Circle of curvature. Center of curvature. This center is the point where two infinitely near normals meet.

Radius of curvature with rectilinear and polar co-ordinates. Change of the independent variable.

Contacts of different orders of plane curves. Osculating curves of a given kind. Osculating straight line. Osculating circle. It is identical with the circle of curvature.

Application of the method of infinitesimals to the determination of the radius of curvature of certain curves geometrically defined. Ellipse, cycloid, epicycloid, &c.

Evolutes of plane curves. Value of the arc of the evolute. Equation to the involute of a curve. Application to the circle. Evolutes considered as envelops. On envelops in general. Application to caustics.

Lessons 24–27. Geometrical Applications continued. Curvature of Lines of Double Curvature and of Surfaces.

Osculating plane of a curve of double curvature. It may be considered as passing through three points infinitely near to one another, or as drawn through a tangent parallel to the tangent infinitely near to the former. Center and radius of curvature of a curve of double curvature. Osculating circle. Application to the helix.

Radii of curvature of normal s of a surface. Maximum and minimum radii. Relations between these and that of any , normal or oblique.

Use of the indicatrix for the demonstration of the preceding results. Conjugate tangents. Definition of the lines of curvature. Lines of curvature of certain simple surfaces. Surface of revolution. Developable surfaces. Differential equation of lines of curvature in general.

Lesson 28. Cylindrical, Conical, Conoidal surfaces, and Surfaces of Revolution.

Equations of these surfaces in finite terms. Differential equations of the same deduced from their characteristic geometrical properties.

INTEGRAL CALCULUS.

Lessons 29–34. Integration of Functions of a Single Variable.

Object of the integral calculus. There always exists a function which has a given function for its derivative.

Indefinite integrals. Definite integrals. Notation. Integration by separation, by substitution, by parts.

Integration of rational differentials, integer or fractional, in the several cases which may present themselves. Integration of the algebraical differentials, which contain a radical of the second degree of the form √c+bx+ax². Different transformations which render the differential rational. Reduction of the radical to one of the forms

√x²+x², √a²-x², √x²-a².

Integration of the algebraical differentials which contain two radicals of the form

√a+x, √b+x,

or any number of monomials affected with fractional indices. Application to the expressions

Integration of the differentials

F(log x) dx x , F sin^-1x dx √1-x² , x(log xⁿ)dx, x^m e^ax dx, (sin^-1x^m)dx.

Integration of the differentials e^ax sin bxdx and e^ax cos bxdx.

Integration of (sin x^m.)(cos xⁿ) dx.

Integration by series. Application to the expression

Application of integration by series to the development of functions, the development of whose derivatives is given: tan^-1x, sin^-1x, log(1 + x.)

Lessons 35–38. Geometrical Applications.

Quadrature of certain curves. Circle, hyperbola, cycloid, logarithmic spiral, &c.

Rectification of curves by rectilinear or polar co-ordinates. Examples. Numerical applications.

Cubic content of solids of revolution. Quadrature of their surfaces.

Cubic content of solids in general, with rectilinear or polar co-ordinates. Numerical applications.

Quadrature of any curved surfaces expressed by rectangular co-ordinates. Application to the sphere.

Lessons 39–42. Mechanical Applications.

General formula for the determination of the center of gravity of solids, curved or plane surfaces, and arcs of curves. Various applications.

Guldin’s theorem.

Volume of the truncated cylinder.

General formula which represent the components of the attraction of a body upon a material point, upon the supposition that the action upon each element varies inversely as the square of the distance. Attraction of a spherical shell on an external or internal point.

Definition of moments of inertia. How to calculate the moment of inertia of a body in relation to a straight line, when the moment in relation to a parallel straight line is known. How to represent the moments of inertia of a body relative to the straight lines which pass through a given point by means of the radii vectores of an ellipsoid. What is meant by the principal axes of inertia.

Determination of the principal moments of inertia of certain homogeneous bodies, sphere, ellipsoid, prism, &c.

Lessons 43–45. Calculus of Differences.

Calculation of differences of different orders of a function of one variable by means of values of the function corresponding to equidistant values of the variable.

Expression for any one of the values of the function by means of the first, and its differences. Numerical applications; construction of tables representing a function whose differences beyond a certain order may be neglected. Application to the theory of interpolation. Formulæ for approximation by quadratures. Numerical exercises relative to the area of equilateral hyperbola or the calculation of a logarithm.

Lessons 46–48. Revision.

General reflections on the subjects contained in the preceding course.

ANALYSIS.—SECOND YEAR.

CONTINUATION OF THE INTEGRAL CALCULUS.

Lessons 1–2. Definite Integrals.

Differentiation of a definite integral with respect to a parameter in it, which is made to vary. Geometrical demonstration of the formula. Integration under the sign of integration. Application to the determination of certain definite integrals.

Determination of the integrals ∫ sin ax x dx, and ∫ cos bx sin ax x dx, between the limits 0 and x. Remarkable discontinuity which these integrals present.

Determination of ∫e^-x²dx and ∫e^-x²cos mx dx between the limits 0 and ∞.

Lesson 3. Integration of Differentials containing several Variables.

Condition that an expression of the form M dx + N dy in which M and N are given functions of x and y may be an exact differential of two independent variables x and y. When this condition is satisfied, to find the function.

Extension of this theory to the case of three variables.

Lessons 4–6. Integration of Differential Equations of the First Order.

Differential equations of the first order with two variables. Problem in geometry to which these equations correspond. What is meant by their integral. This integral always exists, and its expression contains an arbitrary constant.

Integration of the equation M dx + N dy = 0 when its first member is an exact differential. Whatever the functions M and N may be there always exists a factor µ, such that µ (M dx + N dy) is an exact differential.

Integration of homogeneous equations. Their general integral represents a system of similar curves. The equation (a + b x + c y) dx + (a’ + b’ x + c’ y) dy = c, may be rendered homogeneous. Particular case where the method fails. How the integration may be effected in such case.

Integration of the linear equation of the first order dy dx + P y = Q, where P and Q denote functions of x. Examples.

Remarks on the integration of equations of the first order which contain a higher power than the first of dy dx . Case in which it may be resolved in respect of dy dx . Case in which it may be resolved in respect of x or y.

Integrations of the equation y = x dy dx + φ ( dy dx ). Its general integral represents a system of straight lines. A particular solution represents the envelop of this system.

Solution of various problems in geometry which lead to differential equations of the first order.

Lessons 7–8. Integration of Differential Equations of Orders superior to the First.

The general integral of an equation of the m order contains m arbitrary constants.

(The demonstration is made to depend on the consideration of infinitely small quantities.)

Integration of the equation d^my dx^m = φ (x.)

Integration of the equation d²y dx² = φ (y, dy dx ).

How this is reduced to an equation of the first order. Solution of various problems in geometry which conduct to differential equations of the second order.

Lessons 9–10. On Linear Equations.

When a linear equation of the m^th order contains no term independent of the unknown function and its derivatives, the sum of any number whatever of 96 particular integrals multiplied by arbitrary constants is also an integral. From this the conclusion is drawn that the general integral of this equation is deducible from the knowledge of m particular integrals.

Application to linear equations with constant co-efficients. Their integration is made to depend on the resolution of an algebraical equation. Case where this equation has imaginary roots. Case where it has equal roots. The general integral of a linear equation of any order, which contains a term independent of the function, may be reduced by the aid of quadratures to the integration of the same equation with this term omitted.

Lesson 11. Simultaneous Equations.

General considerations on the integration of simultaneous equations. It may be made to depend on the integrations of a single differential equation. Integration of a system of two simultaneous linear equations of the first order.

Lesson 12. Integrations of Equations by Series.

Development of the unknown function of the variable x according to the powers of x-a. In certain cases only a particular integral is obtained. If the equation is linear, the general integral may be deduced from it by the variation of constants.

Lessons 13–16. Partial Differential Equations.

Elimination of the arbitrary functions which enter into an equation by means of partial derivatives. Integration of an equation of partial differences with two independent variables, in the case where it is linear in respect to the derivatives of the unknown function. The general integral contains an arbitrary function.

Indication of the geometrical problem, of which the partial differential equation expresses analytically the enunciation. Integration of the partial differential equations to cylindrical, conical, conoidal surfaces of revolution. Determination of the arbitrary functions.

Integration of the equation d²u dy² = a² d²u dx². The general integral contains two arbitrary functions. Determination of these functions.

Lessons 17–23. Applications to Mechanics.

Equation to the catenary.

Vertical motion of a heavy particle, taking into account the variation of gravity according to the distance from the center of the earth. Vertical motion of a heavy point in a resisting medium, the resistance being supposed proportional to the square of the velocity.

Motion of a heavy point compelled to remain in a circle or cycloid. Simple pendulum. Indication of the analytical problem to which we are led in investigating the motion of a free point.

Motion of projectiles in a vacuum. Calculation of the longitudinal and transversal vibrations of cords. Longitudinal vibrations of elastic rods. Vibration of gases in cylindical tubes.

Lessons 24–26. Applications to Astronomy.

Calculation of the force which attracts the planets, deduced from Kepler’s laws. Numerical data of the question.

Calculation of the relative motion of two points attracting one another, according to the inverse square of the distance.

Determination of the masses of the earth and of the planets accompanied by satellites. Numerical applications.

Lessons 27–30.

Elements of the calculus of probabilities and social arithmetic.

General principles of the calculus of chances. Simple probability, compound probability, partial probability, total probability. Repeated trials. Enunciation of Bernouilli’s theorem (without proof.)

Mathematical expectation. Applications to various cases, and especially to lotteries.

Tables of population and mortality. Mean life annuities, life interests, assurances, &c.

Lessons 31–32. Revision.

General reflections on the subjects comprised in the course.

II. DESCRIPTIVE GEOMETRY AND STEREOTOMY.

General Arrangements.

The pupils take in the lecture-room notes and sketches upon sheets, which are presented to the professor and the “répétiteurs” at each interrogation. The care with which these notes are taken is determined by “marks,” of which account is taken in arranging the pupils in order of merit.

The plans are made according to programmes, of which the conditions are different for different pupils. The drawings are in general accompanied with decimal scales, expressing a simple ratio to the meter. They carry inscriptions written conformably to the admitted models, and are, when necessary, accompanied with verbal descriptions.

In the graphic exercises of the first part of the course, the principal object is to familiarize the pupils with the different kinds of geometrical drawing, such as elevations and shaded s, oblique projections and various kinds of perspective. The pupils are also accustomed to different constructions useful in stereotomy.

The subjects for graphic exercises in stereotomy are taken from roofs, vaults, and staircases. Skew and oblique arches are the subject of detailed plans.

FIRST YEAR.

DESCRIPTIVE GEOMETRY.—GEOMETRICAL DRAWING.

Lessons 1–3. Revision and Completion of the Subjects of Descriptive Geometry comprised in the Programme for Admission into the School.

Object of geometrical drawing. Methods of projection. Representation of points, lines, planes, cones, cylinders, and surfaces of revolution. Construction of tangent planes to surfaces, of curves, of inter of surfaces, of their tangents and their assymplotes.

Osculating plane of a curve of double curvature. A curve in general cuts its osculating plane.

When the generating line of a cylinder or a cone becomes a tangent to the directrix, the cylinder or cone in general has an edge of regression along this 98 generating line. The osculating plane of the directrix at the point of contact touches the surface along this edge.

Projections of curves of double curvature; infinite branches and their assymplotes, inflections, nodes, cusps, &c.

Change of planes of projection.

Reduction of scale; transposition.

Advantage and employment of curves of error; their irrelevant solutions.

Lessons 4–6. Modes of Representation for the Complete Definition of Objects.

Representation by plans, s, and elevation.

Projection by the method of contours. Representation of a point, a line, and a plane; questions relative to the straight line and plane. Representation of cones and cylinders; tangent planes to these surfaces.

Lessons 7–11. Modes of Representation which are not enough in themselves to define objects completely.

Isometrical and other kinds of perspective.

Oblique projections.

Conical perspective: vanishing points; scales of perspective; method of squares; perspective of curved lines; diverse applications. Choice of the point of sight. Rules for putting an elevation in perspective. Rule for determining the point of sight of a given picture, and for passing from the perspective to the plan as far as that is possible. Perspective of reflected images. Notions on panoramas.

Lessons 12–13. Representations with Shadows.

General observations on envelops and characteristics.

A developable surface is the envelop of the position of a movable plane; it is composed of two sheets which meet. It may be considered as generated by a straight line, which moves so as to remain always a tangent to a fixed curve.

Theory of shade and shadow, of the penumbra, of the brilliant point, of curves of equal intensity, of bright and dark edges.

Atmospheric light: direction of the principal atmospheric ray. Notions on the degradation of tints; construction of curves of equal tint.

Influence of light reflected by neighboring bodies.

Received convention in geometrical drawing on the direction of the luminous ray, &c.

Perspective of shadows.

Lessons 14–15. Construction of Lines of Shadows and of Perspective of Surfaces.

Use of circumscribed cones and cylinders, and of the normal parallel to a given straight line.

General method of construction of lines of shadow and of perspective of surfaces by plane s and auxiliary cylindrical or conical surfaces.

Construction of lines of shadow and perspective of a surface of revolution.

The curve of contact of a cone circumscribed about a surface of the second degree is a plane curve. Its plane is parallel to the diametral plane, conjugate to the diameter passing through the summit of the cone. The curve of contact of a cylinder circumscribed about a surface of the second degree is a plane 99 curve, and situated in the diametral plane conjugate to the diameter parallel to the axis of the cylinder.

The plane parallel s of a surface of the second degree are similar curves. The locus of their centers is the diameter conjugate to that one of the secant planes which passes through the center of the surface.

General study of surfaces with reference to the geometrical constructions to which their use gives rise.

Lesson 16. Complementary Notions on Developable Surfaces.

Development of a developable surface; construction of transformed curves and their tangents. Developable surface; an envelop of the osculating planes of a curve. The osculating plane of a curve at a given point may be constructed by considering it as the edge of regression of a developable surface; this construction presents some uncertainty in practice. Notions on the helix and the developable helicoid.

Approximate development of a segment of an undevelopable surface.

Lessons 17–18. Hyperbolic Paraboloid.

Double mode of generation of the paraboloid by straight lines; plane-directers; tangent planes, vertex, axis, principal planes; representation of this surface. Construction of the tangent plane parallel to a given plane. Construction of plane s and of curves of contact, of cones, and circumscribed cylinders.

Scalene paraboloid. Isosceles paraboloid.

Identity of the paraboloid with one of the five surfaces of the second degree studied in analytical geometry.

Re-statement without demonstration of the properties of this surface found by analysis, principally as regards its generation by the conic s.

Lessons 19–20. General Properties of Warped or Ruled Surfaces.

Principal modes of generation of warped surfaces. When two warped surfaces touch in three points of a common generatrix, they touch each other in every point of this straight line. Every plane passing through a generatrix touches the surface at one point in this line. The tangent plane at infinity is the plane-directer to all the paraboloids of “raccordement.”

Construction of the tangent planes and curves of contact of circumscribed cones and cylinders. When two infinitely near generatrices of a warped surface are in the same plane, all the curves of contact of the circumscribed cones and cylinders pass through their point of concourse.

The normals to a warped surface along a generatrix form an isosceles paraboloid. The name of central point of a generatrix is given to the point where it is met by the straight line upon which is measured its shortest distance from the adjoining generatrix. The locus of these points forms the line of striction of the surface. The vertex of the normal paraboloid along a generating line is situated at the central point. If the point of contact of a plane touching a warped surface moves along a generatrix, beginning from the central point, the tangent of the angle which the tangent plane makes with its primitive position is proportional to the length described by the point of contact. The tangent 100 plane at the central point is perpendicular to the tangent plane at infinity upon the same generatrix. Construction of the line of striction by aid of this property.

Lessons 21–22. Ruled Surfaces with plane-divecters Conoids.

The plane-directer of the surface is also so to all the paraboloids of “raccordement.” Construction of the tangent planes and curves of contact of the circumscribed cones and cylinders.

The line of striction of the surface is its curve of contact with a circumscribed cylinder perpendicular to the directer-plane. Determination of the nature of the plane s.

The lines of striction of the scalene paraboloid are parabolas; those of the isosceles paraboloid are straight lines.

Construction of the tangent plane parallel to a given plane.

Conoid: discussion of the curves of contact of the circumscribed cones and cylinders.

Right conoid. Conoid whose inter with a torus of the same height, whose axis is its rectilinear directrix, has for its projection upon the directer-plane two arcs of Archimedes’ spiral. Construction of the tangents to this curve of inter.

Lessons 23–25. Ruled Surfaces which have not a Directer-Plane. Hyperboloid. Surface of the “biais passe.”

Directer-cone: its advantages for constructing the tangent plane parallel to a given plane, and for determining the nature of the plane s. The tangent planes to the points of the surface, situated at infinity, are respectively parallel to the tangent plane of the directer-cone. Developable surface which is the envelope of these tangent planes at infinity. Construction of a paraboloid of raccordement to a ruled surface defined by two directrices and a directrix cone.

Hyperboloid; double mode of generation by straight lines; center; assymptotic cone.

Scalene hyperboloid; hyperboloid of revolution. Identity of the hyperboloid with one of the five surfaces of the second degree studied in analytical geometry.

Re-statement without demonstration of the properties of this surface, found by analysis, principally as to what regards the axis, the vertices, the principal planes, and the generation by conic s.

Hyperboloid of raccordement to a ruled surface along a generatrix; all their centers are in the same plane. Transformation of a hyperboloid of raccordement.

Surface of the biais passé. Construction of a hyperboloid of raccordement; its transformation into a paraboloid.

Construction of the tangent plane at a given point.

Lessons 26–28. Curvature of Surfaces. Lines of Curvature.

Re-statement without proof of the formula of Euler given in the course of analysis.

There exists an infinity of surfaces of the second degree, which at one of their vertices osculate any surface whatever at a given point.

In the tangent plane, at a point of a surface, there exists a conic , whose diameters are proportional to the square roots of the radii of curvature of the normal s to which they are tangents. This curve is called the indicatrix. It is defined in form and position, but not in magnitude. The normal s tangential to the axes of the indicatrix are called the principal s.

The indicatrix an ellipse; convex surfaces; umbilici; line of spherical curvatures.

The indicatrix a hyperbola; surfaces with opposite curvatures.

The assymplotes of the indicatrix have a contact of the second order with the surface, and of the first order with the of the surface by its tangent plane.

A ruled surface has contrary curvatures at every point. The second assymplotes of the indicatrices of all the points of the same generatrix form a hyperboloid, if the surface has not directer-plane,—a paraboloid, if it have one.

Curvature of developable surfaces.

There exists upon every surface two systems of orthogonal lines, such that every straight line subject to move by gliding over either of them, and remaining normal to the surface, will engender a developable surface. These lines are called lines of curvature.

The two lines of curvature which cross at a point, are tangents to the principal s of the surface at that point.

Remarks upon the lines of curvature of developable surfaces, and surfaces of revolution.

Determination of the radii of curvature, and assymplotes of the indicatrix at a point of a surface of revolution.

Lessons 29–30. Division of Curves of Apparent Contour, and of Separation of Light and Shadow into Real and Virtual Parts.

When a cone is circumscribed about a surface, at any point whatever of the curve of contact, the tangent to this curve and the generatrix of the cone are parallel to two conjugate diameters of the indicatrix.

Surfaces, as they are considered in shadows, envelop opaque bodies, and the curve of contact of a circumscribed cone, only forms a separation of light and shadow, for a luminous point at the summit of the cone, when the generatrices of this cone are exterior. This line is thus sometimes real and sometimes virtual.

Upon a convex surface, the curve of separation of light and shade is either all real or all virtual. Upon a surface with contrary curvatures, this curve presents generally a succession of real and virtual parts: the curve of shadow cast from the surface upon itself presents a like succession. These curves meet tangentially, and the transition from the real to the virtual parts upon one and the other, take place at their points of contact in such a way that the real part of the curve of shadow continues the real part of the curve of separation of light and shade. The circumscribed cones have edges of regression along the generatrices, which correspond to the points of transition.

The lines of visible contour present analogous circumstances.

General method of determining the position of the transition points. Special method for a surface of revolution.

Lessons 31–34. Ruled Helicoidal Surfaces.

Surface of the thread of the triangular screw; generation, representation, s by planes and conical cylinders.

Construction of the tangent plane at a given point, or parallel to a given plane. The axis is the line of striction.

Construction of lines of shadow and perspective: their infinite branches, their assymplotes. Determination of the osculating hyperboloid along a generatrix.

Representation and shading of the screw with a triangular thread and its nut.

Surface of the thread of the square screw; generation, s by planes and conical cylinders; tangent planes; curve of contact of a circumscribed cone.

The curve of contact of a circumscribed cylinder is a helix whose step is half that of the surface. Determination of the osculating paraboloid. At any point whatever of the surface, the absolute lengths of the radii of curvature are equal.

Representation and shading of the screw with a square thread, and of its nut.

Observations on the general ruled helicoidal surface, and on the surface of intrados of the winding staircase.

Lesson 35. Different Helicoidal Surfaces.

Saint-Giles screw, worm-shaped screw and helicoidal surfaces to any generatrix. Every tangent to the meridian generatrix describes a screw surface with triangular thread, which is circumscribed about the surface, along a helix, and may be used to resolve the problems of tangent planes, circumscribed cylinders, &c.

Helicoid of the open screw, its generation, tangent planes.

Lessons 36–37. Topographical Surfaces.

Approximate representation of a surface by the figured horizontal projections of a series of equidistant horizontal s. This method of representation is especially adapted to topographical surfaces, that is to say, surfaces which a vertical line can only meet in one point.

Lines of greatest slope. Trace of a line of equal slope between two given points.

Inter of a plane and a surface, of two surfaces, of a straight line and a surface.

Tangent planes, cones, and cylinders circumscribed about topographical surfaces.

Use of a topographical surface to replace a table of double-entry when the function of two variables, which it represents, is continuous. It is often possible, by a suitable anamorphosis, to make an advantageous transformation in the curves of level.

Lesson 38. Revision.

Review of the different methods of geometrical drawing. Advantages and disadvantages of each.

Comparison of the different kinds of surfaces, résumé of their general properties.

Object, method, and spirit of descriptive geometry.

SECOND YEAR.

STEREOTOMY.—WOOD-WORK.

Lessons 1–4. Generalities.

Notions on the mode of action of forces in carpentry. Resistance of a piece of wood to a longitudinal effort and to a transversal effort. Distinction between resistance to flexure and resistance to rupture. Beams.

Advantages of the triangular system, St. Andrew’s cross.

Lessons 5–8. Roofs.

Ordinary composition of roofs.

Distribution of pressures in the different parts of a girded roof.

Design of the different parts of roofs, &c., &c.

Lessons 9–10. Staircases.

MASONRY.

Lessons 11–12. Generalities.

Notions on the settlement of vaulted roofs. Principal forms of vaults, en berceau, &c., &c.

Distribution of the pressures, &c.

Division of the intrados. Nature of the surfaces at the joints, &c., &c.

Lessons 13–15. Berceaux and descentes.

Lessons 16–22. Skew Arches.

Study of the general problem of skew arches.

First solution. Straight arches en échelon.

Second solution: Orthogonal appareil. True and principal properties of the orthogonal trajectories of the parallel s of an elliptical or circular cylinder. Right conoid, having for directrices the axis of the circular cylinder and an orthogonal trajectory. The inter of this conoid by a cylinder about the same axis is an orthogonal trajectory for a series of parallel s.

Third solution: helicoidal. Determination of the angular elevation at which the surfaces of the beds become normal to the head planes; construction in the orthogonal and helicoidal appareil of the curves of junction upon the heads, and the angles which they form with the curves of intrados. Cutting of the stones in these different constructions. Broken helicoidal appareil, for very long skew arches.

Helicoidal trompes at the angles of straight arches; voussures or widenings, which it is necessary to substitute near the heads at the intrados of an arch with a considerable skew; case where the skew is not the same for the two heads. Orthogonal trajectories of the converging s of a cylinder.

Lessons 23–25. Conical Intrados—Intrados of Revolution.

Skew trompe in the angle. Suggestions on the general problem of conical skew vaulted roofs.

Spherical domes, &c.

Lessons 26–27. Intrados, a Ruled Surface.

Winding staircases, &c., &c.

Lesson 28. Helicodial Intrados.

Staircase on the Saint-Giles screw.

Lessons 29–31. Composite Vaulted Roofs.

Various descriptions of vaults.

Suggestions on vaulted roofs with polygonal edges and with ogival edges.

Lesson 32. Revision.

Spirit and method of stereotomy.

Degree of exactness necessary. Approximate solutions. Case where it is proper to employ calculation in aid of graphical constructions.

Review and comparison of different appareils.

MECHANICS AND MACHINES.

GENERAL ARRANGEMENTS.

The pupils execute during the two years of study:—

1. Various drawings or plans of models in relief representing the essential and internal organs of machines, such as articulations of connecting rods, winch-handles and fly-wheels, grease-boxes, eccentrics worked by cams or circles giving motion to rods; the play of slides, &c.; cylinders of steam-engines, condenser, pistons, and various suckers; Archimedes’ screw, and other parts of machines.

The sketches of the plan drawings are traced by hand and figured. The drawings in their finished state are washed and colored according to the table of conventional tints; they all carry a scale suitably divided.

2. A drawing of wheel-work by the method of development, and tracing the curves of teeth by arcs of circles from which they are developed. This drawing represents, of the natural size, or on any other scale of size considered suitable to show the nature of the partial actions only, a small number of teeth either in development or projection; the entire wheel-work is represented by the usual method of projection, where in drawings on a small scale the teeth are replaced by truncated pyramids with a trapezoidal base.

3. Finally, numerical exercises concerning the loss of work due to the proejudicial resistances in various machines, the gauging of holes, orifices, &c.

Models in relief or drawings on a large scale, of the machines or elements of the machines mentioned in the course, assist in explaining the lessons. They are brought back, as often as found necessary, under the eyes of the students. When possible, lithographic sketches of the machines, or the elements of the machines, which ought to enter into the course, are distributed among the pupils.

The pupils, divided into s, pay their first visit to the engine factories towards the end of their first year of study; they make one or more additional visits at the end of the second year.

FIRST YEAR.

PART I. KINEMATICS.—PRELIMINARY ELEMENTARY MOVEMENTS OF INVARIABLE POINTS AND SYSTEMS.

Lessons 1–2.

Object of kinematics, under the geometrical and experimental point of view. Its principal divisions.

Re-statement of the notions relative to the motion of a point, its geometrical representation, and more especially the determination of its velocity.

Simultaneous Velocities of a Point and the Increments of its Velocities.

Ratio of the elementary displacement and the velocity of a point to the displacement, and velocity of its projection upon a straight line or plane. Use of infinitesimals to determine these ratios. Example:—Oscillatory motion of the projection upon a fixed axis of a point moving uniformly upon the circumference of a circle.

Analogous considerations for polar co-ordinates. Relations of the velocity of a point, of its velocity of revolution and its angular velocity about a fixed pole; of its velocity in the direction of the radius vector; of the velocity of increase of the area which this radius describes.

Simple Motions of Solids, or Rigid Systems.

1. Motion of rectilinear or curvilinear translation; simultaneous displacements, and velocities of its different points.

2. Motion of rotation about a fixed axis; relation of the velocities of different points to the angular velocity.

Geometrical notions and theorems relative to the instantaneous center of rotation of a body of invariable figure and movable in one plane, or to the instantaneous axis of rotation of a rigid system situated in space, and movable parallel to a fixed plane. Relation of the velocities of different points to their common angular velocity. Use of the instantaneous center of rotation for tracing tangents; examples—and amongst others—that of the plane curve described by a point in a straight line of given length, whose extremities slide upon two fixed lines. Rolling of a curve upon another fixed curve in a plane. Descartes’ theorems upon the inter of the normals at the successive points of contact: cycloids, epicycloids, involutes, and evolutes. Extension of the preceding motions to the instantaneous axis of rotation of a rigid system movable about a fixed point.

COMPOSITION OF MOTIONS.

Lessons 3–6. Composition of the Velocities of a Point.

Polygon of velocities. Example of movements observed relatively to the earth. Particular cases; composition of velocities taken along three axes; composition of the velocity of a point round a fixed pole, and its velocity along the radius vector. Method of Roberval for tracing tangents.

Composition of the Simple Motions of a Solid System.

Composition of any number of translatory displacements of a solid. Composition of two rotations about two intersecting axes. Composition of any number of rotations about axes cutting one another at the same point; parallelopiped and polygon of rotations. Composition of two simultaneous rotations about parallel axes; case where the rotations are equal and of opposite kinds. Decomposition of a rotation about an axis into an equal rotation about any axis whatever parallel to the first, and a translation perpendicular to the direction of this axis. Direct and geometrical decomposition of the most general motions of a body into a rotation about, and a translation along, an axis called the instantaneous axis. Composition of any two motions whatever. Every movement of an invariable system is at each instant of time decomposable into three movements of rotation, and three movements of translation with respect to three axes, which are neither parallel nor lying in the same plane, but otherwise arbitrarily chosen.

Relative or Apparent Motions.

Relative motion of two points whose absolute motions are given graphically à priori. Trajectory of the relative motions, relative velocities, and displacements upon curves or upon the direction of the mutual distance of the two points; use of the parallelogram to determine its amount. Relative motion of a point in motion in respect of a body turning about a fixed axis; relative motion of two bodies which turn about parallel or converging axes, and in general of two rigid bodies or systems impelled by any motions whatever. How this problem is immediately reduced to that of the composition of given motions.

The most general continued motion of an invariable figure in a plane is an epicycloidal motion, in which the instantaneous center describes a curve fixed in relation to absolute space, and traces relatively to the proposed figure a movable curve, which is rigidly connected with that figure and draws it along with it in its motion of rolling upon the other fixed curve. Case of space or spherical figures.

ON THE ACCELERATED MOTION OF A POINT.

Lessons 7–9. Accelerated Rectilinear Motion.

Re-statement of the motions acquired relatively to the acceleration in the variable rectilinear motion of a point. Brief indication of the solution of six problems arising out of the investigation of the laws of the motion in terms of the space, time, velocity, and accelerating force. For the most part these solutions may be brought to depend on exact or approximate quadratures. Numerical exercises.

Accelerated Curvilinear Motions.

Re-statement of the notions acquired relative to the composition of accelerating forces; the resulting acceleration, the normal and tangential acceleration animating a point in motion on a curve. The total acceleration of a point upon an axis or plane is the projection upon this axis or plane of the acceleration of the moving body in space. In uniform curvilinear motion the total or resultant acceleration becomes normal to the curve. Particular case of the circle; value of the normal acceleration in terms of the velocity of revolution or the angular 107 velocity of the radius vector. Case of any curve whatever; geometrical expression of the total or resultant acceleration.

Accelerated Compound and Relative Motions.

Geometrical investigation of the simple and compound accelerations arising out of the hypothesis in which the motion of any system of points whatever is referred to another system of invariable form, but also in motion. Geometrical and elementary explanations of the results obtained by means of the transformation of co-ordinates.

Examples or Exercises chosen from among the following Questions:—

Projection of circular and uniform motion upon a fixed straight line or plane; motion of a circle which rolls uniformly on a straight line; comparison of the motions of the planets relatively to each other, treating them as circular and uniform: comparison of the accelerating force on the moon with that of bodies which fall to the earth.

GEOMETRICAL THEORY AND APPLICATION OF MECHANISMS OR CONTRIVANCES FOR THE TRANSFORMATION OF MOTION.

Lessons 10–19.

Succinct notions on the classification of elementary motions and organs for transmission of motion in machines after Monge and Hachette, Lanz and Bétancourt.

The most essential details upon this subject are set forth in the following order, and made clear by outline drawings previously distributed among the pupils.

Organs fitted to regulate the direction of the circular or rectilinear motion of certain pieces.

Axle; trunnions, gudgeons; pivots and bearings; couplings of axes; adjustment of wheels and of their arms. Joints with hinges, &c.; sheaves and pulleys; chains, ropes, and straps; means of securing them to the necks. Grooves and tongue-pieces. Eyelet-holes sliding along rectilinear or curvilinear rods. Advantages and disadvantages of these different systems of guides under the point of view of accuracy.

Rapid indication of some of their applications to drawbridges and to the movable frames or wagons of saw-works and railways.

Transmission at a Distance of Rectilinear Motion in a determinate Direction and Ratio.

Inclined plane or wedge guiding a vertical rod. Wedge applied to presses. Rods, winch-handles, &c. Disposition of drums or pulleys in the same plane or in different planes; geometrical problem on this subject. Fixed and movable pulleys. Blocks to pulleys. Simple and differential wheel and axle moved by cords. Transmission through a liquid. Ratios of velocities in these different organs.

Direct Transformation of circular progressive motion into progressive and intermittent rectilinear motion.

Rod conducted between guides: 1^o, by the simple contact of a wheel; 2^o, by cross-straps or chains; 3^o, by a projecting cam; 4^o, by means of a helicoidal 108 groove set upon the cylindrical axis of the wheel. To-and-fro movement, and heart-shaped or continuous cam, waves, and eccentrics. Simple screw and nut. Left and right handed screws; differential screw of Prony, called the micrometric screw. Ratio of the velocities in these different organs.

The example of the cam and pile-driver will be particularly insisted upon; 1^o, in the case where this cam and the extremity of the rod have any continuous form given by a simple geometrical drawing; 2^o, in the case where this form is defined geometrically by the condition, that the velocity is to be transmitted in an invariable ratio, as takes place for cams in the form of epicycloids or involutes of circles.

Transformation of a circular progressive motion into another similar to the first.

1^o, by contact of cylinders or cones, the two axes being situated in the same plane; 2^o, by straps, cords, or endless chains, the axes being in the same situation; 3^o, by cams, teeth, and grooves, at very slight intervals; 4^o, by the Dutch or universal joint. Case, where the axes are not situated in the same plane; use of an intermediate axis with beveled wheels or a train of pulleys; idea of White or Hooke’s joint in its improved form. Endless screw specially employed in the case of two axes at right angles to one another. Combinations or groupings of wheels. Idea of differential wheels. Relations of velocities in the most important of these systems of transmission.

Transformation of circular progressive Motion into rectilinear or alternating circular motion.

Ordinary circular eccentric. Eccentrics with closed waves or cams. Examples and graphical exercises in the class-rooms relative to the alternate action of the traveling frames of saw-mills, of the slides or entrance valves of steam-engines. Cams for working hammers and bellows.

Transformation of alternating circular motion into alternating rectilinear motion, or into intermittent and progressive circular motion.

Pump rods with or without circular sectors, &c. Examples taken from large exhausting pumps, fire-engines, and common pumps. Suggestions as to the best arrangement of the parts. Lagarousse’s lever, &c. Application of the principle relative to the instantaneous center of rotation to give the relations of the velocities in certain simple cases.

Transformation of alternating circular or rectilinear motions into progressive circular motion.

The knife-grinder’s treadle. System of great machines worked with connecting rods, fly-wheel, &c. Watt’s parallelogram, and the simplest modifications of it for steamboats, for instance. The most favorable proportions for avoiding the deviation of piston-rods. Simplification of parts in the modern steam-engines of Maudsley, Cavé, &c. Variable ratios of the velocities.

Of organs for effecting a sudden change of motion.

Suspendors or moderators, &c. Dead wheels and pulleys, &c. Mechanisms for stretching cords or straps, and make them change pulleys during the motion. Brakes to windmills, carriages, &c., &c. Case where the axes are rendered 109 movable. Means for changing the directions and velocity of the motions. Coupled and alternate pulleys; alternate cones; castors moving by friction and rotation upon a plate or turning-cone; eccentric and orrery wheels. Means of changing the motion suddenly and by intervals; wheels with a detent pile-drivers; Dobo’s escapement for diminishing the shock, &c.

Geometrical Drawing of Wheel-work.

General condition which the teeth of toothed wheels must satisfy. Consequence resulting from this for the determination of the form of the teeth of one of two wheels, when the form of the teeth of the other wheel is given.

Cylindrical action of toothed wheels or toothed wheels with parallel axes. External engagement of the teeth; internal engagement. Particular systems of toothed wheels; lantern wheels, flange wheels, involutes of circles. Reciprocity of action; case where the action can not be rendered reciprocal. Pothook action. Details as to the form and dimensions given in practice to the teeth and the spaces which separate them.

Conical action of toothed wheels, or toothed wheels with converging axes. Practical approximate method of reducing the construction of a conical to that of a cylindrical engagement of toothed wheels.

Means of observation and apparatus proper for discovering experimentally the law of any given movement.

Simple methods practiced by Galileo and Coulomb in their experiments relative to the inclined plane and the motion of bodies sliding down it. Various means of observing and discovering the law of the translatory and rotatory motion of a body according as the motion is slow or rapid. Determination of the angular velocity, &c. The counter in machines. Apparatus of Mattei and Grobert for assigning the initial velocity of projectiles (musket balls.) Colonel Beaufoy’s pendulum apparatus. Chronometrical apparatus for continuous indications by means of a pencil. Eytelwein’s apparatus with bands, and its simplest modifications. Apparatus with cylinders or revolving disks. Use of the tuning-fork for measuring with precision very small fractions of time.

(The principal sorts of the apparatus above described are made to act under the eyes of the pupils.)

PART II.—EQUILIBRIUM OF FORCES APPLIED TO MATERIAL SYSTEMS.

Lesson 21.

Résumé of the notions acquired upon the subject of forces, and their effects on material points.

Principle of inertia, notion of force, of its direction, of its intensity. Principle of the equality of action and reaction. What is meant by the force of inertia? Principle of the independence and composition of the effects of forces. Forces proportional to the acceleration which they produce on the same body. Composition of forces. Relation between the accelerating force, the pressure, and the mass. Definition of the work done by a force. The work done by the resultant is equal to the sum of the works done by the components. Moment of a force in relation to an axis deduced from the consideration of the work of the force applied to a point turning about a fixed line. The moment of the 110 resultant of several forces applied to a point is equal to the sum of the moments of the components. Corresponding propositions of geometry.

Lessons 22–25.

Succinct Notions upon the Constitution of Solid Bodies.

Every body or system of bodies may be regarded as a combination of material points isolated or at a distance, subject to equal and opposite mutual actions. Interior and exterior forces. Example of two molecules subject to their reciprocal actions alternately, attractive and repulsive, when the forces applied draw them out of their position of natural equilibrium. Different degrees of natural solidity, stability, or elasticity; they can only be appreciated by experience.

Equilibrium of any Systems whatever of Material Points.

General theorem of the virtual work of forces applied to any system whatever of material points. It is applicable to every finite portion of the system, provided regard be had to the actions exercised by the molecules exterior to the part under consideration. Determination of the sum of the virtual works of the equal and reciprocal actions of two material points. Demonstration of the six general equations of equilibrium of any system whatever. They comprise implicitly every equation deduced from a virtual movement compatible with the pre-supposed solidification of the system.

Theorem on the virtual work in the case of systems where one supposes ideal connections, such as the invariability of the distance of certain points of the system from one another, and the condition that certain of them are to remain upon curves either fixed or moving without friction.

Equilibrium of Solid Bodies.

The six general equations of equilibrium are sufficient as conditions of the equilibrium of a solid body. Theory of moments and couples.

APPLICATIONS.

Lessons 26–29. Equilibrium of Heavy Systems.

Recapitulation of some indispensable notions for the experimental determination of the center of gravity of solids when the law of their densities is unknown. Re-statement of the theorem relative to the work done by gravity upon a system of bodies connected or otherwise. In machines supposed without friction submitted, with the exception of their supports, to the action of gravity alone, the positions of stable or unstable equilibrium correspond to the highest or lowest points of the curve which would be described by the center of gravity of the system when made to move. Influence of defect of centering in its wheels, upon the equilibrium of a machine. Case where the center of gravity always remaining at the same height the equilibrium is neutral. Examples relative to the most simple drawbridges, &c.

Equilibrium of Jointed Systems.

Equilibrium of the funicular polygon deduced from direct geometrical considerations: Varignon’s theorem giving the law of the tensions by another 111 polygon whose sides are parallel and proportional to the forces acting upon the vertices of the funicular polygon. Case of suspension bridges; investigation of the curve which defines the boundary of the suspension chain; tensions at the extremities.

Equilibrium of systems of jointed rigid bodies without friction. Determination of the pressure upon the supports and the mutual actions at the joints.

Equilibrium and stability of solid bodies submitted to the action of stretching or compressing forces.

Permanent resistance and limiting resistance of prisms to longitudinal extension and compression. Equilibrium and stability of a heavy solid placed upon a horizontal plane and submitted to the action of forces which tend to overset it. Resultant pressure and mean pressure; hypothetical distribution of the elements of the pressure on the base of support. Conditions of stability, regard being had to the limit of resistance of solid materials, co-efficient of stability deduced from it.

PART III.—ON THE WORK DONE BY FORCES IN MACHINES.

Lessons 30–39. General Notions.

Principle of work in the motion of a material point. Extension of this principle to the case of any material system whatever in motion. Considerations relative to mechanical work in various operations, such as the lifting of weights, sawing, planing, &c. It is the true measure of the productive activity of forces in industrial works. It may always be calculated either rigorously or approximately when the mathematical or experimental law which connects the force with the spaces described is given. Uniform work, periodical work, mean work, for the unit of time. Horse-power unit. Examples and various exercises, such as the calculation of the work corresponding to the elasticity of gases on the hypothesis of Mariotte’s law, the elongation of a metallic prism, &c.

Dynamometrical Apparatus.

Dynamometer of traction by a band or rotating disc or register. Dynamometer of rotation with simple spring, with band or register. Dynamometer of rotation with multiple springs and with register for the axles of powerful machines. Improved indicator of Watt.

(These pieces of apparatus are made to act under the eyes of the pupils.)

Work of Animal Prime Movers upon Machines.

Results of experience as to the values of the daily work which animal motors can supply under different circumstances without exceeding the fatigue which sleep and nourishment are capable of repairing.

Theory of the Transmission of Work in Machines.

Principal resistance. Secondary resistances. Two manners in which bodies perform the duty of motors. Ratio of work done to work expended always inferior to unity. Different parts of machines; receiver; organs of transmission; tools as machines.

Calculation of the Work due to the passive resistances in machines.

Résumé of the notions previously acquired on friction. Application to the inclined plane, to the printing-press, to guides or grooves, to the screw with a square thread; different cases of uniform motion being impossible under the action of forces of given directions. Friction of trunnions, pivots, eccentrics, and insertions of winch-handles. Prony’s dynamometrical brake; conditions of its application. Resistance to rolling; its laws according to experiment. Use of rollers and friction-wheels; their practical inconveniences.

Mixed friction of toothed wheels; the Dobo escapement: friction of the teeth in the endless screw.

Stiffness and friction of cords. Results of experience. Friction of cords and straps running round drums. Different applications; brakes; transmission by cords, endless straps, or chains.

Examples and exercises; effects of passive resistances in the capstan, the crane, pulleys, &c.

Lesson 40. Revision.

SECOND YEAR.

PART I.—DYNAMICS.— DYNAMICS OF A MATERIAL POINT.

Lessons 1–2. Completion of the Notions acquired on this Subject.

Differential equations of the motion of a material point submitted to the continued action of one or more forces. The acceleration of the projection of a point upon any axis or plane is due to the projection of the forces on this axis or plane. The acceleration along the trajectory is due to the tangential force. Relation of the curvature to the centripetal force. Introduction of the force of inertia into the preceding enunciations.

The increase of the quantity of motion projected upon an axis or taken along the trajectory is equal to the impulsion of the projected resultant, or to that of the tangential force. The total impulsion of a force is got by methods of calculation and of experiment analogous to those which relate to work. The increase of the moment of the quantity of motion in relation to any axis is equal to the total moment of the impulsions of the forces during the same interval of time; direct geometrical demonstration of this theorem. In decomposing the velocity of the moving body into a velocity in the plane passing through the axis of the moments, and a velocity of revolution perpendicular to this plane, we may replace the moment of the quantity of motion in space by the quantity of motion of revolution. Particular case known under the name of the principle of areas.

Extension of the preceding theorems to the case of relative motions. Apparent forces which must be combined with the real ones that the relative motion of a point may be assimilated to an absolute motion. Particular case of relative equilibrium. Influence of the motion of the earth upon the accelerating force of gravity.

DYNAMICS OF ANY MATERIAL SYSTEMS.

Lessons 3–8.

Principle or general rule which reduces questions in dynamics to questions in equilibrium by the addition of the forces of inertia to the forces which really 113 act on the system. Equation of virtual work which expresses this equilibrium; it comprises in general the external and internal forces.

General Theorems.

These theorems, four in number, are founded upon the principle of the equality of action and reaction applied to internal forces. They may be deduced from the preceding rule, but the three last are obtained more simply by extending to a system of material points analogous theorems established for isolated material points.

General theorem of the motion of the center of gravity of a system. Particular case called principle of the conservation of the motion of the center of gravity.

General theorem on the quantities of motion and impulsions of exterior forces projected on any axis.

General theorems of moments of quantities of motion and impulsions of exterior forces, projected on any axis whatever.

General theorems of the moments of quantities of motion and impulsions of exterior forces about any axis. Analogy of these two theorems with the equations of the equilibrium of a solid, in which the forces are replaced by impulsions and quantities of motion.

Composition of impulsions, of quantities of motion, or the areas which represent them. All the equations which can be obtained by the application of the two theorems relative to quantities of motion and impulsions, reduce themselves to six distinct equations. Particular case called principle of the conservation of areas. Fixed plane of the resulting moment of the quantities of motion called plane of maximum areas.

General theorem of work and vis viva. Part which appertains to the interior forces in this theorem. Particular case called principle of the conservation of vires vivæ, where the sum of the elements of work done by the exterior and interior forces is the differential of a function of the co-ordinates of different points of the system. Application of the theorem of work to the stability of the equilibrium of heavy systems.

Extension of the preceding theorems to the case of relative motions. Particular case of relative equilibrium. Motion of any material system relative to axes always passing through the center of gravity, and moving parallel to themselves. Invariable plane of Laplace. Relation between the absolute vis viva of a material system, and that which would be due to its motion, referred to the system of movable axes above indicated.

Examples and Applications.

The following examples, amongst others, to be taken as applications or subjects of exercises relative to the general principles which precede.

Walking. Recoil of guns. Eolypile. Flight of rockets.

Pressure of fluid veins, resistance of mediums, &c. Direct collision of bodies more or less hard, elastic, or penetrable. Exchange of quantities of motion. Loss of vis viva under different hypotheses. Influence of vibrations and permanent molecular displacements.

Pile driving; advantage of large rammers. Comparison of effects of the 114 shocks and of simple pressures due to the weight of the construction. Oblique collision, and ricochet. Data furnished by experiment.

Oscillations of a vertical elastic prism suspended to a fixed point, and loaded with a weight, neglecting the inertia, and the weight of the material parts of this prism. Case of a sudden blow. What is meant by the “resistance vive” of a prism to rupture? Results of experiments.

Work developed by powder upon projectiles, estimated according to the vis viva which it impresses on them, as well as upon the gun and the gases upon hypothesis of a mean velocity.

SPECIAL DYNAMICS OF SOLID BODIES.

Lessons 9–12. Simple Rotation of an invariable Solid about its Axis.

In applying to this case the first general rule of dynamics, the theorem of the moments of the quantities of motion, and the theorem of work, we are led to the notion of the moment of inertia; explanation of the origin of this name. The angular acceleration is equal to the sum of the moments of the exterior forces divided by the moment of inertia about the axis of rotation. Sum of the moments of the quantities of motion relative to this axis. Vis viva of a solid simply turning about an axis. What is meant by radius of gyration?

Remind of the geometrical properties of moments of inertia, of the ellipsoid which represents them, of the principal axes at any point, of those which are referred to the center of gravity.

Pressure which a rotating body exercises on its supports. Reduction of the centrifugal and tangential forces of inertia to a force which is the force of inertia of the entire mass accumulated at the center of gravity, and a couple.

Particular case where the forces of inertia have a single resultant; different examples. Center of percussion. Compound pendulum; length of the corresponding simple pendulum. Center of oscillation; reciprocity of the centers or axes of suspension and oscillation. Pressure upon the axis. Influence of the medium; experience proves that the resistance, varying with the velocity, changes the extent of the oscillations, but does not sensibly affect the time. Experimental determination of the center of oscillation and the moment of inertia about an axis.

Motion of an invariable Solid subject to certain Forces.

General notions on this subject. Motion of the center of gravity; motion of rotation about this point.

Lessons 13–19. Various Applications.

Motion of a homogeneous sphere or cylinder rolling upon an inclined plane, taking friction into account.

Motion of a pulley with its axis horizontal, solicited by two weights suspended vertically to a thread or fine string passing round the neck of the pulley, the axle of which rests upon movable wheels. Atwood’s machine serving to demonstrate the laws of the communication of motion.

Motion of a horizontal wheel and axle acted on by a weight suspended vertically to a cord rolled round the axle, or upon a drum with the same axis, and presenting an eccentric mass. To take account of the variable friction of the 115 bearings, and the stiffness of the cord, with recourse, if necessary, to approximation by quadratures. Oscillations of the torsion balance.

Balistic pendulum. Condition that there may be no shock on the axis. Experimental determination of the direction in which the percussion should take place.

Theory of Huyghen’s conical pendulum considered as a regulator of machinery. How to take account of the inertia and friction of the jointed rods, as well as of the force necessary to move the regulating lever, &c.; appreciation of the degree of sensibility of the ball apparatus with a given uniform velocity.

Windlass with fly-wheel. Dynamical properties of the fly-wheel. Reduced formulæ for a crank with single or double action. Advantages and disadvantages of eccentric masses. Tendency of the tangential forces of inertia to break the arms. Numerical examples and computations.

Mutual action of rotating bodies connected by straps or toothed wheels in varying motion.

The wedge and punching-press. Stamping screw or lever used in coining, cams, lifting a pile or a hammer. To take account of the friction during the blow, and afterwards to estimate the loss of vis viva in cases which admit of it.

PART II.—SPECIAL MECHANICS OF FLUIDS.—HYDROSTATICS.

Lessons 20–22.

Principle of the equality of pressure in all directions. Propagation of the pressures from the surface to the interior of a fluid, and upon the sides of the vessel. Equations of equilibrium for any set of forces. Pressure exerted in the containing orifices. Measure of the pressure upon a plain portion of surface inclined or vertical (sluice-gate, embankments, &c.) Center of push or pressure. Pressure against the surfaces of a cylindrical tube. Effect, and resistance to oppose to the pressure. Manometer and piezometer. Equilibrium of a body plunged in a heavy fluid or floating at its surface. Stability of floating bodies. Metacenter. Laws of the pressure in the different atmospheric strata.

HYDRAULICS.

Lessons 23–27. Flow of Fluids through small Orifices.

Study of the phenomena which accompany this flow in the case of a thin envelop and a liquid kept at a constant level. Conditions of this constancy in the level, and the permanence of the motion in general. Motion of the lines of fluid; form; contraction; reversal and discontinuity of liquid veins. Fundamental formulæ for liquids and gases based upon the principle of vis viva, and Bernoulli’s hypothesis of parallel s or Borda’s of contiguous threads. Torricelli’s theorem relative to small orifices. What is called the theoretical expenditure, effective expenditure, and co-efficient of geometrical contraction. Co-efficient deduced from the effective expenditure. Its variations with the volume of the fluid contents, and the form of the inner surfaces of the reservoir. Results of the experiments of Michelotti, Borda, Bossut, &c. Phenomenon of adjutages. Venturi’s experiments; influence of atmospheric pressure; loss of vis viva; reduction of the velocity and augmentation of the expenditure. Results of experience relative to the co-efficient of expenditure, the form and range of the parabolic jets, showing the initial vis viva, and the loss of vis viva.

Large orifices.—Sluice holes and floodgates; reservoirs or open orifices; expenditure; practical formulæ and results of experiment. Influence of the proximity of the sides and the walls. Arrangement to avoid the effects of contraction or the losses of vis viva.

Flow through conducting Pipes and Open Canals.

Practical formulæ relative to the case of uniform s of great length. Measure of the pressures at different points of a conduit-pipe. Expression for the losses of effect due to corners and obstructions. Flow of gases. Principal methods of measuring the volume consumed adopted in practice. Floats. Pitot’s tube. Woltman’s mill. Register mill in air or gas. Waste in such instruments. Modulus and scale for water-supply.

PART III.—DIFFERENT MACHINES CONSIDERED IN THE STATE OF MOTION.

Lesson 28. General Considerations. Résumé of the Notions acquired on this Subject.

Equation of vis viva, and transmission of work in machines, account being taken of the different causes of power and resistance. Physical constitution of machines; receiver, communicators, and operator. Influence of the weights, of frictions, of shocks, and any changes in the vis viva. Parts with continuous or uniform motion, with alternating or oscillating motion. Laws of the motion on starting from rest, and when the stationary condition is established. The positions to which the maximum and minimum of the vis viva correspond are those in which there is equilibrium between all the forces, exclusive of the forces of inertia. Advantage of uniform or periodic motion. General methods for regulating the motion; symmetrical distribution of the masses and strains; flys and various regulators. Brakes and moderators; their inconveniences. Object and real advantages of machines.

Lessons 27–35. Hydraulic Wheels.

Vertical wheels with float-boards, with curved ladles, and with spouts. Figure of the surface of the fluid in these latter. Horizontal wheels working by float-boards, buckets, and reaction. Turbines. Description, play, and useful effects compared according to the results of experiment. Vertical wheels of windmills and steamboats. Screw propeller.

Windmills.

Description. Result of Coulomb’s observations.

On the principal kinds of Pumps.

Special organs of pumps. Valves and pistons, force pump, sucking pump; limit to the rise of the water. Sucking and force pump. Dynamical effects. Indication as to the losses of vis viva and the waste in different pumps. Explanation of the hydraulic ram. Air vessel. Fire pumps. Double action pumps.

Various Hydraulic Machines.

Hydraulic press. Water engine. Exhausting machines; norias; under and overshot wheels; Archimedes’ screw, construction and experimental data.

Lessons 36–39. Steam Engines.

Succinct description of the principal kinds of steam-engine with or without detent. Effects and advantages of the detent. Condenser. Air Pump. Furnace and feeding-pump.

Variable detent. Formulæ and experimental results.

Lessons 40–42. Revision.

Reflections on the totality of the subjects of the course.

IV. PHYSICS.—FIRST YEAR.

GENERAL PROPERTIES OF BODIES.—HYDROSTATICS.—HYDRODYNAMICS.

Lessons 1–5. Preliminary Notions.

Definitions of physics. Phenomena. Physical laws. Experiments are designed to make them spring out of the phenomena. Method of induction. Physical theories; different character of the experimental and mathematical methods.

General Properties of Bodies.

Extension. Measure of lengths. Vernier. Cathetometer. Micrometer screw. Spherometer. Dividing engine.

Divisibility. Porosity. Ideas generally received on the molecular constitution of bodies. These conceptions, which are purely hypothetical, must not be confounded with physical laws. Elasticity. Mobility. Inertia. Forces; their equilibrium, their effects, their numerical estimation.

Weight or Gravity.

Direction of gravity. Plumb-line. Relation between the direction of gravity and the surface of still water.

Weight. Center of gravity.

Experimental study of the motion produced by weight. In vacuum, all bodies fall with the same velocity. Disturbing influence of the air. Inclined plane of Galileo. Atwood’s machine. To prove by experiment; 1^o the law of the spaces described; 2^o the law of velocities. Morin’s self-registering apparatus with revolving cylinder.

Law of the independence of the effect produced by a force upon a body, and the motion anteriorily acquired by this body. Law of the independence of the effects of forces which act simultaneously upon the same body. Experimental demonstration and generalization of these laws. Law of the equality of action and reaction.

Mass. Acceleration. For equal masses the forces are as the accelerations which they produce. Relation between the force, mass, and acceleration. Collision.

General laws of uniformly accelerated motion. Formulæ.

Pendulum. Law of the isochronism of small oscillations and law of the lengths deduced from observation.

Method of coincidences or beats. Use of the pendulum as the measure of time. Simple pendulum; formulæ. Compound pendulum: the laws of the oscillations of a compound pendulum are the same as the laws of the oscillations of a simple pendulum whose length may be calculated.

Determination by means of the pendulum of the acceleration produced by gravity. This acceleration is independent of the nature of the body.

Remark that the formulæ for the motion of oscillation apply to the comparison of forces of any kind, that may be regarded as constant and parallel to themselves in all positions of the oscillating body.

Identity of gravity and universal attraction.

Measure of weights. Balance. Conditions to be attended to in making it. Absolute sensibility; proportional sensibility. Method of double weighing. Details of the precautions necessary in order to obtain an exact weight.

Different States of Bodies. Hydrostatics.

Solids. Cohesion. Transmission of external pressures.

Elasticity. The true laws of elasticity are unknown. Empirical laws in certain simple cases, and for a very small action. Elasticity of compression, extension, torsion. Experimental determination of the co-efficients of elasticity. Limits of elasticity. Limits of tenacity.

Ductility. Temper. Cold hammering. Annealing.

Liquids. Fluidity. Viscosity. Physical laws which form the basis of hydrostatics:—1^o the transmission of external pressures is equal in all directions; 2^o the pressure exercised in the interior of a liquid upon an element of a surface is normal to that element, and independent (as to amount) of its direction. These principles are demonstrated by the experimental verification of the consequences drawn from them.

Application to heavy liquids. Free surface, and surface de niveau. Pressure upon the parts of the containing vessel, and upon the bottom in particular; hydrostatic paradox; verificatory experiments. Haldat’s apparatus. Hydrostatic press.

Application to immersed or floating bodies (principle of Archimedes;) verificatory experiments. (In treating of the equilibrium of floating bodies, the conditions of stability are not gone into.)

Superposed liquids.

Communicating vessels. Water level. Spirit level; its use in instruments.

Densities of solids and liquids. Anemometers.

Compressibility of liquids. Piezometer. Correction due to the compressibility of the solid envelop.

Gas. Expansibility. Other properties common to liquids and gases. Principle of the equal transmission of pressures in all directions. Weight of gases. Pressure due to weight (principle of Archimedes.) Weight of body in air and in vacuum. Aerostation.

Superposed liquids and gases.

Communicating vessels. Barometer.

Detailed construction of barometer. Barometers of Fortin, Gay-Lussac, Bunten. Indication of the corrections necessary.

Mariotte’s law. Regnault’s experiments.

Manometer with atmospheric air—with compressed air. Bourdon’s manometer.

Law of the mixture of gases.

Air pump. Condensing pump.

Primary Notions of Hydrodynamics.

Toricelli’s principle. Mariotte’s vessel and syphon. Uniform flow of liquids. The same of gases.

Molecular Phenomena.

Cohesion of liquids. Adhesion of liquids to solids. Capillary phenomena. Apparent attractions and repulsions of floating bodies.

Adhesion of drops.

Molecular actions intervene as disturbing forces in the phenomena of the equilibrium and motion of liquids.

HEAT.

EFFECTS OF HEAT ON BODIES.

Lessons 6–9. Generalities.

General effects. Arbitrary choice of one of these effects to define the thermometric condition of a body. Conventional adoption of a thermometer. Definition of temperature.

Dilating Effects.

Definition of the co-efficients of linear, superficial, and cubic dilatation. Approximate relation between the numerical values of these three co-efficients. The value of the co-efficient of dilatation depends upon the thermometric substance and the temperature selected as the zero point. It becomes nearly independent of the zero point when the co-efficient is very small.

Relation between volume, density, and temperature. Linear dilatation of solid bodies. Ramsden’s instrument. Cubical dilatation of liquids. Dulong and Petit’s experiments on mercury. Discussion. Regnault’s experiments.

Cubical dilatation of solids and of other liquids when that of mercury is given.

Relations between the volume, density, and elasticity of a gas, and its temperature.

Cubical dilatation of gases. Experiments of Gay-Lussac, Rudberg, and M. Regnault. Advantage of varying the methods of experimenting in these delicate researches.

Methods based upon the changes of volume under a constant pressure, and upon the changes of pressure for a constant volume.

The disagreement of these two methods is due to deviations from the law of Mariotte.

The constancy of the co-efficients of dilatation previously defined is only approximately true.

Necessity of employing two different co-efficients of dilatation according as consideration is being had to the variations of volume to a given pressure, or of pressure to a given volume.

Empirical formulæ for the dilatation of liquids.

Graphical constructions.

Lesson 10. Thermometers.

Construction of thermometers. Mercurial thermometer. Details of construction. Fixed points. Different scales; their relation. Arbitrary scales. 120 Change which takes place in the zero point. Different precautions to be observed in using the mercurial thermometer.

General want of comparability of mercurial thermometers with tubes of different material.

Air thermometers. They are comparable with one another within the limits of the errors of experiment, whatever the nature of the tube employed. This property entitles the air thermometer to a preference for all accurate measures. Comparison of the air and mercurial thermometers.

THERMOSCOPE, DIFFERENTIAL THERMOMETER, PYROMETERS, BREGUET’S THERMOMETER.

Lessons 11–13. Changes of State produced by Heat.

Exposition of the phenomena which accompany the liquefaction of solids and the solidification of liquids. Constancy of the temperature whilst the phenomenon is going on.

Sudden melting and freezing. Persistance of the liquid state beneath the melting point.

Influence of pressure.

Exposition of the phenomena which accompany the conversion of liquids or solids into vapor, and the inverse passage from the gaseous to the liquid or solid state. Constancy of the temperatures whilst the phenomenon is going on.

Influence of pressure.

Phenomena of ebullition in free space. Augmentation of the temperature and pressure in a confined space. Papin’s digester.

Properties of vapors in spaces and in gases. Saturated vapors. Their tension does not depend upon the space which they occupy, but only upon their temperature.

Effects of a diminution or increase of pressure without change of temperature; the same without change of pressure. Effects of lowering the temperature in a limited region of space occupied by vapor.

Tension of a saturated vapor at the boiling point of its liquid.

Measure of the tensions of the vapor of water. Experiments of Dalton, Gay-Lussac, Dulong, and Arago, and of M. Regnault.

Tables of the tensions of steam. Empirical formulæ. Graphical constructions.

It is assumed that non-saturated vapors are subject to the same laws as gases.

APPLICATIONS. CORRECTION OF THE BOILING-POINT IN THE CONSTRUCTION OF THERMOMETERS. BAROMETRICAL THERMOMETERS.

Lessons 14–16. Various Applications of the Laws previously established.

A phenomenon can not always be separated from the accessory phenomena which concur with it in producing the final result. Necessity of corrections to render complex results comparable inter se.

Density of solids when regard is had to the temperature and weight of the gases displaced by them.

Precautions to be attended to in the experiments. Empirical formulæ for the 121 density of liquids. Maximum density of water. The temperature corresponding to the maximum must be determined graphically, or by interpolation.

Corrections for measures of capacity, for barometric measures.

The uncertainty of the corrections can not, in any considerable degree, affect the densities of solids and liquids.

Density of gases. Biot and Arago’s experiments. Special difficulties of the question. The uncertainty of the corrections may sensibly affect the results. Regnault’s method.

The same method may be applied to the determination of the co-efficient of dilatation for gases.

Density of vapors. Definition founded on the hypothetical application of the same laws to gases and vapors. Formulæ. Experimental method of Gay-Lussac and of Dumas. Corrections. Comparison of the two methods. Necessity of conducting the experiments at a distance from the saturation point. Latour’s experiments. Relations between the weight and volume of a gas, and its temperatures; between the weight and volume of a gas mixed with vapors, and its temperature. Various problems.

Hygrometry. Chemical hygrometry. Hygrometry by the dew-point. Psychrometry.

PROPAGATION OF HEAT.

Lessons 17–18. Propagation at a Distance.

Rapid propagation of heat at a distance, in vacuum, in gases, in certain liquid or solid mediums. Experiments which establish this.

Rays of heat. Velocity of propagation. Intensity of heat received at a distance. Intensity of heat received or emitted obliquely. Emitting power, power of absorption, reflection, diffusion. The emitting and absorbing power are expressible by the same number in terms of their proper units respectively.

Analysis of calorific radiations by absorption. Different effects of deathermanous or thermochroic medium. Different influences of increasing thicknesses of the combination of different mediums. Radiations proceeding from different sources, various effects of different mediums on these radiations.

The calorific radiations emanating from different sources, have all the characters of differently colored heterogeneous rays of light.

THEORY OF RADIATION AND OF THE DYNAMICAL EQUILIBRIUM OF TEMPERATURES. APPARENT REFLECTION OF COLD.

Lesson 19. Law of Cooling.

Definition of the rate of cooling. Many causes may conspire in the cooling of a body.

Cooling in space. Newton’s law only an approximation. Experimental investigation of the true law. Method to be followed in this investigation. The velocity of cooling is not a datum directly observable. It must be deduced provisionally from an empirical relation between the temperature and the time. Preliminary experiments. Course of the definitive experiments. Elementary experimental laws.

Hypothetical form of the function which expresses the velocity of cooling. To determine by means of the preceding experimental laws the unknown form 122 of the function which expresses the law of radiation. Relation between the temperatures and the times. This relation only contains data immediately observable, and may be verified à posteriori.

The contents which enter into the preceding relation depend upon thermometric constants and the nature of the radiating surface.

The contact of a gas modifies the law of cooling.

Lessons 20–21. Propagation by Contact.

Slow propagation of heat in the interior of bodies, in solids, liquids, and gases. Confirmatory experiments. Hypothesis of partial radiation. Theoretical law resulting from this hypothesis upon the decrease of temperatures in a solid limited by two indefinite parallel planes maintained at constant temperatures. Determination of the co-efficient of conductibility by the experimental realization of these conditions. This experiment determines a numerical value of the co-efficients; it is not of a nature to serve as a check upon the theoretical principles. Enunciation of the law resulting from the same theoretical principles upon the decrease of temperatures in a thin bar heated at one end.

CALORIMETRY.

Lessons 22–23. Specific Heats.

Comparison of the quantities of heat. The quantities of heat are not proportioned to the temperatures. Definitions of the unity of heat. General method of mixtures to estimate the quantities of heat. Experimental precautions and corrections.

Application of the general method of mixtures. Specific heats of solids and liquids. Law of the specific heat of atoms. Heat absorbed by expansion, restored by the compression of bodies. Experiments on gases. Specific heats of gases under constant pressure. Measure of specific heats of gases under constant pressure. Special difficulties of the question. Succinct indication of one of the methods. Specific heats to a constant volume.

Lesson 24. Latent Heat.

Component heat of liquids absorbed into the latent state during fusion, restored to the free state during solidification.

Influence of the viscous state. Latent heat of ice. Ice calorimeter; its defects.

Component heat of vapors, absorbed into the latent state during vaporization, restored to the free state during condensation. Measure of the latent heat of vapors. Regnault’s experiments.

Empirical laws on the latent heat of vaporization.

Applications of Calorimetry.

Means of producing heat or cold; 1, by changes in density; 2, by changes of state. Freezing mixtures. Vaporization of liquids. Condensation of vapors.

Steam-boilers. Warming by hot air and hot water. Various problems. Sensations produced by a jet of vapor.

Different physical and chemical sources of heat; percussion, friction, chemical combinations, animal heat, natural heat of the globe, solar heat, &c. It will be 123 remarked that mechanical work may become a source of heat, and heat a source of mechanical work.

STATICAL ELECTRICITY.—MAGNETISM.—STATICAL ELECTRICITY.

Lessons 25–27.

General phenomena. Distinction of bodies into conductors and non-conductors. Distinction of electricity into two kinds. Separation of the two electricities by friction. Hypothesis of electric fluids. Effects of vacuum of gases and vapors of points. Electrical attractions and repulsions. Electrization by influence. Case where the influenced body is already electrized. Sparks; power of points. Electrization by influence preceding the motion of light bodies.

Electroscopes.

Electrical machines of Van-Marum, Nairne, Armstrong.

Condenser. Accumulation of electricity upon its surface. Leyden jar. Batteries. Electrical discharges. Effects of electricity.

Condensing electroscope. Electrophorus.

Velocity of statical electricity.

Atmospherical electricity. Phenomena observed with a serene sky. Electricity of clouds. Storms. Lightning. Thunder. Effects of thunder. Return-shock. Lightning conductor.

Different sources of statical electricity.

MAGNETISM.

Lessons 28–30.

Natural magnets. Action upon iron and steel. Artificial magnets. The attractive action appears as if it were concentrated about the extremities of magnetic bars. First idea of poles.

Direction of a magnetized bar under the earth’s action. Reciprocal action of the poles of two magnets. Names given to the poles.

Phenomena of influence. Action of a magnet upon a bar of soft iron; upon a bar of steel. Coercive force. Effects of the rupture of a magnetized bar. Theoretical ideas on the constitution of magnets. More precise definition of the poles.

Action of the earth upon a magnet. The earth may be considered as a magnet. Its action may be destroyed by means of a magnet suitably placed. Astatic needles. The magnetic action of the earth is equivalent to a couple. Three constants define the couple of terrestrial action. Declination. Inclination. Intensity. Measure of the declination; of the inclination.

Magnetic metals. Influence of hammering, tempering, &c. Methods of magnetizing. Saturation. Loss of magnetism. Influence of heat. Magnetic lines. Armatures.

Magnetization by the earth’s influence. Means of determining the magnetic state of a body.

Measure of Magnetism and Electricity.

Lessons 31–32.

Coulomb’s balance. Distribution of magnetism on a magnetized bar; distribution 124 of electricity at the surface of isolated conductors. Comparative discussion of the conditions of the two problems and the methods of experiment.

Laws of the magnetic attractions and repulsions. Law of electric attractions and repulsions. Comparative discussion of the conditions of the two problems, and the methods of experiment.

Determination of the law of magnetic attractions and repulsions by the method of oscillations.

Comparison of the magnetic intensity at different points of the earth’s surface.

Lessons 33–34. Revision.

Considerations on the totality of the subjects of the course.

SECOND YEAR.

DYNAMICAL ELECTRICITY.—GALVANISM.

Lessons 1–2.

Chemical sources of electricity. Experimental proofs. Arrangement devised by Volta to accumulate, at least in part, at the extremities of a heterogeneous conductor the electricity developed by chemical actions.

Pile. Tension at the two isolated extremities; at one single isolated extremity; at the two extremities reunited by a conductor. Continuous current of electricity. Poles. Direction of the current, &c.

Various modifications of the pile of Volta. Woollaston’s pile, Münch’s pile, &c. Dry piles; their application to the electroscope.

Principal effects of electricity in motion, and means of making the currents perceptible. Experiment of Oersted. Galvanoscopes.

Currents produced by heat in heterogeneous circuits. Thermo-electric piles. Thermometric graduation of thermo-electric piles.

Currents produced by the sources of statical electricity.

PROPERTIES OF CURRENTS.

Lesson 3.   1. Chemical Actions.

Definitions. Phenomena of decomposition and transference. Reaction of the elements transferred upon electrodes of different kinds.

Principles of electrotyping.

Causes of the variation of the current in ordinary piles; means of remedying this; Daniell’s pile. Bunsen’s pile.

Lessons 4–8.   2. Mechanical Properties.

Reciprocal actions of rectilinear or sinuous currents parallel or inclined. Reaction of a current on itself.

Reciprocal actions of helices or solenoids. Continuous rotation of currents by their mutual action; by reaction. Analogy of magnets and solenoids. Electro-dynamical theory of magnetism. Action of magnets upon currents and solenoids. Action of currents upon magnets. Experiments of Biot and Savart. Continual rotation of a current by a magnet; of a magnet by a magnet.

Action of the earth upon currents; it acts as a rectilinear current directed from east to west, perpendicularly to the magnetic meridian.

Continual rotation of a current by the action of the earth.

Astatic conductors.

Lessons 9–10.   3. Magnetic Properties.

Action of an interposed conductor upon iron filings.

Electro-magnets. Magnetization temporary or permanent. Principles of the electric telegraph. Electrometers. Reference to diamagnetic phenomena.

4. Electro-motive Properties.

Phenomena of induction by currents, by magnets. Phenomena of magnetism in motion. Induction of a current upon itself.

Induction of different orders.

Interrupted currents. Clarke’s machine.

Lesson 11.   5. Calorific Properties.

Influence of the nature of the interposed conductor; of its ; of the intensity of the current. Unequal temperatures at the different junctions of a heterogeneous circuit.

6. Luminous Properties.

Incandescence of solid conductors. Spectrum of the electric light. Voltaic arc. Transfer of ponderable matter. Action of the magnet upon the Voltaic arc.

7. Physiological Action of Currents.

Some words on this subject. Muscles and nerves. Actions of discontinuous currents. Reotomic contrivances.

Reometry.

Compass of sines, of tangents. Experimental graduation of galvanometers.

The dynamical intensity of a current diminishes when the length of a current increases. Reostat.

Laws of the dynamical intensity of a current in a homogeneous circuit. Reduced length and resistance of a circuit. Specific co-efficients of resistance. Laws of the dynamic intensity of a current in a heterogeneous circuit.

The intensity of currents is in the inverse ratio of the total reduced length, and proportional to the sum of the electromotive forces. Formula of the pile. Discussion of the case of hydro-electric piles—thermo-electric piles. Conditions for the construction of a pile, with reference to the effects to be produced. Conditions for the construction of a galvanometer with reference to its intended application.

Laws of secondary currents in the simplest cases. The chemical intensity of a current is proportional to its dynamical intensity.

ACOUSTICS.

Lessons 12–15.

Noise, sound, quality of the sound, pitch, intensity, timbre. A state of vibration in a solid, liquid, or gaseous body is accompanied with the production of sound.

The pitch depends on the number of vibrations. Unison. Instruments for 126 counting the vibrations:—1st. Graphic method. 2nd. Toothed wheels. 3rd. Lever. Feeling of concord. Musical scale. Gamut. Limit of appreciable sounds.

Study of vibrating motions in solids. Vibrating cords. Vibrations transversal, longitudinal. Experimental laws. Sonometer.

Spontaneous division of a cord into segments. Fundamental sounds. Harmonic sounds.

Straight and curved rods. Transversal and longitudinal vibrations. Experimental laws. Division into segments. Nodes. Ventral segments. Membranes.

Plane and curved plates. The vibrations divide them into “concamerations.” Nodal lines. Harmonic sounds.

Study of the vibrations in liquids and in gases.

Theoretical ideas upon the propagation of a vibratory motion in indefinite elastic media, on an indefinite cylindrical tube. Waves of condensation of dilatation. Progressive nodes and ventral divisions. Laws of the intensities of sound. Direct measure of the velocity of the propagation of sound in water. Measure of the velocity of the propagation of sound in air. Formulæ without demonstration. Comparison of the formulæ with experiment.

Sonorous waves reflected in an indefinite medium.

Fixed nodes and ventral divisions. Sonorous waves reflected in closed and open tubes. Fixed nodes and ventral divisions; the vibratory state and density thereat.

Series of sounds afforded by the same tube. Effect of holes.

Sonorous reflected waves in rods. Series of sounds afforded by the same rod vibrating longitudinally. Indirect measure of the velocity of sound in gases, liquids, and solids.

Experiments on the communication of vibrating motion in heterogeneous mediums, on the general direction of the vibrating motion communicated.

Intensification of sounds. Interferences. Beats. Different stringed and wind instruments. Means of setting them in vibration.

A few words on the organs of voice and hearing. Incompleteness of our knowledge on this subject.

OPTICS.

Lessons 16–17. Propagation of Light.

Propagation of light in a straight line. Rays of light. Geometrical theory of shadows. Velocity of light. Rœmer’s observations. Laws of intensity of light. Photometers of Bouguer, Rumford. Intensity of oblique rays. Comparison of illuminating powers. Total brightness. Intrinsic brightness.

Reflection.

Reflection of light: its laws. Experimental demonstration. Images formed by one or more plane mirrors. To ascertain if a looking-glass has its two faces parallel.

Spherical mirrors. Foci, formulæ. Discussion. Images by reflection. Measure of the radius of a spherical mirror.

Definition of caustics by reflection. Definition of the two spherical aberrations in mirrors.

Woollaston’s goniometer.

Lesson 18. Refraction.

Refraction of light in homogeneous mediums. Descartes’ law. Experimental demonstration for solids and liquids.

Inverse return of the rays. Successive refractions. Indices of transmission in terms of the principal indices. Consequences of Descartes’ law. Total reflection. Manner of observing it.

Irregular refractions. Mirage.

Refraction is always accompanied with the accessory phenomenon of dispersion.

Geometrical consequences of the law of refraction. Focus of a plane surface. Focus of a medium bounded by two parallel plane surfaces; by two plane surfaces inclined in the form of a prism.

Foci of a spherical surface; of a medium limited by two spherical surfaces. Lenses.

Formula for lenses. Discussion. Varieties of lenses. Optic center. Images. Measure of the focal distance of lenses.

Definition of caustics by refraction. Definition of the two spherical aberrations of a lens.

Lessons 19–20. Dispersion.

Unequal refrangibility of the differently colored rays which compose white light. Analysis of heterogeneous light by the prisms. Newton’s method. Solar spectrum. Homogeneity of the different colors. Second refraction of a homogeneous pencil. Experiment with crossed prisms. Precautions to be attended to in the experiments. The spectrum, obtained by Newton’s method, differs from the spectrum produced at the focus of a lens placed between the prism and the picture, according to the method of Fraunhofer. Reasons of the comparative purity of this latter spectrum. Fraunhofer’s lines. Different spectra of different sources of heterogeneous light. Marginal iridescence of a large pencil of natural light traversing a prism. Dispersion of light by lenses. Iridescence of focal images. Recomposition of light, by means of a prism at the focus of a spherical mirror or a lens, by the rapid rotation of a plane mirror, by the rotation of a disk with party-colored sectors. Compound colors.

Chemical and calorific radiations accompany luminous radiations.

Analysis of light by absorption. Characteristic action of transparent colored mediums upon different sorts of compound light. Different influences of increasing thickness. Effects of differently colored mediums upon heterogeneous light. Effects of differently colored mediums upon homogeneous rays separated by the prism.

Lesson 21. Measure of the Indices of Refraction.

Determination of the indices of refraction.

1. In solids. Measure of the refracting angles. Minimum of deviation. Measure of the corresponding deviation. Use of Fraunhofer’s lines.

2. In liquids.

3. In gases. Special difficulties of the question. Experimental method. Biot’s and Arago’s experiments.

Any power whatever of the index of refraction diminished by unit is sensibly proportional to the density of the gas. Method of Dulong founded on this remark.

Lessons 22–23. Application of the preceding Laws.

Rainbow. Different orders of bow.

Achromatism.

Achromatic prisms. Diasperometer achromatism of lenses; how to verify it. Definition of secondary spectra: their nature gives the means of recognizing, whether flint or crown glass predominates, in an imperfectly achromatic lens.

Instruments essentially consisting of an achromatic lens. Magic lantern; megascope; solar microscope; camera obscura; collimators.

Vision.

Summary description of the principal optical parts of the eye. They act like the lens of a camera obscura to form an image upon the retina. Distinct vision; optometers; short sight; long sight; spectacles.

Binocular vision; perspective peculiar to each eye; estimation of distances; sensation of solidity; stereoscope; estimation of magnitudes.

PERSISTENCE OF IMPRESSIONS; DIVERS EXPERIMENTS.

Lessons 24–26. Optical Instruments.

Camera lucida. A lens is necessary to reduce to the same apparent distance the two objects seen simultaneously. Instruments to assist the sight; simple microscope; the magnifying power; distinctness; field; advantage of a diaphragm; it modifies the field and the brightness variously according to its position.

Woollaston’s double glass; its advantages.

General principle of compound dioptrical instruments.

Compound microscope; experimental measure of its magnifying power, by means of the diaphragm, by means of the camera lucida.

Astronomical telescope; object glass; simple eye-glass. Necessity for a diaphragm; its place; the wires, their place; optic axis of a telescope. Parallax of the threads of the wires; magnifying power of the object-glass; of the eye-glass; field of view of a telescope.

Optic ring; different methods of measuring the magnifying power.

Distinctness of a telescope; night-glass.

Different distances of drawing out the eye-glass for short-sighted and long-sighted observers.

Different sorts of eye-pieces; positive eye-pieces; ordinary double eye-piece of the astronomical telescope. Ramsden’s eye-piece; treble eye-piece of the terrestrial telescope. Negative eye-pieces; simple eye-piece of Galileo. Compound ditto of Huyghens; advantages and disadvantages of these different combinations; general principle of catadioptrical instruments.

Lessons 27–29. Double Refraction.

Crystallized mediums do not all act upon light like homogeneous mediums.

Double refraction of Iceland spar: the extraordinary image turns round the ordinary image. The ordinary and extraordinary rays cross at the interior of the crystal.

Huyghens’ construction; measure of the ordinary and extraordinary indices of refraction; attractive and repulsive crystals; a ray falling perpendicularly does not always bifurcate in a camera with parallel faces, nor in a prism. Definition of uniaxial and biaxial crystals.

The dispersion of the ordinary ray differs from that of the extraordinary ray.

The two rays are unequally absorbed in many colored mediums. Tourmaline.

Doubly-refracting prisms; their construction. Use of doubly-refracting prisms to measure apparent diameters, &c.

Lessons 30–31. Polarization.

Successive refractions in doubly-refracting prisms. Special properties of the two rays emerging from the first doubly refracting crystal. Polarization by double refraction.

Reflection from transparent media polarizes the light partially or wholly according to the incidence. Brewster’s law. Reflection of polarized light from a transparent medium.

Simple refraction partially polarizes the light. Many successive refractions polarize it almost totally. Piles of glasses.

Different methods to obtain a ray of polarized light, 1st, by reflection; 2nd, by simple refraction; 3rd, by double refraction, by eliminating one of the refracted pencils;—by a screen,—by total reflection, Nicol’s prism, by absoption, tourmaline.

Distinctive characters of light completely or partially polarized.

Lessons 32–34. Theory of Undulations.

Hypothesis of luminous undulations.

Vibratory state of a simple ray of homogeneous light. Vibratory state at the inter of two simple rays of homogeneous light intersecting at a very small angle.

Experimental proofs in support of this hypothesis:

1st. Experiment with interferences, fringes. Their breadth is different for different colors; they give the various colors of the prism in white light. The alternately bright and dark sheets are hyperboloids of revolution. The measure of the fringes give the means of estimating the lengths of the undulations corresponding to different colors.

2nd. Colored rings of Newton, observed by reflection, by refraction. Law of the diameters; these vary in absolute length for different colors. Variously colored rings with white light. Reflected rings with a white spot at the center.

The theory of the undulations does not apply merely to theses phenomena. Explication of the laws of reflection and refraction. Definition of polarization in the system of waves. Elementary application of double refraction and the polarization which accompanies it in uniaxial crystals when the face of the crystal is parallel to the axis, and the plane of incidence normal or parallel to this axis.

Chemical and Calorific Radiations.

Chemical and calorific radiations are subject, like luminous radiations, to the laws of reflection, refraction, dispersion, double refraction, polarization, interferences.

Lessons 35–36. Revision.

Considerations on the totality of the subjects of the course.

MANIPULATIONS IN PHYSICS.

The practical exercises which constitute the subject of this programme will be performed in part by the pupils under the direction of the professors and répétiteurs, in part by the professors and répétiteurs, with the coöperation of the pupils.

FIRST YEAR.

Use of various instruments, designed for measuring lengths. Experiments on weight with Atwood’s machine, the inclined plane, Morin’s apparatus, and the pendulum.

Some experiments on elasticity.

Various verifications of the principles of hydrostatics and hydrodynamics.

Construction of aerometers.

Construction of a barometer, of a manometer. Various verifications of the law of Mariotte.

Various experiments with the air-pump.

Determination the density of solids or liquids by different methods.

Construction of a thermometer.

Experiments on the dilatation of liquids and solids by means of the ordinary thermometer and by means of the statical thermometer.

Experiments upon the dilatation of air by various methods.

Experiments upon the tension of vapors by different methods.

Determination of the density of vapors and gases by various methods.

Leading experiments on calorific radiation.

Experiments on cooling.

Determination of specific heats, heats of fusion, heats at which bodies pass into vapor.

Cooling mixtures.

Use of the chemical hygrometer, the wet bulb hygrometer.

Rehearsal of the leading experiments on magnetism.

To magnetize a needle, to reverse its poles.

Rehearsal of the principal experiments of statical electricity.

Experiments verificatory of the laws of electricity and magnetism.

Use of compasses.

SECOND YEAR.

Experiments upon the chemical actions of poles.

Leading experiments in electro-dynamics.

Leading experiments upon the magnetic properties of currents.

Experiments on induction.

Experiments on the calorific and luminous actions of currents.

Quantitative experiments on the laws of currents.

Experiments on the propagation of sound; on the vibrations of rods of plane or curved plates, membranes, sonorous tubes.

Experiments on mirrors, plane or curved.

Experiments on lenses. Experiments on the decomposition of light by the prism—by absorption. Measures of the indices of the refraction of solids. Use of the magnifying glass and microscope; measure of the magnifying power. Use of different telescopes, with and without corrections. Measure of the magnifying power. Experiments on double refraction and polarization. Experiments on interferences and colored rings.

ORGANIZATION AND CONDITION IN 1869.

The organization of the school, which is fixed by a Decree dated Nov. 30th, 1863, is of a military character. There is a staff of military officers in addition to, and quite separate from, the staff employed in the duties of instruction. The pupils wear uniform, which, however, is more civil than military in appearance. They are formed into four companies which together constitute a battalion; and, although they are not actually subject to the penal code of the army, the discipline maintained and the punishments inflicted are entirety military in character.

The military establishment remains exactly as it was in 1856, and consists of:

The Commandant, a General Officer, usually of the Artillery or the Engineers, at present a General of Artillery.

A Second Commandant, a colonel or lieutenant-colonel, chosen from among the former pupils of the school; at present a colonel of Engineers.

Three captains of Artillery and three captains of Engineers, as inspectors of studies, chosen also from former pupils of the school.

Six adjutants (adjudants), non-commissioned officers, usually such as have been recommended for promotion.

Slight changes have been made in the civil establishment; it now consists of:—

1. A Director of Studies, at present a colonel of Engineers.

2. Seventeen professors,12 (two additional professors for history) seventeen Répétiteurs and assistant Répétiteurs, and five drawing masters. Of the 17 professors, two are at present officers of Engineers, and one an officer of Artillery; the remainder are civilians, of whom three are members of the Academy of Sciences.

3. Five examiners for admission, and five for conducting the examinations at the school. All of these at present are civilians.

4. An administrative staff consisting of a treasurer, librarian, &c.; and a medical staff.

The general control or supervision of the school is vested, under the War Department, in four great boards or councils, viz.:—

1. A Board of Administration, composed of the Commandant, the Second Commandant, the Director of Studies, two professors, two captains of the military staff, and two members of the administrative staff. This board has the superintendence of all the financial business, and all the minutiæ of the internal administration of the school.

2. A Board of Discipline, consisting of the Second Commandant, the Director of Studies, three captains of the Military Staff, and one major of the army, selected from former pupils of the school.13 The duty of this board is to decide upon cases of misconduct.

3. A Board of Instruction, whose members are, the Commandant, the Second Commandant, the Director of Studies, the Examiners of Students, the Professors, and two captains of the Military Staff; and whose chief duty is to make recommendations relating to ameliorations in the studies and the programmes of admission and of instruction in the school to—

4. A Board of Improvement (Conseil de Perfectionnement), charged with the general control of the studies, and formed of:—

The delegates from the public departments are appointed by the respective ministers; the members of the Academy, the examiners, and the professors are selected by the Minister of War. The real management of the school, so far as the course of instruction is concerned, is in the hands of the Conseil de Perfectionnement; it will be seen that of the 18 members composing it more than half are entirely independent of the school, and are men of eminence in the various public services for which the instruction at the Polytechnic is preparatory. One of the chief duties of the Council is to see that the studies form a good preparation for those of the more special schools (Ecoles d’ Application) for the civil and military services; and the eminent character of its members gives great weight to the recommendations they make to the Minister of War.

The annual expenses of the school, as extracted from the Budget for 1869, are as follows:—

The chief changes that have been made in regard to the course of instruction since 1856, may be summarized as follows:

1. The more elementary portions of chemistry and physics which are required in the entrance examination, but which were formerly repeated at the school, have been omitted. The course of instruction in these subjects is now confined to the more advanced portions which do not enter into the entrance examination.

2. The mathematical courses have in some points been slightly curtailed, and the number of lectures in French literature and German have been diminished. By the modifications thus made in the programmes, it has been found possible to shorten the whole course of study and to increase the length of the vacations.

3. The subject of “Military Art,” which formerly entered into the final examination 133 is no longer taken into consideration in determining the order of merit of the pupils. In this respect the course of instruction may be said to have even less of a military character than formerly. Topographical drawing is the single military subject which has any influence on the final classification of the pupils, and this only to a very slight extent.

4. History has been introduced as a subject of instruction. This change was made in 1862. The course comprises general history, both ancient and modern, but more especially the history of France in modern times. The introduction of this subject appears to have arisen partly from a feeling that an acquaintance with history was a necessary element of a liberal education, and partly from a wish to meet, to some extent, an objection often made to the Polytechnic course of instruction, that it was too deficient in studies of a literary character. History, however, like military art, is evidently still regarded as a subject of only secondary importance and has no influence on the final classification.

5. A diminution has been made in the number of examinations during the course, by the suppression of one of the half-yearly examinations by the professors (interrogations générales, as distinct from the interrogations particulières) in each year. Further reference will be made to this point when speaking of the examinations at the school.

6. The importance of written exercises in determining the respective merits of the pupils has been decreased, apparently from the difficulty of establishing a security that such compositions were the unaided work of the individual.

The following table shows the present course of instruction during the two years, and the alterations which have been made in the number of lectures in each subject since 1856:—

* Introduced in 1862.

In connection with several of the courses, such as descriptive geometry, stereotomy, machinery, and architecture, much drawing is done by the pupils; hand sketches are taken of the diagrams shown in the lecture-room, and finished drawings are afterwards executed in the salles d’étude. In addition to this, 30 attendances of two or three hours each, distributed over the two years, are especially devoted to drawing more elaborate plans and elevations of architectural constructions and machinery. The practical applications of the theoretical instruction are limited to manipulations in the laboratory in connection with the course of lectures on chemistry and physics. Towards the close of the second year the pupils are also taken to visit some of the large manufacturing establishments in Paris, in order to gain a practical acquaintance with machinery.

All the subjects taught at the school are obligatory, but history and military art, as already stated, have no influence in determining the order of merit of the pupils in the final result.

The only instruction in practical military exercises, which is compulsory upon all, is that in drill. The pupils are exercised under arms in company drill, and are also occasionally drilled as a battalion; but very little importance is attached to this point—the only really military portion of their training. Drill goes on only for about three months in each year during the spring and summer, and even during this brief period only takes place about twice a week. By the regulations of the school the pupils should be exercised in musketry practice, but although they are armed with the Chassepot rifle this regulation is never carried out. Instruction is given in fencing and gymnastics, but attendance at both is voluntary, and scarcely more than half the pupils take advantage of it. Neither riding nor swimming are taught at the school.

The school year commences about the 1st of November, and terminates about the first of August. Some seven months of the year are given up to lectures and the ordinary routine of study; about two months are occupied with the annual examinations and private preparation for them; the remaining three months—August, September, and October—are the vacation. In addition to this long vacation, from eight to twelve days are allowed after the periodical examination, which takes place near the end of February, at the close of the first portion of each year’s study.

One peculiarity in the arrangements of the school is that the subjects of each year’s course are not all studied simultaneously. The lectures in the main subjects of instruction—those which, as a rule, present the most difficulty—are divided into courses which continue only during a certain portion of each year. Thus in the junior division, analysis and descriptive geometry are the mathematical subjects studied during the first three months, or three months and a half. The course in them is then concluded; an examination by the professors (interrogation générale) is held in these subjects, and they are laid aside for the remainder of the year, though they enter into the examination at the close of the year. Their place is then taken by a course of lectures in mechanics and geodesy. Similarly in the second year, analysis and mechanics are the subjects of the first course of lectures, at the termination of which there is an examination; and for the remainder of the year no further lectures in them are given, stereotomy and military art taking their place.

The subjects involving as a rule less difficulty—such as history, French literature, German, and drawing—are spread over the whole year, forming generally the evenings’ occupation.

THE SPECIAL MILITARY SCHOOLS OF FRANCE.

SCHOOL FOR ARTILLERY AND ENGINEERS
AT METZ.

HISTORY AND GENERAL DESCRIPTION,

The first French Artillery School was founded in the time of Louis XIV. (in 1679) at Douai. It had but a short existence: and it was only in 1720 (under the Regency,) when the Royal Regiment of Artillery received a new organization, that schools of theory were permanently founded in each of the seven towns where there were garrisons of artillery. But no academy properly so called was established before that founded by D’Argenson at La Fère, in 1756, with a staff of two professors of mathematics, and two of drawing. This was transferred to Bapaume, near the Flemish frontier, in 1766, re-transferred to La Fère, and suppressed, among other schools, at the beginning of the Revolution.

Of early Engineer Schools there was only one, the very distinguished School of Mézières, near the northern frontier. This was founded in 1749, also under the ministry of D’Argenson; Monge was a professor there; and it had a very high reputation down to its suppression in the Revolution.

When the wars of the Revolution broke out, Provisional Schools for giving a brief course of rapid instruction was established at Metz for the engineers, and at Chalons-sur-Marne for the artillery. These had to supply, at a great disadvantage, the officers needed for the protection of the invaded frontier.

It was intended originally that the Polytechnic, established in 1794, should send engineers direct to the army; but it was quickly found to be a better plan to allow the pupils destined for this service first to spend some little time at Metz; which thus, in October, 1795, became a School of Application for Engineers. The artillery pupils in like manner went to Châlons. This separate system of two Schools of Application continued till 1802, when the establishment at Châlons was united with that of Metz, and Metz became what it has since continued to be, the seat of the United School of Application for the two services. The Polytechnic students who 138 select the Artillerie de terre, Artillerie de mer, or the Génie militaire, enter here to receive the special and professional instruction deemed requisite to fit them for actual employment.

The students quitting the Polytechnic in the manner described in the account of that school, at the average age of twenty-one, enter the School of Application, with the provisional rank, the uniform, and the pay of sub-lieutenants (sous-lieutenants.) The ordinary term of residence is two years. Under special circumstances this may be shortened; and in case of illness or want of application individual students are occasionally retained for a third year. Each new body of students, each admission or promotion, is classified at the end of the first year, and the students composing it are arranged in order of merit in accordance with the reports of the professors, but without an examination; at the close of the second year they pass a final examination before the Board of Officers, and are definitively placed in the corps they have chosen, the artillery or engineers, according to the order of merit. They are allowed to count, as regards retirement from the service and towards military decorations, four year’s service on account of the two years passed at the Polytechnic School, and of the time passed in preparing for admission to it, reckoning from the day of their admission to the School of Application.

Metz is a fortified place on the Prussian frontier, the seat of war at the time of the school’s first foundation; it is on the line of railway to Mannheim, about thirty miles from the point where this branch diverges from the main line to Strasburg. The Moselle flows through the town, and is employed, with its little affluent the Seille, in the military defenses. The garrison numbers 10,000 men; there is an Arsenal, a school of Pyrotechny for the manufacture of rockets, two Regimental Schools, one of Artillery and the other of Engineers. The School of Application occupies buildings erected on the site, and partly the original buildings themselves, of a suppressed Benedictine monastery. Three sides of the cloistered monastic quadrangle are devoted to the offices, lecture-rooms, galleries and halls of study. A fourth, formerly the ancient church, is converted into a salle des manœuvres. There is an adjoining residence for the commandant; and a separate modern building, four stories in height, affords lodging to the young men.

The salle des manœuvres is a large area under a lofty roof, rising to the whole height of the buildings of the quadrangle; it contains artillery of various descriptions, mortars, field and siege guns placed as in a battery, and is amply large enough to allow cannon to be 139 moved and exercises performed when the state of the weather may make it desirable.

The amphitheaters or lecture rooms, much on the same system as those at the Polytechnic, are two in number, one for each of the two divisions. Officers of the artillery and engineers who are in garrison, are entitled, if they please, to attend the lectures, and other officers also may be admitted by permission.

The galleries, partly on the ground floor, partly on the first floor, contain very good collections of models of artillery, ancient and modern, of sets of small arms, of tools, of locks, barrels and other portions of muskets in various stages of the process of their manufacture, of specimens of carpentry and roofing, of minerals, of models of fortifications, bridges, coffer-dams, locks, &c.

The library on the first floor has an adjoining reading room; and near it is the examination room, of which further mention will be made. The three halls of study (salles d’étude) on the first floor are on a different plan from those of the Polytechnic, each one being large enough to accommodate a whole division (seventy students.) Three rooms are also provided for the professors to prepare their lectures in.

The barracks, on the opposite side of the open space used for drill and exercises, form a lofty and handsome building, entered by separate staircases, the ground-floor rooms of each being assigned to a servant, who undertakes to provide attendance for all the young men lodging in the rooms above. The rooms are comfortable, mostly double-bedded, the bedroom serving also as a sitting room, and a small adjoining closet being used for washing, &c. Twenty or twenty-two appear to be thus accommodated on each staircase; there are lodgings altogether for one hundred and forty-five. A certain number of the senior sub-lieutenants would, probably, on the arrival of the new cadets from the Polytechnic, be removed to lodge in the town.

There is a riding-school adjoining the court; stables, for thirty-three horses, which are kept for the use of the pupils, and lodgings for the attendants are provided in the neighborhood.

The mere description of the buildings shows at once that the system is different in many respects from that of the Polytechnic. Young men of twenty-one and twenty-two years of age, already holding provisional commissions in the service, receiving the pay and wearing the uniform of sub-lieutenants, are naturally allowed much greater freedom of action. They live, and partly also study, not in the halls of study, but in their own rooms; they take their 140 meals in the town, where they frequent the cafés and restaurants of their choice. The rappel summons them every morning to rise and attend a roll-call at half-past five or six; military exercises, riding, or interrogations, similar to the interrogations particulières, require the presence of a portion of the number, but the rest are free to return to their rooms. At ten they have to attend either the day’s lecture, followed by employment in the halls of study, till four o’clock P.M., or they proceed at once to the halls of study, and set to work on the drawings, designs, projects, &c., which are described hereafter in the account of the studies. From four to half-past five P.M.; drill, exercises, and riding occupy a portion of the number, probably those who were not called for in the morning. After half-past five they are left to themselves.

This ordinary routine of studies is interrupted in the summer months by the occurrence of expeditions for making surveys, and for measuring and sketching machines in manufactories. The young men are sent, two together, to survey (lever à boussole;) singly for the reconnaissance sketch (lever à vue ;) and generally, a certain number are distributed about a district not too large for an officer to make his round in it, and see each day that all are at work. The railways afford considerable facilities; the expeditions never occupy more than ten days at a time, but they may be extended as far as Strasburg.

There are no répétiteurs in the school; but the system of interrogations particulières is carried on; and an examination by the professor and an assistant professor takes place after, about, every eight or ten lectures.

THE STAFF AND GOVERNMENT.

The Staff of the Institution consists of—

The Commandant is taken alternately from the Artillery and Engineers, and the command lasts for five years only.

The Second in Command is always chosen from that arm of the service which does not supply the Commandant.

The inferior officers of each rank are taken in equal numbers from the two arms.

The Staff of Instructors is as follows:—

In all, nine Professors, four Assistant Professors, and one Drawing Master.

The School employs in addition an administrative staff, consisting of—

Clerks and draughtsmen are provided as required.

The school is under the general superintendence of two hoards or councils, the Superior Council and the Administrative Council.

The Superior Council consists of the General Commandant, as President, the Second in Command, the Director of Studies, as Vice-President; the Major of Artillery, and the Major of Engineers, as permanent members; two Captains of the Establishment, one of each arm; two Military Professors, one of each arm; and one Captain of the Establishment; these five last being all removable at the General Inspections.

The Superior Council has the duty of drawing up the programme of the studies of the year, of suggesting changes in the regulations relating both to studies and discipline, all subject to the approval of the Minister of War; of preparing at the end of the year the classified list of the students, drawn up according to their conduct and progress in their studies, and of pointing out to the Jury of Examiners any students who should go again through the courses 142 of the year, and stay in consequence an additional year at the school.

When questions relating to the instruction are brought before the Superior Council, the whole body of military professors attend and take part in the proceedings, and the Council is thus said to be constituted as a Board or Council of Instruction. Improvements are here suggested, and are subsequently submitted to the Jury of Examiners, and to the Minister of War; the value to be attached, in the system of marks or credits, to each particular course of study is determined; a statement is drawn up showing what printed works, models, &c., are wanted. The budget itself, to be submitted to the Minister of War, is finally drawn up by the Superior Council in its ordinary sittings.

The Administrative Council, composed of the Second in Command as President, the two Majors of Artillery and of Engineers, one Captain and one Military Professor, and the Treasurer as Secretary without the right of voting, takes cognizance of all the financial and other business matters of the school.

SUBJECTS AND METHOD OF STUDY.

The studies at Metz consist of topography and geodesy, including military drawing and surveying under special circumstances; field fortification, military art and legislation, permanent fortification, and the attack and defense of fortified places, accompanied by a sham siege, without, however, executing the details practically on the ground; architecture, as applicable to military buildings and fortifications; the theory and practice of construction, and artillery. The programmes of these studies are inserted at length in the Appendix.

The instruction is given principally (as at the Polytechnic) by means of a series of lectures, and the knowledge which the students have acquired is first directly tested by requiring them to execute various kinds of surveys of ground, either with or without the use of instruments; to prepare drawings of buildings, workshops, and machines in full detail (plan, elevation, and s) from the measurements they have recorded in their note-books or on their sketches, and to accompany such drawings with descriptive memoirs of all particulars and calculations that may be necessary to exhibit their purpose or efficiency; to draw up projects and lay out works of field and permanent fortification, or of those of attack or defense of a particular place on certain given data, or according to the nature of the ground; to design a military building, bridge, 143 machine, or piece of ordnance, accompanied by estimates and descriptive memoirs, showing in what manner the instructions and conditions under which it was drawn up have been complied with; and to prepare a project for the amelioration of the works of defense of a specified portion of a fortified place known to be defective in some respects.

The instruction during the first year’s residence is common to the two arms; and the time is appropriated in the following manner, namely:—

The sous-lieutenants who complete their first year’s work are allowed nearly a month’s vacation during November.

The instruction given to the Artillery and Engineers during the second year’s residence is not entirely the same, as will be seen by comparing the accompanying table of the year’s study:—

We should not omit to state that there is a short course on the Veterinary Art.

The lectures, as before said, begin at 10 A.M., and they last usually an hour and a half, and are followed by work in the halls of study. It would appear, however, that very frequently the day’s occupation consists simply of work in the halls of study (or occasionally out of the school buildings, when the students are sent on some excursion;) and, accordingly, in giving the account of the studies, a day or day’s work will sometimes mean a lecture followed by drawing or other employment, sometimes this drawing or other employment without any lecture preceding. Taking a general 144 average, the proportion appears to be about two lectures to five séances, i.e., sittings without lectures.

The system will be better understood by referring to the accompanying tables, which are translated from the Project for the Employment of Time for the year 1851–2, submitted for the approval of the Minister of War. The dates in the first column indicate the days of the commencement of each particular study. The school year, it should be said, begins on the 1st of December.

EMPLOYMENT OF TIME FOR THE YEARS 1851–1852.

EMPLOYMENT OF TIME FOR THE YEAR 1851–1852.

EXAMINATION AND CLASSIFICATION.

FINAL EXAMINATION.

About six weeks of free or voluntary study is allowed, immediately prior to the Final Examination, for the sub-lieutenants to prepare for their last effort.

The examination which takes place prior to their leaving the School of Application, is entirely conducted by a board of six officers, under the presidency of a general officer alternately of the artillery or engineers, the remaining members of the board consisting of a general officer of each corps and three field officers of these corps; the last three being specially charged with the duty of examining. It takes place in a room set apart for the purpose, with a small interior room in connection with it, into which the members of the board retire to deliberate at the end of each student’s examination. The jury assembles each year at the period fixed by the minister of war.

The three examining members conduct the examination of the students in three different branches of study; the first more particularly relating to artillery science, the second to engineering science, and the third to mechanical science in its connection with the art of war. The whole of the students who are to leave the school are first examined in such one or other of these branches of study as may be determined on.

The student under examination is specially questioned by the examining officer in his subject, and occasionally by the president or any other member of the board that may wish to do so, for three-quarters of an hour. As soon as the examination of the student has been concluded, the board retire to the adjoining room and compare their notes of the credits they have severally awarded to the student under examination, and they also examine his drawings, sketches, and memoirs relating to the subjects on which he has been questioned, and prepared during his two years of residence in the school. They severally note the credits to which they consider him to be entitled for them, and adopt the general mean.

As soon as the examination of the whole of the students in this particular study has been finished, the examination in the next branch is commenced, so that five or six days elapse between the first and second examinations of the same student; and the same interval of time occurs between the second and third examinations.

The credit allotted to each student by the board of examiners represents, on the scale of 0 to 20, the manner in which he has replied to the questions, or executed the drawings, sketches, memoirs, &c., belonging to each course. The importance attached to each particular branch of study is estimated very nearly by the amount of time allowed for its execution divided by 20; and the definitive marks which each student obtains for that branch of study is obtained from the products of the numbers respectively representing 147 the credit for answering, and that for the importance of the subjects on which he has been examined.

The final classification of the order of merit, in each arm of the service, is arranged after a comparison of the total of the marks obtained by each student. This total is the sum of the definitive marks gained by each student in the sciences bearing on artillery, engineering, and mechanics in connection with the art of war, for the talent displayed in drawing, sketching, and writing memoirs, and for skill in practical exercises, as determined by the results of the examination conducted by the jury of examiners, added to the marks due to the previous classification in the school, with the weight or influence equal to one-third of that allowed for the examination by the jury.

The co-efficients of influence for the present year are—

So that the examination conducted by the jury of examiners exercises an influence on the position of the students very nearly approaching to two-thirds of the whole amount.

It is this final classification which determines their seniority in the respective services. We were permitted to be present during the examination, which was entirely oral, of two of the sous-lieutenants, before the jury of examiners.

The questions were replied to with great fluency and readiness, but it seemed to us that the examination was somewhat limited for the object in view, viz., that of awarding a credit representing the progress which each student had made in the particular science on which he had been questioned, especially as that credit would have very great weight in determining the candidate’s future position.14

On quitting the School of Application at Metz, the sub-lieutenants of artillery and engineers respectively join the regiments, to which they are then definitely assigned as second lieutenants, and continue to be employed in doing duty, and in receiving practical instruction with them, until they are promoted.

SUBSEQUENT INSTRUCTION AND EMPLOYMENT.

The lieutenants of the artillery are employed on all duties that will tend to make them efficient artillery officers, and fully acquainted with all details connected with the drill, practice, and manœuvres of the artillery, and also with the interior economy and discipline of a regiment of artillery.

After the officers of artillery are promoted to the rank of second captain, but not before, they are detached from their regiments and successively sent into the various arsenals, cannon foundries, powder mills, and small arm manufactories, pyrotechnic establishments, and workshops, in order that they may become practically acquainted with the whole of the processes connected with the manufacture and supply of artillery, rockets, small arms, powder, material of all kinds, tools, &c., and also with the construction and repair of the buildings and factories required for these purposes. Sometimes they are employed as assistants in these establishments. The inspectors of the arms of regiments are selected from among those who have become acquainted with the manufacture of small arms.

When promoted to first captains they again rejoin their regiments, so that they may not lose the qualifications and knowledge required from a good practical artillery officer.

Field-officers of artillery are employed as superintendents and directors, and captains as sub-directors, of the important works intrusted to their arm.

In time of war, the officers of artillery have the construction of their own batteries, and the direction of the ordnance in battles and sieges, together with the formation of movable bridges and passages by boats.

It must be noticed, in contradistinction to the practice which prevails in England, that the artillery and engineer services manufacture their own tools.

The young engineer officers are employed with the men of their regiments, and with them pass through courses of practical instruction in the field, in sapping, mining, field fortification, sham-sieges, 149 bridges, and castrametation. During this practical instruction one of the lieutenants belonging to each company is always present, and the captain of the company visits the work once in the course of the day.

The duties of the officers of engineers in time of peace are the construction, preservation, and repairs of fortresses and military buildings, and the command and instruction of the engineer soldiers.

In time of war, the officers of engineers are intrusted with the construction of works of permanent fortification, of the general works in the attack and defense of fortresses, and the reconnaissance connected therewith.

They may also be charged—

With the construction of such works of field fortifications as the commander-in-chief or the generals of division consider necessary; such as épaulments, trenches, redoubts, forts, blockhouses, bridgeheads, intrenched camps, as well as the opening of communications, the establishment of bridges resting on fixed supports, and the formation and destruction of roads.

After the officers of engineers have been promoted to the rank of second captain, and not before, they are mostly employed apart from their regiments, on the état major of the engineers in fortified towns and places, either in charge of the existing military buildings and fortifications, or with the duty of carrying on, or assisting to carry on, such new works as are in course of construction from time to time.

We have already stated that by the law in France one-third of the officers of the army is obtained from the military schools; one-third from the non-commissioned officers who have been raised to that grade from the ranks; while the remaining third is placed at the disposal of the supreme executive power. As regards the artillery and engineers this last third is in actual practice obtained, like the first third part, from the Polytechnic School, so that only one-third of the officers of those arms are promoted from among the non-commissioned officers, and these seldom rise above the rank of captain. Much attention is, however, paid to the improvement of the education of these latter officers, and we found that four officers of engineers and one officer of artillery so promoted were, by order of the minister of war, on the recommendation of the inspectors-general, passing through the School of Application at Metz, the course of instruction for them being modified on their account. And it was confidently expected that a large number of those officers who 150 had been promoted in this way during the war would be ordered to the School of Application at Metz.

We should not omit to mention that occasional exchanges of service take place, during the first year of residence at Metz, among the pupils destined for the artillery, and those destined for the engineers.

The pay of officers of the artillery and of the engineers is the same. A small additional allowance is granted to officers of artillery when mounted.

REGIMENTAL SCHOOLS.

ARTILLERY REGIMENTAL SCHOOLS.

There are ten regimental artillery schools established in places or towns that are usually garrisoned by the troops of this arm, and one of these schools exists at Metz.

ENGINEER REGIMENTAL SCHOOLS.

The soldiers of the engineers appear to be very well taught in their regimental schools, of which there are three, one for each regiment, established at Metz, Arras, and Montpellier, where the regiments are usually in garrison. The strength of each regiment is 4,500 men.

The instruction given in these schools has for its object to afford, to its full extent, to the officers, sous-officiers, and soldiers of the engineers, the requisite theoretical and practical knowledge to enable them satisfactorily to fulfill the duties of their various ranks, and to qualify them for promotion to higher rank.

It is so regulated that at the end of the first year the men have learnt the nature of the service and duties of a soldier; and that at the close of the second year, the practiced sapper is cognizant of mining, and the practical miner is acquainted with sapping.

In the lowest classes the men begin with learning to read and write; this if followed by arithmetic, grammar, writing from dictation, and composition. The next subjects are special mathematics, landscape, plan, topographical and architectural drawing. We attended a class in which a corporal of sappers was explaining to the mathematical teacher (a civilian) the theory of the inclined plane, and we saw a large number of their drawings, topographical and architectural, many of which were very well executed.

The theoretical instruction is given between the months of November and March, the practical instruction in the field, (already noticed) occupies the rest of the year. The combined courses are completed in two years.

REGULATIONS AND PROGRAMMES OF INSTRUCTION
OF THE
IMPERIAL SCHOOL OF APPLICATION FOR THE ARTILLERY AND ENGINEERS AT METZ.

(Abridged.)

I. POLICE REGULATIONS.

The chief Regulations for the Police of the Establishment are as follows:—

I. Barracks.—The Students are lodged in Barracks in the School, under the command of a Captain of the Staff, with the title of Commandant of the Quarter. They take their meals, however, out of the Barracks, in the town. They are allowed free egress and ingress from and to their Barracks, from the call at 6 in the morning to 10 at night, excepting during the hours devoted to lectures and the studies in the rooms. During these hours they must give special notice o£ their times of going out and coming in.

II. Organization into Brigades and Sections.—Each Division is arranged in Brigades of thirty Students at the utmost, and each Brigade in two s. The Students of Artillery and those of the Engineers constitute, as far as possible, separate Brigades. A Captain of the Staff is attached to each Brigade for its superintendence. The students in these Brigades and Sections are arranged in the order of merit which they held on entrance, and the first Student on the list of each Brigade and of each of a Brigade is called its Chief. This arrangement is preserved at their messes, which are held at the Restaurateurs’, each of fifteen having its own table, and its chief being the head of the mess. Private bills or private additions to the mess are forbidden, the maximum price for the daily fare being fixed by the Commandant of the School.

III. Conduct of the Students.—All games of chance are forbidden; and any debts discovered are punished. If a Student continues long without paying such, he is reported to the Minister of War.

IV. Inspection of Work Done Within the House.—No work or drawing may be done out of the rooms of study, except in cases of illness.

All works to be executed by the Students are considered as service ordered to be done, which must be completed at the hours and within the period fixed in the order of the day. Students who are in arrears of work at the end of their first year are required to finish them during the time of vacation.

V. Superintendence of out-of-door Work.—After describing facilities afforded to the Students for working in the country, and stating minutely the method to be followed, the directions add that “on bringing back their plans, Students must present their sketches, and all the notes taken by them, in their rough state, to the Officer of the Staff intrusted to inspect them. They can not begin to put their work into shape till this Officer’s visa has been affixed to the sketches, notes,” &c.

VI. Vacation.—There is one vacation at the end of the first year. Any class, or any single student, under punishment, may be deprived of this. Any work to which the Professor gives a mark below 7, must be considered incomplete, and to be done again. Students are kept up in vacation to finish their work; but if it is done within fifteen days, and marked by the Professor’s visa, they are allowed to go away for the rest of the vacation.

Young Officers, after their final examination, are subject to all the Regulations of the School, down to the moment of their leaving the town.

II. REGULATIONS FOR ESTIMATING THE VALUE OF THE WORK EXECUTED.

The time devoted to each of the courses in the School, to the works of every kind which belong to it, to the exercises, drill, theoretical instructions, &c., is fixed in accordance with programmes approved by the Minister of War; and the Table similar to that given at pages 180–181, exhibiting the employment, is each year submitted for his approbation by the Superior Council of the School.

Every kind of work, such as the out-door operations, sketches, drawings, memoirs, calculations, interrogations, manipulations, manœuvres, drill, &c., is valued by the Professor or Officer of the Staff charged with its direction, by the product of two numbers, one representing the merit of its execution, and the other the importance of the work.

The numbers representing the merit of the execution or instruction are regulated by the scale of 0 to 20, as at the Polytechnic School.

The co-efficient of importance is found by dividing the number representing the maximum value allowed for the execution of any work by 20, the maximum credit for merit; and the number representing the maximum value, allowed for the execution of any work has reference to all the circumstances bearing upon its execution. It is regulated by the number of hours appropriated to its execution; and in estimating this number of hours, regard is had, not only to the time occupied in making the drawing, but also to that which is necessary for the calculations, essays, and sketches indispensable to its execution. The lectures are reckoned at one and a half hours, and the sittings in the Halls of Study at four and a half hours.

The number of hours inserted in the Table giving the distribution of the time employed, being insufficient for the composition of the memoirs, specifications, estimates, &c., the value given for this kind of work, of which a great part is performed out of the Halls of Study, is fixed at twice the number of hours inserted in the Table showing the distribution of the time employed.

The interrogations are the subject of a special credit, the maximum being equal to the number of hours devoted to the lectures, multiplied by one and a half hour, the length of each lecture.

The credit given for a work performed outside the school is divided into two parts: one, equal to one-third of the total credit, is in the hands of the Officer charged with the superintendence of the work, who estimates the zeal and aptitude of the student; the other, equal to two-thirds, is applied by the Professor, and given according to the merit of the work.

The sum of the credits, given for work of all kinds in a course of study, forms the maximum credit for the course.

The method of fixing the credit for the execution of works, according to the time devoted to them, is equally applicable to the exercises, practice, and drill.

When the time granted for the execution of any work has expired, the Director of Studies sends this work to the Professor for his examination, who establishes the number or credit, showing its importance, and returns it to the Director of Studies.

Every work which has been finished and examined, is marked by the Professor by a number representing its merit, which number may be fractional.

This is multiplied by the number representing its importance, and the nearest whole number resulting from this product expresses the value of the examined work.

Every unfinished work receives a provisional value, and is then returned to the person executing it, and as soon as it has been completed a second evaluation is made, but only two-thirds of the difference between the first and second evaluations is added to the first; the same principle is applied to the works which have been valued below seven, or to those which have been amended or recommenced.

Every work which has not been executed by the student is marked 0; but the grounds for its non-execution are placed before the Jury of Examination.

In the event of two papers being so similar that it is evident one must have been copied from the other, and that it is not possible to decide which has been copied from the other, both are marked 0.

And on the other hand, if it is proved that there was no complicity between the authors of the two papers, the copied paper is the only one canceled.

At the end of each year’s study, the Council of the School makes a classification of the students of the two divisions.

Each of these classifications is formed of the following elements:—

1st. Notes of conduct given by the General commanding and the Colonel Second in Command.

2nd. Notes of appreciation given by the General Commanding, and the Colonel Second in Command, and by the Officers of the Staff of the School.

3rd. Tables of credits given by two Field Officers of the Artillery and Engineers on the theoretical and practical instruction with which they are charged.

4th. Tables of credits given by each Professor for the works of all kinds, interrogations, &c., of his course.

The classification of the first year comprehends all the works, drill, and practice, executed during the first year, which have been valued, as well as the notes of appreciation and of conduct.

The number appropriated to these notes at the end of the first year is equal to the moiety of the total number allowed for the two years of study.

The classification of the students of the second year presents the reunion of the works executed by them since their entrance into the school.

The maximum number of credits appropriated to all the Officers of the Staff, as a note of appreciation, is equal to one-sixth of the total of all the courses taken together.

The same number, divided into two equal parts, is assigned to the notes of appreciation given by the General commanding and the Second in Command.

Lastly, the notes of conduct given by the General commanding and the Second in Command form one-fiftieth of the total value.

For the classification of each division the Director of Studies abstracts into a Table, for each arm, all the elements which should enter into this classification. Below the name of each student are inserted all the credits which belong to him, and the total, reduced in the ratio of the maximum 20, is the definitive number of the classification of each student.

The Director of Studies appends to these Tables a report containing everything which affords a means of estimating the work, the conduct of each 154 student, the delays, and the causes, &c. In giving the names of the students whose credits are less than 7, he proposes, conformably with the Regulations, the measures that should be taken with regard to them.

The Superior Council of the School being assembled, the different Tables furnished by the Professors and by the Officers of the Staff, as well as those in which they are summed up, are collated, and the list of classifications for each division and for each arm is fixed separately, with the definitive numbers representing the credits.

These classified lists indicate for each arm the new rank of the Students, their rank at admission to the School of Application and of passage to the first division, the sum of the values for the works executed by them, and all the elements which would tend to enable a proper judgment to be formed of their merits and conduct.

The Superior Council adds to it, if there be any necessity for it, notes, exposing the grounds which have contributed to the principal alterations in the relative position of the Student, and points out those whose credit is less than 7, as well as those who by their bad conduct deserve to become the object of exceptional measures.

Examination for Leaving.

Each year the General commanding the School determines by lot, at least one month in advance, the order in which the examinations for the promotions in the Artillery and Engineers are to take place. The Students belonging to the same arm can change among themselves, but eight days after the lots have been drawn the list of the order of examination is definitely closed. The General commanding the School makes known at the same period the order of the examinations and the division of the subjects between these examinations.

The General commanding the School places before the General of Division, President of the Jury of Examination, the following:—

1st. The division of the subjects between the three examinations.

2nd. The order of examination of the Arms, and of the students of each Arm.

3rd. The provisional classification of the students of the first division made by the Superior Council.

4th. The particular reports relating to each student made by the General commanding the School.

5th. The list of the propositions made by the Superior Council and the proceedings of the sitting at which it was agreed to.

6th. The classification of the Students of the second Division.

7th. Tables of questions established for each course.

8th. The abstracts of the sittings of the Superior Council held since the last examination.

The Student Sub-lieutenants are successively examined in all the branches composing the theoretical and practical instruction of the School. The theoretical knowledge is grouped in three series, each of which is the object of a particular trial.

The drill and practice are executed in the presence of the Jury, who cause the command to be given to the Sub-lieutenant, in order to satisfy themselves of the amount of their instruction, and to assign marks of merit to them individually.

The subjects of the three examinations are divided in the following manner:

First. Examination, made by the Field Officer of Artillery in the—

Second. Examination, held by the Field Officer of Engineers.

Third. Examination, held by the third Examiner, taken either from the Artillery or Engineers, in the—

Every Student, on presenting himself before the Examiners, submits for their approbation the drawings and manuscripts relating to the subjects on which the examination is to bear. Independent of the questions which are placed before him by the Examiners, the Student Sub-lieutenant must reply to any objections or questions which the members of the Jury may think fit to address to him.

The German Master directly questions the Students, if the Jury wish it. The Professors or their Assistants must be present at the examinations relating to their course.

As soon as the examination is ended, the members of the Jury retire to an adjoining room with closed doors, to determine on the amount of marks to be given to the Student examined.

When the trials of all kinds are finished, the Jury proceed to the definitive classification of the Students belonging to each arm. In making this classification, regard is had to the following considerations:—

1st. Each examination has a co-efficient of importance equal to the sum of all the different courses which are included in it.

2nd. The co-efficient of importance for drawing is equal to the 1/20 of the sum of the co-efficients of the three examinations.

3rd. The co-efficient of importance of the practice, drill, &c., is, as for the courses, the sum of the co-efficients appropriated to the works taught in the School.

By multiplying the co-efficients of importance by the mean number of marks of merit obtained by the Students in the different examinations, the definitive credit which must be assigned to each Student in the Table of Classification is obtained.

The classification of the School enters into the definitive classification for a value equal to one-third of the total number of the three examinations, without comprising the valuation of the drawings; this value is added to the credits determined above.

The Jury give an account of the proceedings of the examinations in a “procès-verbal” addressed to the Minister by the General acting as President.

III. PROGRAMME OF THE ARTILLERY COURSE.

FIRST PART.—INTRODUCTION.

Twenty-six Lectures common to Students of both Arms.

First Lecture.—(1.) Definition of the word Artillery. Material, personnel, science. Object and division of the course.

FIRST SECTION.—EFFECTS OF POWDER.

Ideas on the origin of powder and its use in fire-arms; mealed or pulverized powder; powder in grain. General conditions which powder ought to satisfy; action of each of its component parts. Proportion of component parts used in France. Fulmi-ligneux.

Considerations on the physical properties of powder. Size of the grains expressed by the number of grains to the gramme. Density of the grains and specific density of the powder; circumstances causing them to vary. Effects of damp upon powder.

Second Lecture.—(2.) Combustion of powder. Different modes of ignition of powder. Research respecting the laws of its combustion, process of observation employed, laws discovered. Influence of the density, the composition, the mode of manufacture, the damp, the tension and temperature of the surrounding gases.

Combustion of the grains of powder. Calculation applied to the spherical grain. The formula is applicable to the irregular grains of ordinary powder.

Calculation of the density of the gases of powder in a fixed space, on the hypothesis of a simultaneous ignition of the grains. Discussion of the formula obtained; influence of the density of the grains, of the duration of their combustion and of the space in which the powder is inclosed.

Inquiry into the rapidity of ignition of charges of powder. Experiments made upon trains of powder, and upon gun-barrels filled with powder. Conclusions drawn from the results obtained.

Third Lecture.—(3.) Calculation of the density of the gases of the powder on the hypothesis of successive ignition.

Results of the application of the formula to charges of a spherical and a truncated form.

Tension of the gases of powder. Impossibility of determining it by considerations of a purely theoretical nature. Experimental solution of this question. Experiments by Rumfort; description of his apparatus. Results obtained. Formula representing them. Observations on these results.

Fourth Lecture.—(4.) Effects of powder in a fixed space.

Hollow projectiles. The readiest bursting of a hollow sphere takes place in the direction of the plane of a great circle. Determination of the minimum bursting charge; law by which this charge varies with the thickness of the envelope. Influence of the fuse-hole of hollow projectiles; weakening of the envelope of the shell, diminution of the charge; loss of gas, increase of the charge. Effects of the shock of the exploding gases; means of estimating it. Influence of the vivacity of the powder in burning. Number and rapidity of the explosions.

Hollow cylinders burst more easily longitudinally than transversely. Consequences 157 of this principle relatively to the employment of a fibrous metal for the manufacture of arms. Thickness necessary to resist bursting.

Fifth Lecture.—(5.) Effects of powder in cannon.

Analytical theory of the effects of powder in cannon.

Equation of the problem. General expressions of the quantity of force exercised by the expansion of the gases,—of the density of the different s of gas and of their tension. Differential equations of the motion of the gases, of the projectile, and of the gun. Equation of condition leading to the establishment of the general formula which determines the position of a stratum of gas in the terms of the function of its original position, and of the other data of the question. General relations between the velocity of the projectile and that of the gun.

Density of the stratum of gas at a given moment. Position of the stratum which has a maximum density.

Sixth Lecture.—(6.) Approximative solution applicable to the cases ordinarily met with in practice. Hypothesis relating to the velocity and the tension of different strata of gas.

Relations between the velocity of the projectile and that of the gun. Approximate expression of the amount of force due to the expansion of the gases; line to be followed in the execution of the arithmetical calculations. Formula serving to determine the velocity of the projectile. General considerations on the state of the gases of powder during the burning of the charge. Influence of the motions of the projectile and of the bottom of the bore on the distribution of the gases at each instant. Influence of the successive generation of the gases combined with the enlargement of the space which incloses them on their density throughout the whole duration of the phenomenon.

Seventh Lecture.—(7.) Influence of the vent and of the windage of the projectile on the effects of powder in cannon.

Determination of the loss of velocity occasioned by the windage of the projectile. Influence of the weight of the piece upon the velocity of the projectile. Influence of the weight of the projectile on tension of the gases and upon the velocities of the two bodies set in motion. Influence of the weight of the charge of powder. Charge giving the maximum of velocity. Influence of the size and density of the grains of the powder as well as other circumstances which cause a variation in the law of generation of the gases. Advantage of very rapid combustion in short pieces and of slower combustion in long ones.

Eighth Lecture.—(8.) Influence of the length of bore; circumstances which modify it; length corresponding to the maximum of velocity. Comparison of the quantities of motion of the projectile and of the gun. Trial of a formula fitted to represent their relation. Determination of this relation with the help of the balistic pendulum.

Mean pressure exercised on the projectile during its passage through the bore. Injuries produced in guns by firing; enlargement of metal and cracks; lodgment and percussion of the projectile.

Different effects of the percussion; means tried to prevent injuries (in general.) Considerations on the metals employed in the manufacture of ordnance. Charging with elongated cartridge; use of wooden bottoms and wads.

Ninth Lecture.—(9.) Examination of the proper means for measuring the effects of powder. Eprouvettes of different sorts. Experimental processes 158 founded on the measure of the velocity of the projectile. Grobert’s rotatory machine. Process of Colonel Debooz. Process based on the employment of an electric current. Method by ranges (mentioned here by way of note.)

Balistic pendulum. Pendulum of Robins, of d’Arcy, of Hutton. Improvements introduced in France into the construction of these apparatus. Description of the pendulums in use at the present day; cannon pendulum; musket pendulum.

Tenth Lecture.—(10.) Analytical theory of the balistic pendulum.

Eleventh Lecture.—(11.) Examination of the effects of the recoil upon guns and their carriages. The question may be considered as resolving itself into two others.

Twelfth Lecture.—(12.) Discussion of points relating to the percussion of the carriage upon its supports, and to the force of the recoil. Influence of the elevation of the line of fire; of the inclination of the ground or of the platform; of the length of the carriage in proportion to its height and of the friction which results from the contact of the trail with the ground. Velocity of recoil of the collective apparatus. Determination of the extent of the recoil on a given ground. Recoil of the different pieces of ordnance in use. Case in which the forepart of the carriage has a tendency to be lifted up; velocity of this motion; determination of the effect resulting from it.

Thirteenth Lecture.—(13.)

Effect of the elasticity of the different parts of the apparatus. It diminishes the wear of the parts struck, and renders it necessary to take into account the velocity of the parts striking.

Fourteenth Lecture.—(14.) Effects of powder in mines. Historical notices. Dimensions of the boxes containing the powder. Considerations on the effects of the expansion of the gases in an indefinite or limited compressible medium.

Definitions having reference to craters and chambers of mines. Ordinary charge of the chamber. The old rule for miners; its entire alteration. Table 159 relating to different kinds of medium. Overcharged chamber. Overcharged chamber or “camouflet.” Limit of the effects of compression which result from the action of the chambers. Use of gun cotton. Considerations on the effects of the petard. Dimensions of the cavity reserved for the powder. Means employed or proposed to diminish the charge of powder proportioned to a given effect.

SECOND SECTION.—MOTION OF PROJECTILES IN SPACE.

Fifteenth Lecture.—(15.) Science of projectiles. Historical notices. Utility of an acquaintance with the laws of the motion of projectiles in a vacuum. Definitions relating to the trajectory. Differential equations of the motion in vacuo. Equation of the trajectory. Inclination of its elements. Velocity of the projectile at any one point. Duration of its passage. Determination of the range and of the angle of greatest range. Relations between the ranges; the initial velocities; and the angles of projection. Examination of the cases where the theory of the parabola is applicable.

Preliminary ideas on the resistance of fluids; difficulties inherent in this question. Approximative formula of the resistance, established by the help of the principle of active forces; circumstances not taken into consideration by it.

Sixteenth Lecture.—(16.) Experiments relating to the determination of the resistance of the air.

Seventeenth Lecture.—(17.) Theory of the motion of projectiles in the air. Differential equations of the motion. Hypothesis on the relation of the element of the trajectory to its projection. Calculations based on this hypothesis, and leading to the final equation of the arc of the trajectory. Inclination of the element of the trajectory. Velocity of the projectile at a given point. Duration of the passage.

Eighteenth Lecture.—(18.) Examination of the functions employed in the formulas of the science of projectiles. Formation of the balistic co-efficient, and the series contained in the functions. Relations of the series and the functions to each other. Arithmetical tables designed to give their values. Determination of the relation of an arc of the trajectory to its projection. Error resulting from the introduction of the constant relation in balistic calculations.

Nineteenth Lecture.—(19.) Application of balistic theories to the movement of projectiles thrown at great angles. Analysis of the trajectory, and determination of all the circumstances of the movement. Trajectory of shells considered as a single arc. Solution of several problems involved in this hypothesis. Determination of the range. Velocity corresponding to a given range 160 and angle of projection. Angle of projection corresponding to a known initial velocity and range. Angle of greatest range. Variation of the velocity of the projectile during the whole of its passage. Limit of velocity of projectiles falling vertically in the air.

Twentieth Lecture.—(20.) Application of balistic theories to the motion of projectiles thrown at low angles. Case where the relation of the arc to its projection can be supposed sensibly equal to unity. Problems relative to direct fire; distinction established between the angle of projection and the angle of fire. In ordinary cases in practice the angle of fire is very nearly independent of the height of the object aimed at. Relations between the angle of projection, the angle of elevation of the object aimed at, and the angle of descent. Problems relating to plunging fire. (Ricochet fire.) Determination of the initial velocity and the angle of projection for a projectile which has to pass, firstly, through two given points; secondly, through one given point, the trajectory having at this point a known direction. Case of practical impossibility.

Twenty-first Lecture.—(21.) Relations between the velocities, the spaces traversed, and the durations of passage in the rectilinear movement of projectiles. They are applicable to direct fire, and are independent of the function of the velocity which enters into the expression of the resistance of the air. Case where the resistance of the air can be supposed proportional to the square of the velocity. Establishment of balistic formulas in this hypothesis. Application of the formulas to the resolution of one of the problems connected with a plunging fire. Comparison of the results obtained with those arrived at by the use of general formulas. Indication of methods applicable to the resolution of several questions in projectiles.

Twenty-second Lecture.—(22.) Examination of disturbing causes which influence the motion of projectiles.

THIRD SECTION.—MOTION OF CARRIAGES.

Twenty-third Lecture.—(23.) Importance of the question. Preliminary ideas. Resistance due to the motion of a carriage and determination of the effort necessary for drawing it in the case of uniform motion. Two-wheeled carriage on level ground; the effort of draught in a direction parallel to the ground; first, resistance referable to the friction of the wheels on the axle; secondly, resistance referable to their revolution upon the ground. Influence of the weight of 161 the carriage. Advantage of large wheels over small ones, demonstrated in the two cases of a yielding soil and a hard soil scattered over with obstacles. Expression of the power of draught necessary to overcome the two resistances united.

Twenty-fourth Lecture.—(24.) General expressions of the effort of draught necessary for two-wheeled and four-wheeled carriages; case of a locked wheel. Influence of the direction of the traces and of the inclination of the ground upon the draught. Advantage of rolling over dragging for the transport of burdens. Examination of resistances which are developed in the passage from repose to motion. Considerations on the position of the fillet in the box, and determination of the co-efficient of friction for the case of the revolution of the wheel about the axle.

Influence of the length of the nave on the frictions when the axle is thrown out of a horizontal position.

Twenty-fifth Lecture.—(25.) Turning of carriages considered successively in the case of two-wheeled and four-wheeled carriages. Center and angle of the turn in four-wheeled carriages. Calculations of the angle of the turn and of the space required by the carriage to execute a half turn. Examination of the dimensions of the carriage which influence the angle of the turn. Diameter of the fore-wheels and height of the body of the carriage; distance between the wheels and breadth of the body of the carriage; position of the point of reunion of its fore and hind parts. Examination of the circumstances favorable or unfavorable to the action of the horse. Relation between the forces to which he is subjected, and the pressure of his feet on the ground. Sliding of the feet; influence of the weight of the animal; of the co-efficient of friction; and of the direction of the traces. Lifting of the fore-hand; influence of the weight of the horse, and of the increased distance between the points on which he rests; of the position of his center of gravity; and of the direction of the traces.

Twenty-sixth Lecture.—(26.) Considerations on the mode of action of the draught-horse. Effect of his weight, and of the inclination of the traces. Effort of draught of which the horse is capable, both momentarily and continuously; results of experiments. Composition of artillery harness. Harness à limonière (with shafts and cross-bar,) or on the French system; on the German system, with pole and support. Use and discontinuance of swing bars. Arrangement of the traces. General arrangement of harness. Bât-saddle.

SECOND PART.

CLASSIFIED ACCOUNT OF SMALL ARMS AND OF ARTILLERY MATERIAL.

Twenty Lectures, of which Fourteen are common to the Students of both Arms and Six confined to Artillery Students.

FIRST SECTION.—SMALL ARMS.

Twenty-seventh Lecture.—(1.) Classification of small arms. Arms not fire-arms. Classification of hand-weapons. Considerations on the profile and outline of cutting weapons. Effect of the curve. Division of the mass. Form of the hilt.

Considerations on the profile and outline of thrusting weapons.

Position of the center of gravity; form of the point. Description of arms other than fire-arms now in use. Sabres and swords. General ideas respecting their component parts; blade, hilt, and scabbard. Regimental arms. Infantry sword. Sword-bayonet of the artillery and chasseurs, cavalry sword; peculiar requisites. Sword of cavalry of reserve, of cavalry of the line, and of light cavalry. Horse artillery sword.

Officers’ and non-commissioned officers’ arms. Cavalry lance. Camping axe. Side-arms in use in the navy. Sword, pike, boarding-axe, dirk.

Defensive armor. Cuirassiers and carabineers’ cuirasses. Cuirass and helmet of the sapper.

Twenty-eighth Lecture.—(2.) Fire-arms. Historical notices. First attempts in fire-arms. Hand cannons. Arquebuses, culverines, &c. Poitrinal, matchlock, firelock, pistol, and blunderbuss.

Means employed successively for loading and ignition of the charge. Twisted match, wheel-lock, flint-lock, percussion-lock, (the two last mentioned here by way of note.) Classified account of fire-arms now in use. Muskets. Considerations on the weight and principal dimensions of muskets. Detailed description of the infantry musket. Action of the flint and the percussion lock.

Twenty-ninth Lecture.—(3.) Comparison of the flint and the percussion musket. Voltigeur’s, dragoon’s, and double-barreled musket. Gendarmerie and cavalry carbine. Cavalry and gendarmerie pistol. Arms in which precision of aim is studied. Means employed to prevent the deviations caused by the windage of the projectiles and their rotatory-movement in the air. Diminution and suppression of the windage; straight grooves in the barrel, spiral grooves, rifled arms. Rotation of the ball about its axis of flight.

Principles of arrangement of rifled arms. Charge of powder and inclination of the grooves; two modes of solution, powerful charge and long spiral, weak charge and short spiral. Length of the barrel: conditions which determine it; number and form of the grooves.

Thirtieth Lecture.—(4.) Loading of rifled arms; ramming the ball home; loading at the breech. Different methods tried. Loading with a flattened ball; effect of the flattening of the ball. Examination of the successive improvements to which this idea has served as a basis. Chambered arms; use of the short bottom and the patch. Arms à tige. Elongation of the ball; shortening of the spiral groove; diminution of the charge: advantages resulting from it. Pointed cylindrical ball; principles of its outline; effect of the notches of the ball; superiority of this projectile over the spherical balls. Summary examination of the different models of rifled arms which have been successively in use. Versailles rifles.

Wall-piece, pattern 1831. Common rifle, pattern 1842. Wall-piece, pattern 1840. Bored-up wall-piece, pattern 1842. Pistols for officers of cavalry and gendarmerie. Rifles à tige, pattern 1846, and artillery carbine à tige. Description of these two arms. Superiority of the rifle à tige over the arms for precise aim previously adopted. Trial relating to a new improvement in the construction of rifled arms. Disuse of the “tige.” Ball with cup. Comparative notice of the fire-arms of the different European powers.

SECOND SECTION.—PROJECTILES AND CANNON.

Thirty-first Lecture.—(5.) Principles of construction of projectiles.

Considerations on the substances which may be chosen for the manufacture 163 of projectiles. Essential conditions, density, hardness, tenacity, cheapness. Projectiles of stone, lead, cast-iron, iron, copper, gun-metal. Forms of projectiles.

Exterior form; conditions which serve to determine it. The spherical form preferable to any other in the actual state of artillery. Advantage of elongated projectiles. Conditions relating to their use. First attempts. Interior form of hollow projectiles; howitzer shells, bombs, and grenades. Thickness of the metal; fuse-hole; charging-hole of naval hollow projectiles; lugs or handles of shells. Density of projectiles. Recapitulation of the balls; howitzer shells; shells and grenades in use, their nomenclature, dimensions, weight. Cannon-balls. Choice of metal and weights. Different arrangements for the use of shot, case-shot, canister or naval grape-shot. Spherical case; conditions relating to their use. Charge of spherical case. Bar-shot. Rescue shells.

Thirty-second Lecture.—(6.) Cannon. Historical ideas on the subject. Principle of arrangement of ancient arms and machines of war. Motive force employed; its inferiority compared to that furnished by the combustion of powder. Earliest cannon.

Historical view of the different systems of ordnance which have been successively in use in France.

1. Cannon. Calibres in use in the 16th century. Edict of Blois, 1572. Cannon employed in the reign of Louis XIV. Regulation of 1732. System of Vallière. Modifications introduced by Gribeauval in 1765. Cannon of the year XI. Cannon in use at the present day.

2. Ordnance adapted to hollow projectiles. Difficulties inseparable from the throwing of hollow projectiles; first attempts. Mortars. Double fire. Ancient calibres. Mortars in use at the present day. Stone mortar. Howitzers, their first use in the French artillery; howitzers of 1765; of the year XI. Calibres in use at the present day. Considerations on the calibres of different kinds of cannon. Siege, garrison, field, coast, and naval ordnance. Siege, garrison, field, mountain, coast, and naval howitzers. Mortars and stone mortars. Considerations on the metals which may be employed in the manufacture of cannon for siege, garrison, field, coast, and naval purposes. Interior form of ordnance.

Thirty-third Lecture.—(7.) Vent; its object, its dimensions. Bushes inserted before casting, (masses de lumière;) after casting, (grains de lumière.) Considerations on the position of the vent relatively to the charge. Experiments made with the infantry musket, and with 24 and 16 pounder guns.

Arrangement of the vent in guns of 1732; portfire chamber. Vent of mortars. Priming pans. Windage of projectiles; conditions which determine it for the different services. Rules received with respect to ancient guns. Dimensions 164 in use at the present day. Different characteristics resulting from the windage of projectiles. Length of the bore. Question of the length of the bore considered with reference to the projectile effect of the powder. The length of ordnance is determined by considerations unconnected with this effect.

Length of bore of siege and defensive artillery, of field, coast, and naval guns. Length of bore of mortars, and of the stone mortar. Length of bore of howitzers. Thickness of metal and external outline. Cannon:—Theoretical determination of the external outline necessary for resistance to the effect of the gases of the powder. Co-efficient of resistance, its value in the guns in use. Thickness in the chase necessary for resistance to the percussions of the projectile.

Swell or moulding of the muzzle. Thickness at the position occupied by the trunnions. Thickness of metal of the different systems of cannon which have been successively in use in France. Thickness of metal in howitzers. Form resulting from the diminution of internal diameter, at the position occupied by the chamber. Exceptional form of the siege howitzer. Outline of the interior of mortars.

Thirty-fourth Lecture.—(8.) Line of sight; its object and arrangement. Considerations on the inclination of the line of sight relatively to the axis of the gun. Trunnions; object and arrangement of trunnions and their shoulders. Position of trunnions relatively to the center of gravity of the gun. Preponderance of the breech over the chase; manner of estimating it; preponderance allowed in the different guns in use. General principle serving as the basis for its adoption. Position of trunnions relatively to the axis of guns. Reasons for their depression; circumstances which cause it to vary. Trunnions of mortars; their reinforces. Dolphins of ordnance. Weight of ordnance; necessary relation between the weight of a gun, and the quantity of movement of its projectile. Conditions serving to determine the weight of the different species of cannon, howitzers, and mortars in use. Examination of the weights adopted for the pieces of ordnance of all sorts, which have been successively employed. General recapitulation of the different species of ordnance in use. Nomenclature. Dimensions, weight. Land artillery. Siege, garrison, and field guns. Siege, garrison, field, and mountain howitzers, mortars, and stone mortars. Naval artillery. Cannon, carronades, howitzers, mortars, stone mortar, blunderbuss. Observations on ordnance. Exceptional ordnance. Villantroy’s howitzers. Belgian mortar of 60 c., &c. Description of the artillery petard.

THIRD SECTION.—WAR AND SIGNAL ROCKETS.

Thirty-fifth Lecture.—(9.) Historical ideas on the subject. Cause of the motion of rockets. Their exterior and interior form. Relation which should exist between the law of generation of the gases and the orifice for their escape. Measure of the tension of the gases in rockets. Results of experiments. Motion of the rocket. Variation of the velocity during its passage. Means of regulating the motion; effect of the directing stick. Influence of the wind upon the trajectory of the rocket.

Description of rockets in use.—1st. War rockets; calibres employed; body of the rocket; arrangement of the stick. Projectiles fitted to the head of the rocket; rockets without stick. 2d. Signal rockets; their calibres and composition.

FOURTH SECTION.—CARRIAGES.

Thirty-sixth Lecture.—(10.) Historical ideas on the subject. Arrangements originally in use for the service of ordnance. Successive improvements. Carriages on wheels. Introduction of limbers. General conditions which gun-carriages should satisfy.

General principles of their construction:—1st. With reference to the act of firing. 2dly. With a view to transport.

Mortar carriages. Particular requisites. Description of the carriages in use. Siege carriages; particular conditions. General arrangement of ancient siege carriages. Detailed description of the present siege carriage and its limber; its weight and different characteristics. Field carriage; particular requisites; general arrangement of the carriages employed before 1765. Field carriages of the system of Gribeauval; its defects. General arrangement and detailed description of the present field carriage and of its limber. Weight and different characteristics. Mountain carriages; particular requisites; description of the carriage and of the arrangement of its shafts (limonière.)

Thirty-seventh Lecture.—(11.) Garrison and coast carriages; particular requisites; object of the platform for the two systems; its principal dimensions; position of the pintle or working bolt (cheville ouvrière.) General arrangement of ancient garrison and coast gun-carriages. Description of the present garrison carriage; change of the carriage into a movable one on four wheels; weight and different characteristics. Replacement of the platform by a directing transom bed under certain circumstances of the service. Casemate carriage. Iron carriages; inconveniences of this kind of construction for siege purposes and on the field of battle; its advantages for the armament of coasts. Description of the coast carriage actually in use; weight and different characteristics. Naval carriages; particular requisites. General arrangement of naval carriages in use. Carriage on four small wheels for cannon. Bracket carriage (à échantignolle,) and carriage with double pivot platform for howitzers. Carronade carriage. Mortar bed, cast in one piece with the mortar, (à plaque.) Exceptional methods of construction. Depressing gun carriages for a very plunging fire. Villantroy’s howitzer beds, those of the Belgian mortar of 60 c., &c.

FIFTH SECTION.—CARRIAGES AND OTHER PARTS OF AN ARTILLERY TRAIN. ARTILLERY OF FOREIGN POWERS.

Thirty-eighth Lecture.—(12.) Battery carriages. Ammunition wagon. Historical ideas on the subject. Requisites for carriages used for the transport of munitions of war. General arrangement and description of the present ammunition wagon. Principles of arrangement of the ammunition chest. Loading of the chest with munitions of various kinds. Mountain ammunition chest. Loading of the chest with howitzer ammunition and infantry cartridges.

Battery wagon; object of this carriage; patterns successively adopted. Description of the wagon, pattern 1833. Field forge; object of this carriage. Description of the forge in use. Arrangement and play of the bellows. Mountain forge. Description and loading of it.

Thirty-ninth Lecture.—(13.) Park carriages and machines.

Park wagon. General arrangement and description of the park wagon and its limber. Carriages destined to the transport of heavy burdens. Ancient gun wagon. Truck. Block carriage. General arrangement and description 166 of the carriage. Siege cart; its object and description. Devil carriages. Arrangement of the ancient devil carriages with perch and with screw. Devil carriage with roller. Description of the carriage and of its mechanism. Gin. General arrangement of the different patterns successively employed. Description of the gin at present in use. Handscrew; its use, general arrangement, and description.

Fortieth Lecture.—(14.) Pontoon equipages. Conditions which military pontoon equipages should satisfy. Considerations on the nature of the supports to be employed. Reserve pontoon equipage. Boat of the reserve equipage; its general form and dimensions. Description of the boat and skiff; use of the boat for navigation; its weight and different properties.

Tackle and machines employed for bridge-making. Balks, moorings, chesses, blocks, and balk collar. Framework, with movable head; different kinds of piles. Means of anchorage. Common anchor; its properties. Anchor basket and chest. Buoy. Cordage. Ideas on its arrangement and on the measure of its resistance. Capstan. Windlass. Tackling. Handscrew. Pile driver. Hand rammer. Grapnel and hooks.

General arrangement of the boat carriage. Description. Its weight and properties. Light equipage.

Forty-first Lecture.—(15.) General ideas on the artillery of the different European powers, and comparison with the French material.

Ordnance; description, species, and calibres. Gun-carriages, carriages, and other parts of the train. General arrangement; facility of movement; modes of harnessing, &c.

SIXTH SECTION.—DETAILS OF CONSTRUCTION OF GUN CARRIAGES AND ARTILLERY CARRIAGES, AND MEANS OF PRESERVATION OF MATERIAL.

Forty-second Lecture.—(16.) Knowledge of woods. Preliminary ideas. Structures and general properties of woods. Diseases and defects of woods. Description and properties of the principal substances employed in the construction of the material; uses to which the different kinds of wood are specially destined. Selection of standing timber; felling; transport; reception of woods; cubature. Cutting up in large and small sizes. Observations on the shrinking of wood. Preservation of woods. Drying in the air. Round, squared, and blocked-out timber. Preservation in store; preservation in water. Steeping. Influence of the contact of woods with other woods, and with metals.

Forty-third Lecture.—(17.) General considerations on the substances employed in the manufacture of gun and artillery carriages. Different properties of metals. Choice of kinds of wood; effects of their being dried. Classified account of axles and wheels. Axles; substance employed, their forms and dimensions. Wheels; essential requisites. Importance of the elasticity of wheels. Effects of the dishing of a wheel, form of the spokes, coupling of the spokes with the nave and the felloes. Tires. Form and number of the felloes determined by the effects of the drying. Form of the nave. Wheel-boxes.

Forty-fourth Lecture.—(18.) Means employed for the connection of the pieces which enter into the composition of gun-carriages, carriages, and other furniture of the train. Nails, clinch nails, rivets, bolts, screws, &c. Examination of the joinings employed in the construction of gun-carriages, carriages, and other furniture of the train.

General principles. Joinings of gun-carriages. Joint plates (“rondelles d’assemblage.”) Mortar beds, siege, field, and garrison carriages.

Forty-fifth Lecture.—(19.) Joining of other carriages and furniture. Hind parts, ammunition wagon, battery wagon, forge, park wagon, block carriage, cart, devil carriage, and drays. Boat and wherry. Fore parts, particular requisites. Fore parts of the field and siege carriage, of the park wagon, devil carriage, and drays. Barrels and cases.

Forty-sixth Lecture.—(20.) Means employed for the preservation of the material. Cost price of the principal parts of the material. Ordnance, projectiles, powder, carriages, and other furniture of the train. Small-arms. Preservation of ordnance in gun-metal and cast-iron. Preservation of projectiles. Formation and counting of piles. Rust-cleaning machine. Preservation of gun-carriages, carriages, and other furniture of the train. Different methods of stacking in use. Preservation of powder and made-up ammunition; stacking in powder magazines. Means proposed for avoiding the danger of explosion. Preservation of small-arms. Armories. Preservation of iron and cut wood.

THIRD PART.

FIRE OF ORDNANCE AND PORTABLE FIRE-ARMS. EFFECTS OF PROJECTILES.

Forty-seventh Lecture.—(1.) Fire of ordnance. Kinds of fire in use with ordnance. Choice of charges of powder. Charges of powder formerly in use; their progressive reduction. Charges of field, siege, garrison, coast, and ships’ cannon; of howitzers and mortars.

Arrangement of the charge. Shot cartridge for field guns. Loading of the other kinds of guns, of howitzers, mortars, and the stone mortar. Loading for fire with red-hot shot. Armaments for the service of ordnance. Methods of igniting the charges of powder; tubes formerly in use, friction tubes. Percussion system; Swedish tube. Ignition of the charge of hollow projectiles, fuses of hollow projectiles, fuse with several pipes for the fire of spherical case, hand grenade fuse. Rapidity of fire. Laying of ordnance. Principal methods of laying guns; laying them by the help of the line of sight. Determination of the elevation. Instruments in use to obtain elevations. Negative elevations, means of using them. Laying guns for fire parallel to the ground; for breaching fire at a short distance.

Forty-eighth Lecture.—(2.) Determinations of elevations by experiment; construction of practice tables. Laying guns when the axis of the trunnions is not horizontal. Laying guns with the help of the plumb-line and quadrant; plunging fire, rectification of the aim.

Fire of mortars, means for directing it in use; use of pickets, of the line, of the quadrant. Laying pieces in the case of a defective platform. Means of laying them for night-firing. Laying naval ordnance; use of the front sight. Initial velocities of projectiles with the different charges in use. Angles of sight, and point-blank ranges of ordnance. Ranges at different sights. Maximum ranges.

Forty-ninth Lecture.—(3.) Probabilities in the fire of ordnance; known laws, facts ascertained by experiment. Distribution of projectiles over an object aimed at of indefinite extent. Mean point of impact. Fire of canister; effects of the dispersion.

Fire of spherical case. Effects of the bursting of the projectile; dispersion of the balls and of the explosions. Fire of the stone mortar; use of mortars for the same purpose.

Fire of small arms: charges of powder adopted. Ball cartridge. Initial velocities of balls with the different arms. Angles of sight and point-blank ranges. Rules for fire according to distances, for muskets, carbines, and pistols. Fire of rifled arms; use of the tangent scale. Probability of the fire of small-arms; comparison of arms with smooth-bored and rifled barrels. Different means employed for the estimation of distances.

Fiftieth Lecture.—(4.) Effects of projectiles on the different substances fired at. Effects of concussion and penetration. Effects on earth. Theory of the penetration of a projectile into a resisting medium. Formula to express the penetration, based on the results of calculation and experiment. Effects of penetration into wood. Effects on metals, cast-iron, iron, lead. Effects on masonry and on rock. Application to a breaching fire delivered in a regular direction relatively to the revetment. Effects of the shock of projectiles upon living bodies. Effects of hollow projectiles bursting in different media; earth, wood. Method of bursting employed against troops.

Effects of spherical case. Incendiary effects. Effects of war rockets. Explosive rockets. Incendiary rockets. Effects of concussion.

FOURTH PART.

TRACE AND CONSTRUCTION OF BATTERIES.

Six Lectures, common to the Students of both Arms.

Fifty-first Lecture.—(1.) Definitions. Meaning attached to the word “battery.” Different denominations given to batteries: first, according to the circumstances of the war in which they are employed; secondly, according to their mode of construction; thirdly, according to the kind of ordnance with which they are armed; fourthly, according to the kind of fire for which they are intended; fifthly, according to the direction of their fire.

Principles of construction. General considerations on the elements which constitute the different kinds of batteries which have reference to them. Epaulment; its length, height, and thickness in different cases. Section of the epaulment. Ground-plan of the epaulment of the different kinds of batteries; returns at its extremities. Case where the battery is in advance of a parallel. Epaulment with redans; its trace.

Embrasures opened in the epaulment; their construction in different cases; slope of the bottom; interior opening; exterior opening; form of the cheeks.

Genouillère; fixing of its height for the different kinds of fire. Limit of the obliquity of the embrasures.

Fifty-second Lecture.—(2.) Terre-Plein; its position relatively to the ground; its length for the different kinds of batteries. Disposition of the part unoccupied by the platforms. Terre-plein of garrison, field, coast, and barbette batteries.

Ditch; cases in which it is employed. Its position with reference to the epaulment. Depth, breadth, , and plan of the ditch.

Communications between the battery and the works, in its neighborhood; parallels or trenches; plan and construction. Communication between the battery and its ditch.

Powder magazines: their object. Discussion respecting their site and capacity with a view to the different kinds of batteries, viz., siege, garrison, and field batteries.

Traverses of crownwork and garrison batteries. Width between them and dimensions.

Fifty-third Lecture.—(3.) Details of construction. Different materials employed in the construction of batteries. First, materials for revetments, fascines, gabions, hurdles, sods, bags of earth, withy-bands, stakes, &c. Secondly, materials for platforms; hurtoir, sleepers, planks, beams, pickets. Construction of revetments of different kinds employed in batteries. First, revetment of the interior slope of a battery upon the natural ground. Secondly, revetment in use when the terre-plein is more or less sunken. Ordinary siege battery, battery in a parallel, battery in a crownwork. Third, revetment of the checks of embrasures in the different cases met with in practice; direct batteries with point-blank range; ricochet, breaching, garrison, and field batteries.

Fifty-fourth Lecture.—(4.) Construction of platforms. Ordinary siege platforms, movable platforms (à la Prussienne,) garrison and coast platforms, ordinary mortar platforms, platforms for coast mortars of great range. Peculiar case where the fire has to be elevated or greatly depressed. Construction of the communications from the battery to the parallel and to its fosse. Construction of powder magazines in batteries. Magazines of siege batteries, Nos. 1, 2, 3, 4. Case of breaching batteries; garrison battery and field battery. Magazines. Degree of resistance offered by blinded magazines. Modifications adopted for the strengthening of magazines whose construction is already fixed.

Fifty-fifth Lecture.—(5.) Number of workmen to be employed on the construction of the different parts of batteries: revetments, platforms, communications, powder magazines. Earthworks.

Duration of the total labor necessary for the construction of each kind of battery. Duration of the duty for the different parts of the personnel employed upon the construction; officers, gunners, assistants. Definitive number of workmen necessary for the construction of the different kinds of batteries. Tools of different kinds.

Simultaneous execution. Preliminary operations. Reconnaissance. Prolongations. Sketch of the plan of a battery. Formation of the working party. Transport of materials. Plan of the battery. First, battery having its terre-plein on the level of the ground. Disposition of the working party. Work of the first night, of the following day, of the second night. Second, a battery sunk outside a parallel. Third, battery in a parallel or trench of some kind already established. Day labor, night labor.

(4.) Particular case of crownwork batteries.

Fifty-sixth Lecture.—(6.) Exceptional constructions. Blinded batteries for cannon or howitzers; for mortars. Batteries of earth-bags. Batteries on stony ground, on the rock, or marshy soil. Floating batteries. Construction on sites deficient in space. Case where the fire of the place is too dangerous. Coast batteries. General arrangement.

Instruction preparatory to working at the plans of batteries. (Course.)

FIFTH PART.

UNIFORM ORGANIZATION AND SERVICE OF THE ARTILLERY.

Ten Lectures common to Students of both Arms.

FIRST SECTION.—UNIFORM ORGANIZATION OF THE ARTILLERY.

Fifty-seventh Lecture.—(1.) Historical résumé. Progress of modern artillery, from its origin down to our time. Artillery of Charles VII. and of Louis XI. Progress under Francis I. Effects of the wars of religion. Edict of Blois, 1572. Improvements by Sully. Creation by Gustavus Adolphus. State of the artillery under Louis XIV. Employment of artillery on the field of battle at the commencement of the 18th century. Regulation of 1732. Introduction of howitzers into the French artillery. Regimental pieces. Progress of the artillery in Prussia and in Austria in the Seven Years’ War. Reorganization of the French artillery in 1765. Résumé of the improvements owing to Gribeauval. System of the year XI. Present system.

Historical ideas on the personnel of the artillery. State of the personnel at the commencement of the use of fire-arms. Masters and grand-masters of the artillery, &c. Personnel employed originally on the service, and the guard of ordnance. Creation by Louis XIV. Account of the successive modifications in the personnel from this epoch down to 1765. Organization of 1765. Horse artillery. Pontoneers. Artillery train. Artillery of the Imperial Guard. Organization of 1829. Present state of the personnel. Regiments of artillery. Composition of the personnel of the different kinds of batteries. Companies of pontoneers, workmen, armorers, veteran gunners. Driver-corps (“train de pare.”) Naval artillery.

Fifty-eighth Lecture.—(2.) Committee and central depôt of artillery. Organization of artillery commands. Establishments for the instruction of the personnel; artillery schools. Creation in 1679. Present schools; personnel attached to them. Central school of military pyrotechnics. Establishments for the preservation of the material. Importance of the material of artillery. Its state in France at different epochs. Artillery directions. Division of the territory of France. Personnel of the directions.

Establishments for the manufacture of the material. Ideas on the subject of their management. Arsenals; their object, management, number, personnel. Forges; their object, management, districts, personnel, inspection. Foundries for land artillery; their number, management, personnel, inspection. Naval foundries. Manufactures of arms; their special management, number, personnel, inspection. Branch of the service connected with gunpowder and saltpetre. Powder manufactories and refineries; management, personnel. Direction of the service. Establishments existing in France. Percussion cap manufactory.

SECOND SECTION.—SERVICE OF THE ARTILLERY IN THE FIELD. ORGANIZATION OF THE FIELD ARTILLERY TRAIN, ETC.

Selection of ordnance, conditions which determine it; cannon, howitzers, relation between them. Proportion of the number of pieces of ordnance to that of the combatants. Mean proportion received in France; circumstances 171 which may lead to a modification of it. Organization of ordnance in batteries. Account of the arrangements formerly adopted. Present system. Distribution of the batteries in the army. Principles received. Application of these principles to the artillery train of an army of a given strength. Infantry divisional batteries; cavalry divisional batteries; reserve batteries. Case of the formation of army corps. Composition and supply of batteries. Principles and details of the supply of batteries with ammunition for the guns and for the troops. Second supply distributed amongst the parks.

Fifty-ninth Lecture.—(3.) Field parks. Their composition, in carriages of all kinds. Application of the principles to the artillery train of an army of a given strength. Approximate relation of the number of the carriages and of the horses of the train to that of the pieces of ordnance. Means of renewing the supply of the parks.

Personnel of the field train. Personnel of the batteries; working companies. Companies forming part of the train. Personnel attached to the parks. Staff. Particular conditions, having reference to war in a mountainous country. Selection of pieces of ordnance. Proportion between their number and that of the combatants. Composition of some artillery trains employed in our African expeditions. Composition and supply of the mountain battery. Lading of the mules. Composition of pontoon trains. Reserve train, boats, wherries, tackle, carriages, and horses. Personnel of the train. Light train: material, personnel.

Sixtieth Lecture.—(4.) Marches of the artillery. Reception of a battery or of a park. Precautions to be taken before the departure. March at a distance from the enemy. Order of march. Distribution of the personnel; halts. Case of an accident to a carriage; ascents; descents; deep-bedded roads; passage through inhabited places; passage of bridges; of fords. Passage over ice. Night march. Transport of mountain artillery. March of pontoon trains. Transport of the trains by water; navigation by convoys; by isolated boats. Transport of ordnance, powder and projectiles in the boats. Transport of artillery trains by sea.

March in the vicinity of the enemy. Isolated convoys; rule with reference to their command; order of march; general measures of security; precautions to be taken during halts; manner of receiving an attack. Case where resistance becomes impossible; arrangements for the night.

Artillery in the march with other troops. Order of march. Relation of the different corps to each other. Exceptional difficulties which may occur on marches; privations of all kinds; bad weather; bad state of the roads; instances. March among high mountains; passes strongly occupied by the enemy; examples.

Encampments and bivouacs. Choice of ground convenient for a camp; disposition of the artillery camp. Establishment of artillery bivouacs. Disposition of the park; precautions relating to the superintendence. Different measures to be taken on arriving on the place of encampment or of bivouac. Attention to be paid to the horses: special precautions for the mules of the mountain artillery. Precautionary measures variable according to circumstances.

Sixty-first Lecture.—(5.) Artillery on the field of battle. Measures to be taken on arriving in the neighborhood of the enemy.

Choice of positions adapted for artillery.

Execution of the fire. Choice of the different kinds of fire according to the nature of the object aimed at and the distance. Fire of cannon, with ball, with shot. Fire of field and mountain howitzers. Fire parallel to the ground.

Use of war rockets. General principles relating to the effects to be produced by artillery, and to the warmth of the fire. Proper use of stores; their replacement. Use of the prolong. Arrangements to be made after the engagement. Spiking and unspiking of ordnance.

Use of artillery in the principal circumstances of a campaign. General case of an offensive engagement. Part played by the artillery in supporting infantry and cavalry marching to the attack. Importance of the artillery for following up a first advantage which has been obtained. Examples. Use of the artillery in masses to strike a decisive blow. Examples. Defensive engagement.

Disposition and use of the artillery for the defense of fortified positions. Attack of entrenchments. Reconnaissance. Disposition and use of artillery; attack of lunettes by the gorge. Examples. Attack and defense of villages; disposition of the artillery under these two circumstances. Attack of squares. Importance of artillery towards preparing for it. Examples. Defense of squares; disposition of artillery. Examples. Case of a charge of cavalry upon artillery. Use of artillery in the advanced guard, in the rearguard, in a retreat.

Use of artillery in the passage of streams. Examples. Use of artillery to defend or force the passage of valleys or defiles. Examples.

THIRD SECTION.—SERVICE OF ARTILLERY IN THE ATTACK AND DEFENSE OF PLACES, AND IN THE DEFENSE OF COASTS.

Sixty-second Lecture.—(6.) Object to be attained with the use of artillery in the attack of places. Selection of ordnance, cannon, howitzers, mortars. Composition of the siege train. Method to be followed in order to determine it. Examples of trains employed in different sieges. Carriages of the train. Supply of the siege train with projectiles, powder, &c.

Personnel of the siege train; troops and staff. Transport of the siege train. Horses to be employed. Limit in either direction. Employment of watercourses. Examples. Establishment of the train before the place. Encampment of the artillery force. Organization of the parks. Workshops, powder magazines, trench-depots. Rules relating to the direction of artillery works.

Commanding officers of attack.

Sixty-third Lecture.—(7.) Considerations on the different kinds of batteries to be employed in the attack of fortified places. Position of the batteries relatively to the point to be breached. Direct battery within point-blank range; enfilading battery, for a plunging fire, for direct fire within point-blank range, for plunging fire. Mortar batteries. Composition of the different kinds of batteries. Position of the directing lines of an enfilading battery, relative positions of the cannon, the howitzers, or the mortars. Position of the batteries relatively 173 to the parallels and the rest of the trenches. Examination of the circumstances which affect the power of a plunging fire, command of the work over the battery; distance between the height of the traverses. Slope of the crests of the work.

General principles relating to the order of the works of the artillery, commencing from the opening of the trenches.

Times for the construction of the first batteries. Batteries of the first and second parallels. Use of field artillery to defend the flank of the attacks. Replacement of the fire covered by the advance of the works; batteries of the third parallel. Use of vertical fire. Mortars of 15c. Throwing of grenades. Breaching and counter batteries. Considerations relating to their position. Batteries in the covered way.

Case of a breach into an interior work. Composition of the breaching and counter batteries. Calibres to be used. Number of pieces of ordnance.

Ideas upon the operation of arming batteries. Precautions to be taken. Passage out of the parallels or trenches. March in the trenches; examples of some operations of this kind. Supply of the different kinds of batteries. Rule relating to their daily service. Firing of siege batteries. Opening of the fire. Direct fire within point-blank range. Plunging fire. Fire of mortars. Warmth of the fire by day and by night; mean consumption of material. Fire of breaching batteries. Effects to be produced. Height of the horizontal cutting, number of the vertical ones. Execution of the fire; fall of the revetment. Fire upon the counter forts. Fire to render the breach practicable; balls, shells, war-rockets, facts ascertained by experiment.

Consumption of powder and projectiles, length of the operation. Breaching fire in a very oblique direction. Fire upon masked masonry. Breach into an unreveted work. Fire of counter-batteries. Bombardment. Case where it can be employed; manner of executing it.

Occupation of the place; arrangements which must be made by the artillery. Case of raising the siege. Case of its transformation into a blockade.

Sixty-fourth Lecture.—(8.) Service of artillery in the defense of places. Object to be attained with artillery. Selection of ordnance, guns, howitzers, mortars. Use of war-rockets and arms of precise aim. Field artillery. Basis of the supply of fortified places. Projectiles, powder, small-arms, various carriages. Personnel of the artillery. Troops. Staff.

Measures to be taken before the siege. Reconnaissances. Arrangement of the material. Organization of the personnel, of the duty by local divisions, of the workshops of all sorts. Precautionary armament. Basis of its organization. Supply of ordnance. Defensive armament. General principles relating to the armament of different kinds of works. Bastions, cavaliers, demilunes, approaches, &c. Organization of the armament. Traverses, embrasures, gun-carriages to be employed. Powder magazines. Supplies. Service of pieces.

Employment of the artillery against the first works of the besiegers, against the construction and armament of batteries; against the besieging artillery. Partial disarmament in case of inferiority. Part played by artillery in sorties. Modification of the defensive armament in proportion to the progress of the attack. Last defensive armament. Principles relating to its disposition. Armament of the flanking part of the fortification. Increased use of vertical fire. Use of war-rockets against works in close proximity. Crowning batteries, 174 cavaliers of the trenches. Heads of saps, &c. Blinded batteries. Conditions of the establishment. Defense of breaches.

Service of artillery in the defense of coasts. General considerations on the degree of extension admissible in the armament of coasts. Principal points to be defended. Selection of ordnance intended for the armament of coast. Objects to be effected. Effects of balls (utility of large calibres;) of howitzer shells and of shells. Fire with red-hot balls. Material appropriated to the defense of coasts.

Position of coast batteries, conditions which determine it. Composition of coast batteries; their supply. Ideas upon the organization of the batteries and their small redoubts (réduits.) Use of the fleet and of field artillery. Personnel allotted to the service of artillery on the coasts.

FOURTH SECTION.—APPLICATION OF THE PRINCIPLES PREVIOUSLY SET FORTH TO THE ATTACK AND DEFENSE OF THE FORTRESS OF METZ, (SHAM SIEGE.)

Sixty-fifth Lecture.—(9.) Composition of the siege train necessary for the attack of Metz. Carriages of the train.

Supply of the train with projectiles, powder, &c. Personnel of the train, troops and staff. Transport of the siege train. Establishment of the train before the place; encampment of the artillery force. Organization of the parks. Work-shops, powder magazines and depôts.

Sixty-sixth Lecture.—(10.) Object, disposition, and armament of all the batteries from the first opening of the trenches to the capture of the place. Use of field artillery to flank the batteries, &c.

Service of artillery in the defense of the place. Supply of ordnance, projectiles, powder, small-arms, and different carriages.

Personnel of the artillery. Troops, staff. Organization of the personnel and of the duties by local divisions. Precautionary armament; supply of ordnance. Defensive armament. Armament of the different works. Service of the pieces. Last defensive armament.

Lectures Preparatory to the Labors of the Course.

The sixth lecture of the fourth part of the course (the fifty-sixth) is partly devoted to the communication of the instructions necessary for the execution of the work of tracing plans of batteries.

Studies in connection with the Artillery Course.

The practical studies which are connected with the artillery course, are,—

The tracing of batteries is executed by the students of both arms, the other tasks by the artillery students alone.

I. DRAWING ORDNANCE (12 DAYS.)

The survey of ordnance consists in constructing accurate sketches of a gun, howitzer, and mortar, in measuring their dimensions, and in giving a description of each of the pieces drawn. It is on this occasion that the students are practiced in the management of instruments to insure precision, such as the étoile mobile, and the sliding compass, &c. One day is devoted to this work.

The tracing of ordnance consists in the execution of a drawing upon colombier paper, containing an exact and detailed representation of a gun, a howitzer, and a mortar, with their projectiles.

This work is performed with the help of the tables for the construction of ordnance. Eleven days are devoted to it.

Detailed Programme of the Drawing.

1. For each gun, howitzer, or mortar, a longitudinal in the direction of the axis, and at right angles to the axis of the trunnions, and a plan parallel to the axis of the bore and of the trunnions.

Besides this, for those cannon and howitzers which have dolphins, a transverse taken across the middle of the dolphins and the axis of the trunnions. For mortars, a transverse made by a plane passing in front of the dolphins, the whole on a scale of one-fifth.

2. Detail of the button (comprising the cascable and breeching loop for naval ordnance) on a scale of two-fifths.

3. Detail of the tracing of a dolphin, on the scale of two-fifths.

4. Tracing of the bush of a gun, on a scale of two-fifths, and tracing of a priming-pan at the real size.

5. For garrison ordnance, in cast-iron, detail of the widening of the base ring on a scale of two-fifths.

6. Tracing of a cannon-ball, of a howitzer-shell, and of a shell, on a scale of one-fifth.

Tracing of the lugs of a shell, ring and lug at the real size.

All the parts of the drawing must be colored in uniform tints in conformity to the table of conventional colors; the annexation of the figures of measurement is not required.

This work is preceded by three or four lectures intended to make the students familiar with the tracings which they have to execute, and the solution of the problems in geometry and descriptive geometry, to which the representation on paper of pieces of ordnance and their projectiles give rise.

II. DESIGN FOR ORDNANCE (24 DAYS.)

The design for ordnance has for its object the complete determination of the nature of a projectile, and of a piece of ordnance in accordance with certain special conditions, inquiring into the laws of the motion of the projectile, and into its principal destructive effects, and the settlement of practice-tables for the 176 gun. The general case for treatment is that of a howitzer, which comprehends the gun and the mortar as particular cases.

The data usually adopted are,—

The drawing, on colombier paper, which must be figured in all its parts, contains,—

The final tracings of the gun, the projectile, the bottom, and the fuse, must be colored in uniform tints conformably to the table of conventional colors.

As to the tracing of the profile founded upon the calculation, it should receive merely an edging of the color which represents the metal used.

PROGRAMME OF THE MEMORANDUM ON THE DESIGN FOR ORDNANCE.

INTRODUCTION.

Object of the work. Data of the Question.

A. PROJECTILE.

First Section.—Substance, Forms, and Dimensions.

1. Choice of the metal employed in the manufacture of this projectile.

2. Forms of the projectile.

3. Internal diameter.

4. External diameter.

5. Dimensions of the vent.

6. Diameters of the high and low gauges.

7. Densities of the projectile empty and filled with powder.

8. Weight of the cast-iron ball of the same calibre as the howitzer shell.

Second Section.—Minimum Bursting Charge.

9. Theoretical bursting charge for the hollow sphere.

10. Effect of the shock of the gases, and of their loss through the vent.

11. Résumé of the results arrived at in this chapter.

B. ORDNANCE.

First Section.—Metal, Calibre, and Length of Bore.

12. Choice of the metal of which the piece is to be formed.

13. Windage of the projectile and diameter of the bore.

14. Effect of the windage on the velocity of the projectile.

15. Length of the bore and charge of powder which satisfy the data of the programme.

16. Résumé of the results arrived at in this .

Second Section.—Thickness of Metal necessary in order that the Piece may resist the Expansion of the Gases.

17. Explanation of the method employed to resolve the question of the thicknesses of metal.

18. First propulsion of the projectile, mean density of the gases after this propulsion.

19. Second propulsion of the projectile, mean density of the gases after this propulsion.

20. Third, fourth, &c., propulsions of the projectile, mean density of the gases after each of them.

21. Density and position of the strata (of gas) at the moment of the maximum of mean density.

22. Density of the last stratum for the positions which come after that of the maximum of mean density.

23. Tensions which result from the densities found.

24. Corresponding thicknesses of metal.

25. Résumé of the results obtained.

Third Section.—Profile of the Piece.

26. Inclosing curve, resulting from the calculations of the second .

27. Modification rendered necessary by the form of the posterior part of the projectile.

28. Utility of the chamber and its dimensions.

29. Tracing of the chamber and of its junction with the bore.

30. Thickness of metal around the chamber.

31. Chase and reinforce.

32. Determination of the angle of sight.

33. Vent and base ring.

34. Minimum weight of the piece for the resistance of the carriage.

35. Approximate calculation of the weight given by the profile previously obtained. Modification of this profile, if there is any.

Fourth Section.—Trunnions, Breech, and Handles.

36. Dimensions of the trunnions and of the shoulders.

37. Tracing of the breech.

38. Base rings and other moldings.

39. Object and fixing of the preponderance of the breech.

40. Exact settlement of the position of the trunnions, definitive length of the reinforce.

41. Center of gravity of the piece; dimensions and position of the handles.

42. Means of executing the calculations indicated in the two preceding articles.

43. Table of the dimensions of the piece.

C. FIRE OF THE HOWITZER. EFFECTS OF THE PROJECTILE.

First Section.—Elements of the Charging of a Howitzer.

44. Tracing of the shot bottom.

45. Tracing of the fuse.

46. Diameter of the cartridge (or of the bag.)

47. Charge of powder for firing with ball.

Second Section.—Laws of the Motion of the Projectile. Establishment of Practice Tables.

48. Preliminary calculations.

49. Trajectory.

50. Curve of the inclinations.

51. Curve of the remaining velocities.

52. Curve of the durations of the passage.

53. Determination of the elevations for the fire at different distances.

54. Angle of fire, corresponding to the different distances of the object aimed at.

55. Angles of descent.

56. Résumé of the laws of the motion and of the practice tables.

Third Section.—Effects of the Projectile.

57. Depth of penetration in the media indicated by the programme.

58. Effects of explosion in earth.

59. Résumé of the results relating to the effects of the projectile.

Note.—The formulas cited in the memoir need not be accompanied by their demonstration, except in the case of the latter not having been already developed in the lessons of the artillery course. It will be sufficient to insert in this notice only the final result of the calculation relating to each formula, without entering into the details of such calculations.

The study of the design for ordnance is preceded by four lessons intended to make the students acquainted with all the details of its execution, and the substance of which is indicated in the programme of the memoir.

III. APPLICATION OF THE THEORIES OF THE ARTILLERY COURSE (6 DAYS.)

This study is intended to apply to the students those theories of the course which have not found their application in the design for ordnance. It comprises the solution by arithmetical calculations of certain questions on the effects of powder, the balistic pendulum, the effects of recoil, the science of projectiles, the draught of carriages, &c. The number of the questions may vary according to their nature and the time which their solution requires. The stating of the questions and the results of the calculations are inscribed on separate papers. This study is preceded by a lesson in which the students have recalled to them the formulas which they have to employ.

IV. DRAWING OF ARTILLERY MATERIAL (26 DAYS.)

The drawing of artillery material has for its object the representation by figured sketches of a gun-carriage, carriage, or other furniture of artillery material. The sketches, on paper put together in the form of a book, and headed by a special programme for the object to be drawn, consist of plans, s, or elevations of the object, executed on certain scales, and of detailed projections of the principal iron-work and joints. The whole fixed by the special programme in question.

All the simultaneous projections of any one part of the object drawn (fore part or hind part for carriages) must be completely figured; they are accompanied by explanatory inscriptions, with letters of reference to show the names of the pieces in wood or metal which they comprise.

Each collection of sketches must contain as well a notice in confirmation of the drawing, giving the complete description and the properties of the object to which it refers.

The students make two surveys of the same kind; eight days are allowed for each of these surveys, including the composition of the confirmatory notice.

The first survey is followed by the execution of an unfigured drawing, containing a complete representation of the object surveyed (elevation and plan,) obtained by the combination of the partial projections contained in the sketch. The drawing should be colored in the conventional uniform tints, and accompanied by an explanatory inscription, with letters of reference. Ten days are devoted to this work of composition.

V. TRACING OF BATTERIES (4 DAYS.)

This work consists in executing sketches showing, each in accordance with a separate programme, the complete plan of a battery and the essential data having reference to its construction and to its armament. The sketches, made by scale and completely figured, must comprise in the case of each battery to be represented—

RECAPITULATIVE TABLE.—ARTILLERY STUDENTS.

RECAPITULATION.

Lectures,     150
Studies,       380 530

RECAPITULATIVE TABLE.—ENGINEER STUDENTS.

RECAPITULATION

Lectures,   162
Studies,       20 182. Round number, 180.

IV. PROGRAMME OF THE COURSE OF MILITARY ART AND FIELD FORTIFICATION.

The course is divided into six parts, and is made up of lectures and works of Application in the Halls of Study and on the ground.

I. LECTURES.

FIRST PART.—HISTORICAL NOTICES ON THE ORGANIZATION OF ARMIES.

The first lecture commences with explanations relating to the Greek and Roman armies; their order of battle, mode of marching; comparison of the 182 Roman Legion with the Greek Phalanx, and of the Roman Legion under Marius and under the Emperors.

2. Military organization of the Franks under the Kings of the first race. Consequences of the feudal system, acting on the military organization. Feudal armies. Chivalry. Crusades, and war against England. Establishment of the first standing armies. Results dependent on the introduction of fire-arms. Progress made in the Art of War and in the organization of armies, from the sixteenth century to the present time.

3. Necessity for standing armies. Their proper character. Recruiting. Promotion. Degrees of rank. Station of the officers. Various positions of military men. On the composition of armies, Infantry, Cavalry, Artillery, Engineers. Corps d’Etat-Major. Composition of the army during the Revolution and during the Empire. Actual formation of a French army.

General Staff. Commissariat. (Intendance.)—Different services dependent on it.

Relations between the strength of each of the arms that make up an army. On other corps which are not classed among the principal arms.

4, 5, 6. Summary relating to the military organization of the principal Powers of Europe.

SECOND PART—ON TACTICS.

1. Definitions. Formations. Manœuvers; character of a good manœuver. Order of battle: first, of the Infantry; second, of Cavalry; third, of the Artillery; relating to Sharpshooters (tirailleurs.)

2. Brief summary of the principal movements in battalion drill to pass from line to the order in columns and reciprocally. Movements in column. Movements in battle. Dispositions to be made against Cavalry.

3. Of the principal movements in line. Order of battle. Line of battle. Formation of Infantry to advance against the enemy. Action of Cavalry. Principal formations. Charges of Artillery. Use of the Three Arms.

THIRD PART.—CASTRAMETATION.

1. General principles of castrametation. Situation. Construction and disposition of barracks. Camp of a Regiment of Infantry, of Cavalry, and of a Battery of Artillery.

2. Manner of tracing a camp on the ground. Huts; details relating to their construction. Tents. Bivouacs. Screens. Kitchens and camp ovens. Choice of the site of a camp; precautions to be taken for its security. Main guards. Advanced posts. Patrols and sentinels.

FOURTH PART.—FIELD FORTIFICATION.

1. Definition of fortification in general. Object and character of field fortification; its utility demonstrated by historical examples. Napoleon’s opinion. Essential principle of field fortification. Discussion on the ordinary profile of earthen entrenchments; on the dimensions to be given to the ditch in level ground.

2. Definitions relating to the trace; general principles. Redoubts.

3. On the elements of lines. Relation that should exist between the crest and the internal size of a closed work. Maximum and minimum of the sides of a square redoubt. Defects inherent to the trace of this kind of redoubt. Circular redoubts. Redoubts en crémaillères. Star forts. Lines with bastions.

4. Revetments of various kinds; case in which the slope of the ditch should be reveted; choice to be made of the different kinds of revetments.

5. Exterior dispositions; accessories to the defense; abattis; trous de loups; palisades; chevaux de frise, &c. Precautions to be adopted with reference to such accessories.

6. Interior dispositions; armament of musketry, artillery, barbettes, and embrasures; their advantages and disadvantages; construction of.

7. Powder magazines of different kinds. Small earthen entrenchments; palisades, carpentry, or blockhouses; advantages and disadvantages of blockhouses. African blockhouse. Closing of field-works.

8. Artificial inundations; under what circumstances they can be considered as obstacles. Positions and dimensions of dikes. Details of their execution; what advantage can be drawn from an inundation having less than five feet depth of water.

9. What is understood by the defilading of a work. The defilading of fieldworks should, above all things, be made to depend on their trace and situation. Definitions: dangerous ground; dangerous points. Defilement of an isolated and closed work; in what case it is practicable. Use of traverses. A partial defilement may sometimes be sufficient.

10. Continuous lines. Broken lines. Traces of redan, tenailles, cromailleres. Bastioned lines. Comparison between continuous and broken lines. Principal objections to their use. Utility of each demonstrated under certain circumstances.

11. Lines in broken ground: their form should depend on the nature of the ground. On the manner of fortifying a table-land. Expedients for defilading portions of lines. On the manner of making use of the natural obstacles of the ground; forests, scarps, marshes, water-courses, &c. Method of fortifying a house, village, an open town. Defense of a bridge or road.

12. Têtes de pont. Utility of small earthen entrenchments in these cases to facilitate the passage of a retreating army. Traces of a large tête de pont. Principal circumstances relating to the use of lines in war. Lines of circumvallation and countervallation. Frontier lines. Retrenchments against a descent. Lines that an army should make in an enemy’s country, far from its base of operations. Entrenchment on the field of battle. Lines, mixed, proposed by General Rogniat.

13. Attack and defense of entrenchments, of a continuous line; of a line at intervals; of an isolated work, &c. Examples of the attack and defense of lines.

14. Instruction relating to the operations for profiling and defilading on the ground.

15. Instruction on the project of field fortification. Calculation of the dimensions of a ditch corresponding to the face of a work of a variable relief, and to be constructed in level or other ground. Details relating to traverses, small entrenchments; defensive caponnieres, and accessories to defense, &c.

16. On the construction of entrenchments. Practical operations and organization of workshops to obtain durable and solid work. Necessity, in most cases, for accelerating the construction of entrenchments. Vauban’s precepts. In what manner the work must proceed to obtain a useful result; and, in the event of plenty of hands, how to finish it promptly.

FIFTH PART.—ON MILITARY COMMUNICATIONS.

1. On roads. 1 and 2, Classification of roads. Section and trace of roads in level and mountain country. Details connected with the study of a project for a road. Particular conditions relating to military roads. Execution of paved and macadamized roads. Roads for passing difficult places by the use of fascines, logs, &c. Maintenance and destruction of roads.

2. On military bridges.

3. Observations on the currents and change of form in the bed of rivers. Fords. Transverse s, &c. Reconnaissances of rivers. Properties essential to military bridges. Relation between the buoyancy and the load in the case of floating supports. Anchorage. Construction of the abutments. Means of rendering bridges stable.

4. Construction of a bridge of boats in different ways. Bridges made of ordinary boats. Method of withdrawing a bridge of boats.

5. Raft bridge. Relation between the weight and the extrinsic load of a raft. Number of trunks of trees required for a raft bridge on a river of given dimensions. Weight of the trunk of a tree. Number and space between rafts. Construction of a raft and a bridge of rafts. Bridges of casks and trestles.

6. Rope bridges; their use. Calculations respecting the tension and diameters of ropes. Construction of a suspension bridge, and calculations relating to it.

7. Bridges on piles, carriages, gabions, &c.

8. Measures to be taken for the preservation of military bridges. Destruction of military bridges; also of masonry bridges. Reëstablishment of bridges.

9. Flying bridges. Ferry-boats, tubs, passage by fords, on the ice, by swimming.

10. Execution of the passage of rivers. Advancing and in retreating. Examples.

SIXTH PART.—STRATEGY.

1. Definition. Fundamental principles of all operations in war. In all cases there are—first, the base of operations; second, the point to be arrived at; third, the line of operations. Strategetical points and lines.

2. On marching. Preparatory and manœuvering marches. Advanced and rear guard. On provisions. System of magazines. Requisitions. Invasions. Battle. Examples.

3. On positions. War in a mountainous district. Retreats. Pursuit. Convoys. Partizans.

4. Winter quarters. Cantonments. War against irregular bands. Military reconnaissances.

5. Precis of the campaigns of the French armies.

6. Analysis of the principal campaigns of great captains.

II. PROGRAMME OF THE WORKS OF APPLICATION EXECUTED IN THE HALLS OF STUDY.

These works consist of four Plates of Drawings, two Memoirs, and a Project, of Field Fortification. Of the four Plates of Drawings, two relate to Field Fortification, and two, accompanied by Memoirs, relate to Military Communications.

Plate 1—Elements of lines. Tracing, on the scale of 1/1000 of the interior crest (only) of a redan, lunette, redoubt, star fort, bastioned fort, according to particular data given to each Sous-Lieutenant. Construction on the scale of 1/200 of a complete profile for each of these works, supposed to be established on level ground. Complete calculation of the deblais and remblais for one of the preceding works, according to the instructions of the Professor.

Plate 2.—Details of a field-work. Trace on the scale of 1/200 of a portion of the work of which the deblais and remblais has been calculated. Graphic construction of a barbette and of a direct or oblique embrasure. Details of revetments in fascines, hurdles, turf. Pisé. Drawing of a blockhouse.

Plate 3.—Accompanied by a Memoir. Project of a portion of road on ground represented by certain lines, according to certain data.

Plate 4.—Accompanied by a Memoir. Military bridges.

Programme of the Project of Field Fortification.

This project is made by the Sub-Lieutenants, according to certain data given to each of them. It has for its object to cause them to study:—1st. The trace. 2d. The complete organization necessary for its defense. 3d. The details of construction of a field-work. In consequence, the work comprises three Plates of Drawings and a Memoir divided into three parts.

Programme of the Drawings.

Plate 1.—Plan of the whole. This plate has for its object the research of a trace and of a combination of suitable works for the fortification of a certain portion of ground under certain circumstances of war defined by particular data. Each Sub-Lieutenant receives a lithographed sheet representing the ground to be fortified, and he has to exhibit on this sheet the works he proposes, in tracing in plain lines the horizontal projections of the interior crests and superior limits of the ditch, and in dotted lines the stockades or palisades; to show in black figures at the angles of the works the relief of the interior crests; the sites of barbettes, embrasures, traverses, barriers, &c., being indicated by reference letters and explanatory notes, the lines in red showing the directions and objects of the line of fire.

Plate 2.—Organization of a work.

This plate has for its object the study of the details of the interior and exterior organization of a work of a certain form, in order to render it susceptible of making a good defense.

Each Sub-Lieutenant will draw a complete plan of such one of the works shown on Plate 1, as may be pointed out by the Professor. He will represent the ditches, parapets, embrasures, accessory defenses, small entrenchments, descents into the ditch, &c., according to the particular data furnished to him; the figures of the relief of the crests of all kinds, the deblais and remblais being marked at all the angles. The figures of the natural ground will be underlined. The same plate will contain figured profiles which have served for the determination of the complete projection of the work. Scale 1/250.

Plate 3.—Details of construction.

The object of this plate is to show the composition of workshops and the manner that should be adopted in the construction of field-works, according to circumstances, for the execution of the deblais and remblais.

Each Sub-Lieutenant will indicate the manner in which the work drawn on Plate 2 should be constructed:—1st. To render it durable and solid. 2d. To arrive rapidly at a useful result, even with limited resources of workmen and tools. 3d. To finish the work in the shortest possible time, by making use of all the necessary means. A plan will show the composition of the workshops under each of these hypotheses, and the successive advancement of the work will be represented by certain profiles supposed to be made at certain periods of the construction through the center of one of the faces of the work. In these profiles a firm trace, figured with altitudes, will show the limits of the deblais and remblais at the period represented by the profiles; and in addition by dotted lines, the final results proposed to be obtained. All these projects must be accompanied by a figured plan, showing the principal altitudes in meters. The remblais will be colored with gamboge, the undisturbed earth in bistre, and the deblais will be left white.

Programme of the Memoir.

Each Sub-Lieutenant will write at the head of his Memoir the text of the particular programme, to which he is obliged to conform in the preparation of his project, and he should add to the text of the Memoir all the sketches properly figured, which are necessary for the proper appreciation of the dispositions which are not sufficiently detailed on the Drawings.

The Memoir is divided into three parts, corresponding to the three Plates of Drawings.

FIRST PART.—CONSIDERATIONS RESPECTING THE WHOLE PROJECT.

1st. General principles, according to which it would be proper to trace the works indicated in the particular programme, such as lines at intervals, continuous lines, têtes de pont, &c.

2d. Description of the tracing in Plate 1. Reasons deduced from the form of the ground or the nature of the military operations that led to the adoption of the trace. Object of the works, and their connection with each other.

3d. Number, description, and position of the pieces of artillery composing the armament.

4th. Maximum and minimum of troops that could be employed in the defense of these works.

5th. Dispositions which should be adopted (relatively to the necessary preparations in materials and to the separation and movement of troops) for the attack and for the defense.

SECOND PART.—COMPLETE ORGANIZATION OF A WORK.

1st. Particular object of the work shown in Plate 2. Trace of the complete projections of the parapets, barbettes, ramps, embrasures, traverses, &c.

2d. Conditions that should be fulfilled by the ditch. Approximate calculation of dimensions which should be given to it, taking into account the increased means of providing for an excess or defect of the deblais.

3d. Discussion on the site and the part which might be expected from small entrenchments, accessory defenses, shutters, descents of ditches, &c.

4th. Site of powder magazines; capacity that should be given to them, suitable to the state of the munitions necessary for the armament of the work.

THIRD PART.—DETAILS OF CONSTRUCTIONS.

1st. Means of ascertaining the nature of the earth; considerations respecting relays for the transport of earth with the shovel.

2d. Description, number and disposition of the workmen in a shed for deblai and remblai, according to the nature of the ground and number of relays.

3d. Explanation of Plate 3. Organization of the sheds and conduct of the work where the duration and solidity of the work are the greatest essentials; where, on the other hand, rapidity of execution is the principal thing to be fulfilled.

4th. Which of the modes of construction exhibited in Plate 3 it would be desirable to employ for the proposed works, according to the circumstance specified in the particular programme. Calculation for this mode of construction, of the time and of the numbers of men and tools necessary for the execution of the deblais and remblais of the work given in the plate.

5th. Details of construction of the revetments, magazines, shutters, accessory defenses, artillery platforms, &c.

III. PROGRAMME OF EXTERIOR WORKS.

These works consist of an exercise in tracing out a camp, and an exercise on the profiling and defilement of field-works.

The exercise on tracing camps has no particular programme, but is preceded by a lecture given by the Professor.

Programme of Practical Exercises on the Defilement and Profiling of Field Works.

This exercise comprehends: 1st, work on the ground; 2d, a Memoir.

The work on the ground has for its object: 1st, the trace of the projections of the interior crest of a work, whose position and form are known; 2d, the determination of the relief of the interior crest; 3d, the profiling of the different parts, so that the relief of the different parts of the parapet, barbettes, traverses, &c., may all be fixed.

The Sub-Lieutenants for this kind of work are divided into groups of six or eight, employed together on the same work, each group being divided into two squads. The work may be a lunette or a redan of given dimensions, having a 188 parapet of three meters thick, and a natural slope of one to one.

1st. The direction of the capital will be marked out in front by two numbered pickets.

2d. The tracing will be executed by means of poles or pickets placed at all the angles, and at the extremities of the gorge; the relief will be determined by the practical methods of defilement adverted to in the lecture which preceded the work.

3d. The relief obtained by the defilement will be marked on all the poles or pickets placed at the angles, and at the extremities of the sides of the work.

4th. On each face two vertical profiles will be executed, perpendicular to the horizontal projections of its interior crest. In order that these profiles shall not interfere with those placed at the angles, they must be established at several meters distant from the extremity of each face.

5th. The profiles of the angles will be deducted by simple prolongations, and the same for the profiles of the gorge. If the homologous crests of two contiguous faces do not meet each other, they should be reconciled by joining two points taken on each of them at half a meter from the inter of their projections.

6th. On the traverse, designed to secure the defenders from a reverse fire, two profiles are constructed, near to its extremities if its crest is a right line, but if it is bent, another profile must be set up at the junction.

7th. The data of all these profiles are, the relief of the interior crest at the point where it is encountered by the profile, the thickness of the parapet, the constant parts of every profile, and the natural slope of the ground; the portion of the slope of the traverses exposed to the view of the dominant heights should not be reveted, the others should be.

8th. At the points of inter of the profiles with the projections of the ridges of the works, as well as at the points used for adjusting, poles or pickets are placed, on which the points belonging to the ridges are marked. These points will be joined together in each profile by twine, indicating the different planes of the work.

9th. The form and dimensions of the batteries, either of barbettes or embrasures, will be equally determined by poles or pickets placed at all their angles, and united together by twine in the manner that will be subsequently explained.

10th. For the barbette batteries, the first thing to be done is to establish and to construct the front coupé of the salient of the interior crest, and substitute an interior horizontal crest throughout the extent of the barbette for that situated in the plane of defilement. The necessary adjustments are then made between the slope of the parapet of the barbette and that of the rest of the face, and indicate by means of twine the inters of the terre-plein of the barbette and of its slope with the different planes of the work.

11th. For the embrasures, after having determined their direction, the inters of the cheeks and bottom, with the interior and exterior slope of the parapet, and with its slope; also the slope which terminates the interruption of the banquette throughout the extent of the battery. In the case where the platform is formed more than 0^m 4 elevated above the soil, a ramp is constructed with its slope, and the inters with the slope from the platform are shown.

12th. After the batteries, the slope of the ends of the traverses and of the passages for entry and exit are constructed.

13th. The traverse will be finished by adjusting its different planes with 189 those of the parapet. In the particular case, where it was interfered with to make a passage over the banquette, it is finished by reveting the slope passing by the crest of the banquette of the work.

14th. At the passages of entry and exit from the work, the parapets will be finished by the slope of the revetment, whose inters with the different planes of the parapets must be determined.

15th. For each squad of workmen, the distance of the salient of the work to the point on which it will be defiladed must be determined.

MEMOIR.

1st. Object of defilement—which is considered to be dangerous ground, dangerous point, plane of defilement.

2d. Position of the dangerous point relatively to the work which is to be defiladed. Practical method on the ground. Results to which it leads.

3d. On the field this method is not always applicable to an isolated work, and never is so to entrenchments of a great development, such as lines, large têtes-de-pont, &c. By what proceeding is it generally expedient to attempt to fulfill in war the indisputable condition of defilement.

RECAPITULATION FOR THE SUB-LIEUTENANTS OF ARTILLERY AND ENGINEERS.

* The number 90 is applied to the interrogations and to the obligations of the notes.

RECAPITULATION OF THE CREDITS OF INFLUENCE.

4th. Methods of defilement employed. Determination of the different planes of barbettes, of their ramps, of the profiles of the gorge, &c. Construction of embrasures.

5th. Means made use of in practice for determining the distance of the salient of the work to the dangerous point on which it is defiladed.

V.—PROGRAMME OF PERMANENT FORTIFICATION, AND THE ATTACK AND DEFENSE OF PLACES.

The course of instruction in Permanent Fortification and the Attack and Defense of Places, is divided into three parts, viz:—

The first part contains a description of the various works of permanent fortification, their respective uses, and the changes that have been successively made in them, together with a short history of ancient fortification prior to the invention of powder, and the changes introduced by the use of fire-arms.

The systems of Errard, Beville, Pagan, Vauban, Cochorn, and Cormontaigne.

The first of the second part describes the principles on which the various parts of a front of fortification on level ground, and according to Cormontaigne’s system, are regulated, such as the command, relief, defilement, form, length, and material of which the various parts should be constructed; the modifications required by the absence or presence of water; the changes which are necessary as regards exterior or advanced works, and ending with a comparison of a front of fortification according to Cormontaigne, with a modification of the same system introduced by the French engineers.

The second commences with the principles of defilement and its application under various given circumstances, proceeds with the description of an imaginary work founded on certain given data, and furnishes the data of its proposed construction. It then supplies the theory relating to mines, and their use in the attack, defense, and destruction of places, and points out the particular duties of engineers in fortified places, and the proper and most efficient manner of carrying them on.

The third relates to the preparation of projects for the improvement of inefficiently fortified places, and to the utility, particular organization, and proper position of fortified places on a frontier line. It then explains the necessity for military law in providing for the security of fortified places and districts along the frontiers of a state.

The third part describes the various operations connected with the attack and defense of a bastioned fortification, commencing with the operations preliminary to the siege and investment of the place, and continuing to describe the 191 several processes to be employed in the attack of the place, with the corresponding efforts that should be made during its defense, and ending with an historical account of certain sieges.

This course requires the practical completion of the following:
